- Page 1 PN-HW861 PN-HW751 PN-HW651 PN-HW551 PN-HW501 PN-HW431 LCD MONITOR OPERATION MANUAL...
- Page 2 Batteries are collected at points of sale. Return is free of charge. If the equipment has been used for BUSINESS PURPOSES, please contact your SHARP dealer who will inform you about take-back. You might be charged for the costs arising from take-back. Small equipment (and small quantities) might be taken back by your local collection facility.
-
Page 3: Important Information
NO USER-SERVICEABLE PARTS product. INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. [PN-HW861/PN-HW751/PN-HW651] FOR CUSTOMERS IN U.K. IMPORTANT The wires in this mains lead are coloured in accordance with the following code: GREEN-AND-YELLOW: Earth BLUE:... -
Page 4: Dear Sharp Customer
DEAR SHARP CUSTOMER Thank you for your purchase of a SHARP LCD product. To ensure safety and many years of trouble-free operation of your product, please read the Safety Precautions carefully before using this product. SAFETY PRECAUTIONS Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. - Page 5 An apparatus with CLASS I construction shall be connected to a MAIN socket outlet with a protective earthing connection. (PN-HW861/PN-HW751/PN-HW651) STABILITY HAZARD If a monitor is not positioned in a sufficiently stable location, it can be potentially hazardous due to falling. Many injuries, particularly to children, can be avoided by taking simple precautions such as: •...
-
Page 6: Tips And Safety Instructions
- Never rub or tap the monitor with hard objects. Doing so could result in electric shock. - Please understand that SHARP CORPORATION bears no - Unplug the power cord if it is not used for a long time. responsibility for errors made during use by the customer or... -
Page 7: Mounting Precautions
• Mounting the monitor on the wall requires special expertise the right side (PN-HW861/PN-HW751/PN-HW651/PN- and the work must be performed by an authorized SHARP HW551/PN-HW501) or the top side (PN-HW431). dealer. You should never attempt to perform any of this work - Set the THERMAL SENSOR SETTING on the SETUP yourself. -
Page 8: Table Of Contents
USB flash drive cover: 1 USB flash drive cover fixing screw: 1 * SHARP Corporation holds authorship rights to the Utility Disk program. Do not reproduce it without permission. * For environmental protection! Do not dispose of batteries in household waste. Follow the disposal instructions for your area. -
Page 9: Part Names
Part Names nFront view nRear view [PN-HW861] [PN-HW751] 20 19 [PN-HW651]... - Page 10 Part Names [PN-HW551] 20 16 [PN-HW501] [PN-HW431]...
- Page 11 15. IR output terminal (See page 13.) control sensor directly to store it inside the monitor. 16. Anti-theft hole ( ) Allows the monitor to be secured using a commercially 18. Handles (PN-HW861/PN-HW751 only) (See page 16.) available anti-theft lock. 19. Vents 20. Speakers nRemote control unit 1.
-
Page 12: Connecting Peripheral Equipment
Connecting Peripheral Equipment 1. RS-232C input terminal Caution • You can control the monitor from a computer by • Be sure to turn off the main power switch and disconnect connecting a commercially available RS-232 straight the plug from the power outlet before connecting/ cable between this terminal and the computer. - Page 13 Connecting Peripheral Equipment 7. HDMI1 input terminal 8. HDMI2 input terminal 9. HDMI3 input terminal • Use a commercially available HDMI cable (conforming to the HDMI standard) that supports 4K. • When HDMI is selected, it is not necessary to connect an audio cable to the audio input terminal.
-
Page 14: Connecting The Power Cord
• Use only the power cord supplied with the monitor. 1. Turn off the main power switch. 2. Plug the power cord (supplied) into the AC input terminal. 3. Plug the power cord (supplied) into the power outlet. [PN-HW861/PN-HW751/PN-HW651] [PN-HW551/PN-HW431] [PN-HW501] Main power... -
Page 15: Attaching The Usb Flash Drive Cover
Attaching the USB flash drive cover 1. Insert the USB flash drive into the USB port. USB port 2. Attach the USB flash drive cover and secure with the provided screw (x1). [PN-HW861/PN-HW751/ PN-HW551/PN-HW501]: Hole B [PN-HW651]: Hole A [PN-HW431]: Hole C... -
Page 16: Attaching The Logo Sticker
You can attach the supplied logo sticker on this monitor. Refer to the following example to attach the sticker as necessary. Example for landscape orientation Example for portrait orientation Removing the Handles (PN-HW861/PN-HW751 only) The handles can be removed. Handle Handle screws Caution •... -
Page 17: Preparing The Remote Control Unit
• Use manganese or alkaline batteries only. Remote control operation range Remote control sensor out Point the remote control unit toward the remote control sensor. For the monitor in landscape orientation For the monitor in portrait orientation [PN-HW861] Remote control 16.4 feet sensor (5m) 16.4 feet (5m) 16.4 feet (5m) - Page 18 The remote control can be operated even when the remote control sensor is stored inside the monitor. Point the remote control unit toward the remote control sensor. For the monitor in landscape orientation For the monitor in portrait orientation [PN-HW861] Remote control 9.8 feet sensor (3m) 9.8 feet...
