Summary of Contents for Manhattan 175586
- Page 1 Serial PCi Card with 5 V Power outPut uSer manual Model 175586 MAN-175586-UM-0308-01...
- Page 3 Thank you for purchasing this MANHATTAN Serial PCI Card with 5 V ® Power Output, Model 175586. The easy-to-follow instructions in this manual help make installation of the card quick and simple, so you’ll also soon be enjoying the benefits of these features: •...
- Page 4 Windows 9X/Me Installation Verification & Frequency Setting 1. Right-click My Computer on the desktop, then select “Properties” and click on the Device Manager tab. 2. Double-click “Multifunction adapters.” If no yellow exclamation point (!) or question mark (?) appears in front of “OX16PCI954 PCI UARTs (unique bars)”...
- Page 5 Windows 2000/XP 1. Turn off the computer. 2. Insert the Serial PCI Card into an available PCI slot. 3. Turn the computer back on. 4. Insert the driver CD in the CD-ROM drive. 5. When the Install Wizard displays the window with a “Found New Hardware”...
-
Page 6: Specifications
SPeCifiCationS • 32-bit / 33 MHz fully complaint PCI host interface; PCI V3.0 • Superset and backward compatible with 16C550, 16C650, 16C750 and 16C850 • 128-Byte deep FIFO per transmitter and receiver • 128Rx and 128Tx interrupt and 128 flow control thresholds •... - Page 8 ® of PC Components, Peripherals, Cables and Accessories. Ask your local computer dealer for more information or visit us online at www.manhattan-products.com Copyright © MANHATTAN All products mentioned are trademarks or registered trademarks of their respective owners.
