- Page 1 Please leave these instructions with the user Baxi Bermuda Inset 3 Range Fireside Gas Central Heating Units Installation and Servicing Instructions TS, BS & KS...
- Page 2 Everyone who works at Baxi has a commitment to quality because we know that satisfied customers mean continued success. We hope you get a satisfactory service from Baxi. If not, please let us know. Baxi is a BS-EN ISO 9001...
-
Page 3: Table Of Contents
Contents Section Page Introduction Technical Data Site Requirements Fireplace Opening Hearth Mounting Ventilation Installation Initial Preparation Gas Supply Fitting the Fire Arranging the Coals Arranging the Coals Commissioning the Fire Arranging the Coals (cont) Checking for Spillage Checking for Spillage The Spillage Checking Procedure Possible Causes of Spillage Completion... -
Page 4: Introduction
1.0 Introduction Description 1. The Baxi Bermuda Inset 3 TS, Inset 3 BS, Inset 3 KS and Inset 3 FS are combined gas fired central heating boiler and gas fire units, designed for installation in a living room with a heat input of 6.52kW (22,246 Btu/h) at maximum setting. -
Page 5: Technical Data
2.0 Technical Data Bermuda Inset 3 TS Bermuda Inset 3 BS Bermuda Inset 3 KS Bermuda Inset 3 FS The fire is set for Gas Type G20 at 20mbar. Heat Input High 6.52 Btu/h 22,246 13,989 Setting Pressure Cold mbar B.S. -
Page 6: Site Requirements
460mm Min 3.0 Site Requirements 560mm Max Fireplace Opening Fireplace 560mm Opening 1. The principal site requirements are determined 590mm by the boiler unit, but the following details are essential for the correct installation of the fire unit: Fireplace Opening (Fig. 2): Height: 560mm (22in) min Fireplace Opening... -
Page 7: Ventilation
3.0 Site Requirements Ventilation 1. Ventilation air supply to BS 5440 Pt 2 is required. The permanent ventilation area size requirements are as shown: 80.1cm 12.42in 2. The permanent vent may be directly into the room containing the appliance. The vent may also be sited in another (not a bedroom, toilet, bathroom or kitchen) room provided an interconnecting vent is used. -
Page 8: Installation
4.0 Installation Fire Surround Initial Preparation 1. Unpack the fire unit from the box. The fire surround, coal bed and fender assembly are packed in individual boxes within the main carton Bottom Fire Surround and should be left in these boxes until required. Fig. - Page 9 7. Turn the control knob to the off ( ) position. Disconnect the pressure gauge and replace the BAXI Bermuda Inset 3 pressure test point sealing screw, ensuring a gas Fire and Boiler tight seal (Figs. 13 & 14).
-
Page 10: Arranging The Coals
Keep the coals away from children at all times. Never use coals other than those originally supplied or Genuine Baxi Spare Parts. Never put additional coals on the fire. Rear Coal Side Please read section 1.3 Important Information. -
Page 11: Arranging The Coals (Cont)
6.0 Arranging the Coals Finial Arranging the Coals (cont) Fender Fender 7. At this point it is necessary to fit the fender assembly. 8. Remove the fender from its packing (Fig. 20) (on FS models screw the finials to the fender assembly). -
Page 12: Checking For Spillage
7.0 Checking for Spillage Checking for Spillage CAUTION - Whilst checking for spillage care must be taken to avoid touching hot panels. 1. Before checking for spillage the worst likely operating environment for the appliance must be created. To do this, close all doors and windows in the room and operate any ceiling or extractor fans that may be present, on the wall or within other appliances. -
Page 13: Completion
7.0 Checking for Spillage Completion 1. Replace the controls access door (Fig. 24). 2. These instructions and the users instructions should be handed to the customer. At the same time the customer should be shown how to operate the fire and boiler safely and efficiently. 3. -
Page 14: Annual Servicing
Keep the coals away from children at all times. Never use coals other Gas Tap Elbow than those originally supplied or Genuine Baxi Fig. 26 Spare Parts. Never put additional coals on the fire. Please read section 1.3 Important Information. -
Page 15: Annual Servicing
8.0 Annual Servicing Preparation (Cont) 8. Remove the two screws inside the flue spigot (Fig. 31). 9. Slide the fire combustion box forward to disengage it from the flue spigot and lift away (Fig. 32). Boiler Hood Removal of Controls (Fig. 33) Flue 1. -
Page 16: Cleaning The Burner & Injectors
2.5 - 4.0mm. 4. The thermocouple cannot be changed as an individual component. The complete assembly must be replaced in the event of one or other component failure(s). Pilot/A.S.D. Fig. 36 Assembly 5. Only use a Genuine Baxi Spare Part. -
Page 17: Cleaning The Combustion Box & Coals
8.0 Annual Servicing Firebed Base Panel Cleaning the Combustion Box & Coals 1. Remove any deposits from the firebed base panel (Fig. 37). 2. If necessary the coals can be cleaned with a very soft brush, and can be retouched using the black stain supplied with the fire. -
Page 18: Changing Components
Keep the coals away from children at all times. Never use coals other Controls Access Door than those originally supplied or Genuine Baxi Fender Assembly Spare Parts. Never put additional coals on the Fig. 42 fire. -
Page 19: Pilot/A.s.d. Assembly
9.0 Changing Components Pilot/A.S.D. Assembly 1. Undo the three retaining screws and remove the controls assembly from the fire combustion box (Fig. 48). NOTE: On refitting the controls assembly, ensure that the tongue on the controls mounting plate engages in the corresponding slot in the combustion box lower panel. -
Page 20: Gas Tap
Keep the coals away from Fig. 54 children at all times. Never use coals other Circlip than those originally supplied or Genuine Baxi Spare Parts. Never put additional coals on the fire. -
Page 21: Fault Finding
10.0 Fault finding Fault Finding Does Does Fire the fire the fire START operating remain ignite ? satisfactorily alight Turn on gas supply there a Open gas cocks gas supply gas cocks spark at fully open ? turned Correct electrode on ? Clean spark gap... -
Page 22: Short Parts List
10.0 Short parts list Short Parts List Key G.C. Description Manufacturers Part No. E25 260 Gas Tap/FFD Assy 244950 E01 353 Spark Generator 239289 E01 617 Electro Magnetic 239413 Unit 156 347 Knob Control 236295 E60 865 Burner Assy 247238 379 914 Oxypilot SIT OP 9402 238087... - Page 23 Baxi UK Limited manufacture a comprehensive range of products for the domestic heating market Gas Central Heating Boilers (Wall, Floor and Fireside models). Independent Gas Fires. Renewal Firefronts. Gas Wall Heaters. Solid Fuel Fires. If you require information on any of these products,...
- Page 24 Comp N 247612 - Iss 3 - 9/01 After Sales Service 08706 096 096 Technical Enquiries 08706 049 049 Baxi UK Limited Brownedge Road Bamber Bridge Preston Lancashire PR5 6SN www.baxi.com...
