Apex Digital UPUT-RACK-V2 Instructions Manual page 2

Parts
A
B
C
D
E
F
Part Description
A Cab Hoop
B Front Side Rail
C Rear Side Rail
D Front Bar
E Center Bar
F Rear Bar
G1 Front Left Leg
G2 Front Right Leg
K
L
M
Part Description
K (1) M16x85 Bolt, (2) 16mm Flat Washer, (1) M16 Lock Washer, (1) M16 Nylock Nut
L (1) M12x55 Bolt, (1) 7/16" USS Flat Washer, (1) M12 Nylock Nut
M (1) M10x70 Carriage Bolt, (1) 3/8" SAE Flat Washer, (1) M10 Nylock Nut
N (1) M10x20 Carriage Bolt, (1) M10 Nylock Nut
(1) M12 J-Bolt, (1) 7/16" USS Flat Washer, (1) M12 Lock Washer, (1) M12 Hex Nut
O
Rev. 062618
Quantity
1
2
2
1
1
1
1
1
Hardware Sets
DiscountRamps.com • 1-888-651-3431
G1 G2
G3 G4
Part Description
G3 Back Left Leg
G4 Back Right Leg
H1 Front Left Mounting Foot
H2 Front Right Mounting Foot
H3 Back Left Mounting Foot
H4 Back Right Mounting Foot
I Connecting Bracket
M10x25 Turn Knob, M10 Flat Washer,
J
M10 Lock Washer
N
H1 H2
H3 H4
Quantity
O
Quantity
12
12
2
10
8
Page 2
I
J
1
1
1
1
1
1
2
2
