- Page 1 BITMAIN APW3-12-1600 PSU Series User Guide...
-
Page 2: Table Of Contents
APW3-12-1600 Series Contents Overview ........................... 3 Features ............................. 3 Specifications ..........................4 Switching On/Off Remotely ....................... 5 Order Information & Wire Type ....................6 Order Information ......................6 Wire Types ........................6 Trouble Shooting & FAQ ......................7 Precautions for Use ........................8 May 14, 2015 Version 1.1... -
Page 3: Overview
APW3-12-1600 Series 1 Overview The APW3-12-1600 series AC-DC PSU combines high efficiency and good dynamic performance into a power dense package. It also features overload, overheat, overcurrent and low voltage protection, making it well suited to 12V, ≤1600W power devices. -
Page 4: Specifications
APW3-12-1600 Series 3 Specifications DC Voltage Rated Current 133A Rated Power 1600W Ripple & Noise <1% Output Voltage Regulation <2% Source Regulation <1% Load Regulation <1% Setup, Rise Time <5S Power off Protection Trip Time >10mS Interface Type 12 pairs of 6 pin PCI-E connectors. 450mm length for each PCI-E cable. -
Page 5: Switching On/Off Remotely
APW3-12-1600 Series Max Load vs. Ambient Temperature Graph (220V input) Max Load vs Input Temperature Current(A) Current(A) Temperature(℃) Efficiency vs Load (220V input) Efficiency Efficiency 94.0% 93.0% 92.0% 91.0% 90.0% Efficiency 89.0% 88.0% 87.0% Load(A) 86.0% 4 Switching On/Off Remotely The PSU turns on automatically by plugging it into the mains. -
Page 6: Order Information & Wire Type
APW3-12-1600 Series closing the circuit turns the machine on, and breaking the circuit turns the machine off. Remote On/Off Method 2: 5V sb PSU supports an external MCU, which controls a transistor or MOSFET to manage the ON/OFF pins to switch the PSU ON/OFF remotely. The PSU will turn on once power is provided to the 5V sb pin. -
Page 7: Trouble Shooting & Faq
APW3-12-1600 Series 6 Trouble Shooting & FAQ Issue Reason Troubleshooting Fan won’t run, and no AC Input is abnormal 1. Make sure the AC input wire has a good 12V output connection and the plugs are connected firmly 2. Make sure the mains power is working well and its voltage is above 205V. -
Page 8: Precautions For Use
APW3-12-1600 Series 7 Precautions for Use 1. Before using the PSU, please ensure that the voltage and power outputs are compatible with your equipment. 2. Please ensure that the PSU appears to be in good shape and has not suffered damage in transit. - Page 9 APW3-12-1600 Series May 14, 2015 Version 1.1 Page 9 / 9...