- Page 19 Preparing the Remote Control Unit [PN-HW751/PN-HW651/PN-HW551/PN-HW501] 9.8 feet (3m) 10º 10º 9.8 feet Remote control 30º (3m) sensor 10º 10º 9.8 feet (3m) 9.8 feet Remote control 30º (3m) sensor 10º 10º10º 10º [PN-HW431] 10º 10º 30º 9.8 feet 9.8 feet (3m) 9.8 feet (3m) 9.8 feet...
-
Page 20: Turning Power On/Off
MONITOR ON button/MONITOR OFF button on the remote button off and back on, always wait for at least 5 seconds. control unit. A short interval may result in a malfunction. [PN-HW861] Turning on the main power [PN-HW861/PN-HW751/PN-HW651] Power LED POWER button... - Page 21 Turning Power On/Off nOperation mode When the monitor is turned on for the first time after being shipped from the factory, the operation mode setting screen will be displayed. Set it to MODE1 or MODE2. MODE1 ..OFF IF NO OPERATION is set to ON, and POWER SAVE MODE is set to ON.
-
Page 22: Basic Operation
Basic Operation 5. VOLUME +/- (Volume adjustment) Press + or - to adjust the volume. 6. INFORMATION Displays monitor information. 7. FUNCTION Disable the MONITOR BUTTONS LOCK and REMOTE CONTROL LOCK. (See page 30.) 8. ENTER Confirms the setting. 9. FREEZE This is not used with this monitor. - Page 23 Basic Operation 16. BRIGHT +/- (Brightness adjustment) Press + or - to adjust the brightness. 17. INPUT (Input mode selection) The menu is displayed. Press the button to select the input mode, and press the ENTER button to enter. * You can change the input mode by pressing the INPUT button of the monitor.
- Page 24 Basic Operation nSwitching the screen size Even when the screen size is changed, the display may remain the same depending on the input signal. WIDE Displays image so it fills the entire screen. ZOOM The image is enlarged to fill the entire screen without changing the aspect ratio. The edges of the image may be cut off.
-
Page 25: Using Media Player
Using Media Player Playing files You can play photo, music, and video files in a USB flash drive connected to the monitor. There are the way to play the specified files/folders and the way to play as auto playback. TIPS You can also play Music file during Photo file display. -
Page 26: Auto Playback
Using Media Player Auto playback Operations during play Photos or video in a USB flash drive can be played When playback starts, you can display the operation bar in the automatically. bottom of the screen by pressing the [square] button. You can perform the actions below while the operation bar is displayed. -
Page 27: Menu Items
Menu Items Displaying the menu screen 4. Press the button to adjust the setting, and press the RETURN button. Video and audio adjustment and settings of various functions PICTURE are enabled. This section describes how to use the menu items. See page 28 for details of each menu items. COLOR MODE ADVANCED BRIGHT... -
Page 28: Menu Item Details
Menu Items Menu item details The menu will differ depending on the input mode. nPICTURE COLOR MODE Changes the color mode on the screen. The color mode on the screen can also be changed using a remote control unit. (See page 22 for details.) ADVANCED SIZE This is the same setting as when SIZE button is pressed. - Page 29 Menu Items nAUDIO TREBLE Adjusts the volume of treble-level sound. BASS Adjusts the volume of bass-level sound. BALANCE Adjusts the balance of the audio sound between right and left. SPEAKER Selects the speaker to be used. AUDIO OUTPUT Sets the volume of sound output from the audio output terminals. VARIABLE ..You can adjust the volume using VOLUME.
- Page 30 Menu Items SCREEN AUTO (D-SUB) The CLOCK, PHASE, H-POS, and V-POS are automatically adjusted. Pressing the ENTER button performs adjustment. Use this automatic adjustment when you use the D-SUB to display a computer screen for the first time or when you change the setting of the computer. (See page 32.) CLOCK (D-SUB) Adjusts frequency for sampling clock for applicable video.
