Page 1: Table Of Contents
ORION BEAN DOSER™ OPERATION MANUAL V 1.13.30 Contents Chapter 1: Introduction Chapter 2: Getting Started Chapter 3: Operations Chapter 4: Settings Chapter 5: Calibration... -
Page 2: Chapter 1: Introduction
The Orion Bean Doser™ is designed for dosing green beans or roasted coffee beans based on weight. Fast Weight-Based On-Demand Dosing The Orion Bean Doser™ can dose 225 grams (1/2 lbs) in 12 seconds and 20 grams in 3 seconds within the error margin of 2-3 beans. Full Automatic Mode Designed with a fully automatic mode for continuous dosing of multiple containers without pressing any buttons. - Page 3 , you may want to add some beans with the pulse function or remove the target amount some. Red Light - System message indicator When the red light is displayed, there is a system error with the Orion. Restart the Orion. If the problem persists, please contact us at support@acaia.co.
- Page 4 1.5 Buttons Button Function Example Turn On Short press to turn on the Orion Turn Off Double press to turn off the Orion Set/Save Preset Short press to set/save preset weight Power Weight Button Set Modes Long press to switch Manual/Auto Mode Save the Setting and Short press to save the Setting and go back to Menu Back to Menu...
-
Page 5: Chapter 2: Getting Started
Chapter 2: Getting Started 2.1 Initial Setup 1. Prior to using your Orion for the first time you should rinse and clean the bean hopper in warm soapy water. Dry immediately after cleaning. 2. Attach the bean hopper on top. 3. -
Page 6: Chapter 3: Operations
Chapter 3: Operations 3.1 Basic Operations Action Operation Turn On Scale Short press Power Turn Off Scale Double press Power Toggle Presets Rotate Dial Set Preset Weight Short press Power, rotate Dial, then short press Power/Dose Switch Mode Long press Power, rotate Dial, then short press Power/Dose Start Dosing Short press Dose Reset Mode... - Page 7 There are 2 different modes in the Orion for operation — Manual dosing mode and Auto dosing mode. You may set different modes using the controls above. 3.1.3 Empty Hopper Action Operation Empty Hopper Long press Dose Stop Emptying Short press Dose Back to Preset Short press Power To empty the bean hopper, you can long press the Dose button.
- Page 8 1. Select a preset by rotating the Dial. Adjust the preset value by short pressing Power and rotating the Dial. Short press Power to confirm. 2. Press Dose, and the Orion will begin dosing until desired weight is reached within +/- 0.5 g (Solid Green LED will display to indicate an accurate dose).
- Page 9 Action Operation Pulse Beans Short press Dose; this action can be repeated several times Reset Mode Short press Power to return to preset selection display Display Action/Description Place container on the platform; dosing will start when weight is detected 1. Switch into automatic dosing mode by long pressing Power and selecting the Auto mode with the Dial.
- Page 10 3.2.3 Weighing Mode The weighing mode is the Orion’s smart scale mode. It will function like an industrial weighing scale with a 3000-gram capacity. To switch to weighing mode, rotate the Dial until a ‘W’ indicator appears on the top left corner of the display. Action Operation Tare...
-
Page 11: Chapter 4: Settings
Chapter 4: Settings 4.1 Accessing the Orion’s Settings 4.1.1 How to Enter the Settings Menu 1. With Orion powered on, long press Power to enter the Settings mode. The display will show [ SEt ]. 2. Press Dose to enter the Settings Menu. It will show the first setting for [ SPEEd ]. Action Operation Enter Setting Mode... - Page 12 Zero Tracking Setting [ trAcE ] Zero Tracking is a function to help compensate the weight readout fluctuations at zero point to improve the usability of the scale. The Acaia Orion is allowed to compensate fluctuations by up to 2d according to industrial weighing guidelines.
-
Page 13: Chapter 5: Calibration
* Note: Calibration weights of 100 g, 1000 g, 1500 g, 2000 g, and 3000 g can also be used. For highest accuracy use Acaia calibration weights or F1 or F2 Class calibration weights. Inexpensive lower-class calibration weights have a higher deviation from a true... - Page 14 Appendix: Display Codes Error Codes List Error Code Description Code error EEPROM error AD read error Over load: The weight is over the maximum capacity. Under load: The weight is under the minimum capacity. Unable to make zero point because the initial weight exceeds the limit (250% of capacity).
- Page 15 This Operation Manual is protected by copyright. All rights reserved. No part of the operation manual may be reproduced, processed, duplicated or published in any form by photocopying, microfilming, reprinting or any other method, in particular electronic means, without the written agreement of Acaia. © Acaia, California, 2019.
