Step 8. Attach the mounting feet (H1-H4) to the legs (G1-G4) using M16x85 bolts, washers, and
nuts.
8.
Installation
The truck rack mounts on pick-up trucks with short or long beds. *Note: Will not work with step-side
beds.
Step 1. Measure your truck bed and adjust the truck rack legs to the appropriate positions.
Step 2. Set the truck rack on the bed rails with or without padding underneath to prevent paint
scratching. Line up the support legs so that they sit level with the cab and are evenly straight. Fully
tighten the eight M16x85Bolts (K).
Step 3. Secure the J-Bolts (O) to the inside of your bed rails, making sure they grab onto your vehi-
cle's attaching inside lips. The rack can also be permanently mounted to the bed rails by drilling into
the truck and securing it with hardware (not included).
Rev. 062618
DiscountRamps.com • 1-888-651-3431
Page 6