- Page 31 Menu Items Specifies whether to light the power LED. INFORMATION Displays monitor information. ALL RESET Resets the settings to the factory default settings. TIPS • When WHITE BALANCE is set to THRU, BLACK LEVEL, CONTRAST, TINT, COLORS, GAMMA, PRESET and USER cannot be set.
-
Page 32: Adjustments For Computer Screen Display
Menu Items Adjustments for computer screen display nAutomatic adjustment When you use the D-SUB to display a computer screen for the first time, or when you change the setting of the computer, use the automatic screen adjustment. 1. Switch the input to D-SUB and display the adjustment pattern. -
Page 33: Controlling The Monitor With A Computer (Rs-232C)
Controlling the Monitor with a computer (RS-232C) You can control this monitor from a computer via RS-232C The current value can be returned by using “?” as the (COM port) on the computer. parameter. Example: TIPS From computer to monitor (How VOLM ? ? ? ? ←... -
Page 34: Rs-232C Command Table
Controlling the Monitor with a computer (RS-232C) RS-232C command table How to read the command table Command: Command field (See page 33.) Direction: W When the “Parameter” is set in the parameter field (see page 33), the command functions as described under “Control/Response Contents”. R The returned value indicated under “Reply” can be obtained by setting “????”, “ ?” or “???+” (repeater control) in the parameter field. (See page 33.) Parameter: Parameter field (See page 33.) Reply: Response (Returned value) * : When POWER SAVE MODE is set to OFF: “●/○” : I ndicates a command which can be used in standby mode or when the power is on. “–” : I ndicates a command which can be used when the power is on. Cannot be used in standby mode. When POWER SAVE MODE is set to ON: “●” : I ndicates a command which can be used in standby mode or when the power is on. - Page 35 Controlling the Monitor with a computer (RS-232C) Others Function Command Direction Parameter Reply Control/Response contents VOLUME VOLM 0-31 0-31 MUTE AUDIO MUTE 0-1 0: OFF, 1: ON Temperature sensor DSTA 0 Internal temperature normal 1 Internal temperature abnormal has occurred and the monitor is in standby mode 2 Internal temperature abnormal occurred (To delete the information of temperature ●...
-
Page 36: Controlling The Monitor With A Computer (Lan)
Controlling the Monitor with a computer (LAN) Command-based control Your monitor can be connected to a LAN allowing you to control it from a computer on the LAN. The connection requires a commercially available LAN cable You can control the monitor using RS-232C commands (UTP cable, Category 5, straight through). -
Page 37: Troubleshooting
Internal temperature 38.) rises quickly if the vents on the monitor are blocked. - Internal temperature rises quickly if dust accumulates inside the monitor or around the vents. Remove dust if possible. Ask SHARP dealer about removing internal dust. -
Page 38: Specifications
Specifications nDDC (plug and play) The monitor supports the VESA DDC (Display Data Channel) standard. DDC is a signal standard for plug and play between monitors and computers. Information about resolution and other parameters is exchanged between the two. This function can be used if the computer supports DDC and it has been configured to detect plug-and-play monitors. - Page 39 Specifications nCompatible signal timing (AV) Screen resolution Frequency HDMI 4096 × 2160p 24Hz 25Hz 30Hz 50Hz 59.94Hz 60Hz 3840 × 2160p 24Hz 25Hz 30Hz 50Hz 59.94Hz 60Hz 1920 × 1080p 24Hz 50Hz 59.94Hz 60Hz 1920 × 1080i 50Hz 59.94Hz 60Hz 1280 ×...
- Page 40 Specifications nHDMI input terminal pins nD-sub input terminal pins (HDMI Connector) (Mini D-sub 15 pin) Function Function Function Function TMDS data 2+ TMDS clock shield Red video signal input TMDS data 2 shield 12 TMDS clock- Green video signal input 10 GND TMDS data 2- 13 CEC...
-
Page 41: Mounting Precautions (For Sharp Dealers And Service Engineers)
Mounting Precautions (For SHARP dealers and service engineers) • When installing, removing or moving the monitor, ensure that this is carried out by at least 2 people. (PN-HW861/PN-HW751: at least 3 people.) • Be sure to use a wall-mount bracket designed or designated for mounting the monitor. - Page 42 PN-HW861-HW751-HW651-HW551-HW501-HW431 Me EN18L(1)
