3 Specifications

DC Voltage
Rated Current
Rated Power
Ripple & Noise
Output
Voltage Regulation
Source Regulation
Load Regulation
Setup, Rise Time
Power off Protection Trip Time
Interface Type
Voltage Range
Starting Voltage
Frequency Range
Input
Power Factor
Leakage Current
Interface Type
Low-voltage Input
Output Short Circuit
Protection
Output Overcurrent
Overheat Protection
Environment Operating Temperature
Conditions
Operating Humidity
Structure Dimensions
Weight
Cooling Fan Size
Air Blowing Direction
APW3-12-1600 Series
12V
133A
1600W
<1%
<2%
<1%
<1%
<5S
>10mS
12 pairs of 6 pin PCI-E connectors. 450mm
length for each PCI-E cable.
176-264V AC
200-205V AC
47-63Hz
>0.95 (full load)
<1.5mA (220V 50Hz)
IEC320-C13
171-181V AC
Yes
134-150A
Yes
-20-50 ºC @ 100%,
-20-60 ºC @ 80% load (refer to
Load/Temperature graph)
20% - 90% RH (non-condensing)
332mm*87mm*41mm
2.3kg
40mm*40mm*28mm
From AC input to DC output
