Apex Digital RCB-3745-U Instructions

Strap-attached roof cross bars

Advertisement

Parts

A
B
D
Part
Description
A
Foot
B
Foot Pad
C
End Cap
D
Tie Strap
E
Clamp Strap

Assembly

Step 1. Place a protective foot pad
on the bottom of each foot.
Step 3. Slide a tie strap loop-end first over one end
of the roof bar and a clamp strap over the other end.
These straps will join together inside the vehicle.
Please Note: The telescoping model TRCB-4460-U requires the telescope bar and
carrier bar to be bolted together in the center at a desired telescope length.
Rev. 062018
Strap-Attached Roof Cross Bars
Instructions for Part # RCB-3745-U,
TRCB-4460-U
C
E
Quantity
4
4
4
2
2
(1)
(3)
DiscountRamps.com • 1-888-651-3431
F
H
I
Part
Description
F
Bolt
G
Lock Nut
H
Carrier Bar
I
Telescope Bar*
*For Model TRCB-4460-U only
Step 2. Tap the end caps onto the carrier bar.
Step 4. Bolt each foot pad to the roof bars and
pull strap until loop slides up against the foot.
G
Quantity
4
4
2
2
(2)
(4)
(5)
Page 1
