Track length 38 ft 9 in (11,8 m)
Hide thumbs Also See for Pneumatic Track System:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
Pneumatic Track System
Track length 38 ft 9 in (11,8 m)
INSTRUCTION MANUAL
PTS
144265(04)
2010-12-17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pneumatic Track System and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nederman Pneumatic Track System

Summary of Contents for Nederman Pneumatic Track System

  • Page 1 Pneumatic Track System Track length 38 ft 9 in (11,8 m) INSTRUCTION MANUAL 144265(04) 2010-12-17...
  • Page 2 min. 1 ft min. 1 ft 1 ft 4 in - 2 ft 1 ft 4 in - 2 ft (0,3 m) (0,3 m) (0,4 - 0,6 m) (0,4 - 0,6 m) Alternative 1 Alternative 2 ~ 3 ft (1 m)
  • Page 3 292 lbs 292 lbs 292 lbs (1300 N) 292 lbs (1300 N) (1300 N) 292 lbs (1300 N) (1300 N)
  • Page 4 Alternative 2 exit...
  • Page 5 exit 12 ft 6 in (min. 3,8 m) 9 a - e Vehicle in parking position 1/6 in Compressed (Ø 4,5 mm) air pressure regulator 87 – 116 psi (6 – 8 bar) Disconnection valve...
  • Page 6 Diagram for 87-116 psi (6-8 bar) 6-8 bar (87-116 psi) compressed air Pressure regulator 14,5 psi (1 bar) 1 bar (14,5 psi) Disconnection valve Air vent Pneumatic nozzle Nozzle kit Manual valve min. 2 in (50 mm) min. 4 in (100 mm) min.

  • Page 7: Declaration Of Conformity

    • The system must not be used when working on the vehicle´s fuel system or whenever there is a We, AB Ph. Nederman & Co., declare under our sole risk of inflammable dust or explosive gases. responsibility that the Nederman product: •...

  • Page 8: Before Installation

    Fit the hose holder on the hose possible. Please contact your Nederman represen- minimum 12 ft 6 in (3,8 m) from the balance cord (see tative for advice on fan selection.

  • Page 9: Spare Parts

    A tail pipe stop is mandatory. The tail pipe stop should be assembled according to Spare parts instruction enclosed in the package of the product. See www.nederman.com When ordering parts always state: Compressed air connection • Part no. and control no.

  • Page 10: Installation And Maintenance Procedure

    INSTALLATION AND MAINTENANCE PROCEDURE The system is ready for use after checking the control points according to this protocol. Check the points 3A – 3P at least twice a year or when necessary. PTS Article no. / Control no. Date Operating hours Performed by Control points...
  • Page 11 112 lbs (500 N) (= solid hand force, see picture B). Clean and grease the safety coupling if necessary. If the operation is not correct, please contact a Nederman representative for technical advice. Make sure the compressed air hose has enough slack to cope with the hose stretching without bee- ing pulled out of the safety coupling valve nipples.
  • Page 12 Nederman is represented in: Australia, Austria, Bahrain, Belgium, Brazil, Bulgaria, Canada, China, the Czech Republic, Cyprus, Denmark, Egypt, Estonia, Finland, France, Germany, Greece, Hong Kong, Hungary, Iceland, India, Iran, Ireland, Italy, Japan, Korea, Latvia, Lithuania, Malaysia, the Netherlands, Norway, Philippines, Poland, Portugal, Romania, Russia, Saudi Arabia, Serbia &...
