5112258/01
OWNER GUIDE
Model 739
Heat Engine
(GC No. 32-032-54)
OPEN DECORATIVE
GAS FIRE
THIS APPLIANCE IS FOR USE WITH NATURAL GAS (G20)
WHEN CONVERTED USING CONVERSION KIT NO. 0595211 THIS
APPLIANCE IS FOR USE WITH PROPANE GAS (G31)
THIS APPLIANCE IS SUITABLE ONLY FOR INSTALLATION IN THE UNITED
KINGDOM (GB) AND THE REPUBLIC OF IRELAND (IE).
For technical advice firstly contact your retailer. If further advice is required then call
0161703 8157 for The Midlands and North or
01462 813 138 for The South.
This guide is intended to help you care for your gas fire. Please read thoroughly before
using and keep for future reference.
owner
INSTALLER: Please leave this guide with the
© Baxi Heating U.K. Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 739 and is the answer not in the manual?

Questions and answers

Related Manuals for Baxi 739

Summary of Contents for Baxi 739

  • Page 1 01462 813 138 for The South. This guide is intended to help you care for your gas fire. Please read thoroughly before using and keep for future reference. owner INSTALLER: Please leave this guide with the © Baxi Heating U.K. Ltd.
  • Page 2 Installer Guide and should not be fitted directly on to a carpet. Baxi Fires Division, Erdington, Birmingham B24 9QP Because our policy is one of constant development and improvement, details may vary slightly from those given in this publication...

  • Page 3: Table Of Contents

    OWNER GUIDE LIST OF CONTENTS Section Page SAFETY GAS CONSUMPTION OPERATING THE FIRE The Oxysafe flame sensing and flue blockage safety system. To light the fire. Lighting with a taper. CLEANING YOUR FIRE Metal parts. Burner. Ceramic fuel effect. CERAMIC FUEL EFFECT FITTING FITTING THE LOWER FIREFRONT MAINTENANCE Regular maintenance.

  • Page 4: Safety

    OWNER GUIDE SAFETY IF YOU SMELL GAS DON’T SMOKE EXTINGUISH ALL NAKED FLAMES DON’T TURN ELECTRICAL SWITCHES ON OR OFF TURN OFF THE GAS SUPPLY AT THE METER OPEN DOORS AND WINDOWS TO GET RID OF THE GAS IMMEDIATELY CALL THE GAS EMERGENCY SERVICE - SEE YOUR LOCAL TELEPHONE DIRECTORY Do have the fire installed by a competent person.

  • Page 5: Gas Consumption

    Has a maximum natural gas input of 6.85kW (Gross) Has a minimum natural gas input of 2.3kW Model 739 when converted using kit number 0595211 Has a maximum propane gas input of 6.7kW (Gross) Has a minimum propane gas input of 4.0kW...

  • Page 6: Operating The Fire

    OWNER GUIDE OPERATING THE FIRE PLEASE NOTE When operating your fire for the first time, some vapours may be given off which may cause a slight odour and could possibly set off any smoke alarms in the immediate vicinity. These vapours are quite normal with new appliances. They are totally harmless and will disappear after a few hours use.

  • Page 7: Lighting With A Taper

    OWNER GUIDE turn back (clockwise) to the Pilot ignition position. The main burner should extinguish but the pilot should remain alight. Depress the control knob slightly and turn back (clockwise) to turn OFF. This will extinguish the pilot. While cooling, the ceramic fuel effect may make some crackling noises. This is quite normal.

  • Page 8: Cleaning Your Fire

    OWNER GUIDE CLEANING YOUR FIRE Turn the fire off and allow it to cool completely before attempting any cleaning. Note that the fire will retain heat for some time after it has been turned off. If large pieces of debris are found anywhere in the fireplace, have the chimney inspected before further use.

  • Page 9: Ceramic Fuel Effect Fitting

    OWNER GUIDE CERAMIC FUEL EFFECT FITTING The installer and owner guide for the ceramic fuel effect is separate from this guide. The installer may have attached it to this guide or placed it inside. It is important that the installer and owner guide for the ceramic fuel effect is followed correctly. If replacing the ceramic fuel effect, where a new guide is supplied, follow the installer and owner guide supplied with the replacement fuel effect.
  • Page 10 OWNER GUIDE If you wish to replace any of the ceramic fuel effect pieces, spare parts are available nationwide via the ‘interpart stockist network’. For your local stockist consult Yellow pages under Central Heating. When fitting replacement parts it is important that only approved parts are used for maximum safety.
