acaia ORION BEAN DOSER Operation Manual

Hide thumbs Also See for ORION BEAN DOSER:

Advertisement

Quick Links

Download this manual See also: Operating Manual
OPERATION MANUAL
Contents
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ORION BEAN DOSER and is the answer not in the manual?

Questions and answers

Related Manuals for acaia ORION BEAN DOSER

Summary of Contents for acaia ORION BEAN DOSER

  • Page 1: Table Of Contents

    ORION BEAN DOSER™ OPERATION MANUAL Contents Chapter 1: Introduction Chapter 2: Getting Started Chapter 3: Operations Chapter 4: Settings Chapter 5: Calibration...

  • Page 2: Orion Bean Doser

    The controls and settings menu can all be accessed through the dial interface. Weighing scale mode The Orion Bean Doser™ can function as a smart industrial weighing scale with a 3000 g capacity. Intelligent dosing: Based on previous target weights and actual outputs, the Orion will automatically adjust and decrease the margin of error.
  • Page 3 Dosing Error Margin ~ 2 beans (+/- 0.5 g) Battery Li-lon 18650 7.4V 2600mAH Measuring Units g, oz Display Connectivity Bluetooth 4.0 Input 12 Vdc, 2.0 A Warranty 1 Year 1.3 Interface & Buttons Power Button Modes Presets Indicators Dose Button Rotate 1.4 LED Indicators Green Light - Dosing progress indicator...

  • Page 4: Chapter 2: Getting Started

    When the red light is lit, there is a system error on the Orion. Restart the Orion by unplugging and plugging back in. If the problem persists, please contact us at support@acaia.co Orion is charging Bluetooth connection indicator Measured in Oz.
  • Page 5 There are two dosing mode in the Orion — manual mode and auto mode. To choose between modes, long press the Power button and the display will show the current mode of operation. Rotate the dial to toggle between modes. Manual Dosing Mode This is the default mode of dosing.

  • Page 6: Chapter 3: Operations

    5. Remove the completed dose and container, and wait for the display shows [ READY ] again. 6. Place another container on top of the platform and it will automatically dispense another dose. 7. Press the Power button to set a different dose and leave the current auto dosing session.
  • Page 7 Action Operation Turn On Scale Short Press Power Turn Off Scale Double Press Power Toggle Presets Rotate Dial Set Preset Weight Short Press Power, rotate Dial, then short Press Power/Dose Switch Mode Long Press Power, rotate Dial, then short Press Power/Dose Start Dosing Short Press Dose Reset Mode...
  • Page 8 Action Operation Switch Mode Rotate Dial Set Mode Short Press Power/Dose The Orion has 2 dosing modes: Manual dosing mode and Automatic dosing mode. You may change the modes with the controls above. 3.1.3 Empty the Hopper Place container on the platform and dosing will start when weight detected Action Operation Empty the hopper...

  • Page 9: Chapter 4: Settings

    Action Operation Enter Ready State Short press Dose Start Dosing Short press Dose Stop Dosing Short press Dose Pulse Beans Short press Dose to add a few beans as needed Reset Mode Short press Power, return to preset mode Automatic dosing mode can dose automatically whenever a container is placed on the platform. There will be an ‘A’...
  • Page 10 Action Operation Enter Set Menu Long press Power and rotate the dial to SEt. Press Dose to enter Settings menu. Enter Speed Settings When Speed is displayed, short press Dose to enter Speed menu. Toggle Speed Options Rotate the dial to toggle between dosing options. There are 3 speed settings: Precision, Fast, and Green.

  • Page 11: Chapter 5: Calibration

    The operation manual is protected by copyright. All rights reserved. No part of the operation manual may be reproduced, processed, duplicated or published in any form by photocopying, microfilming, reprinting or any other method, in particular electronic means, without the written agreement of Acaia. © Acaia, California, 2018.
