Snapper 421622BVE Parts Manual page 9

ITEM
1*
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21*
22
23
24
25
26
27
28
29
30
31
32
33
--
--
--
*NOTE: 5-9203 Cover & Fender Assembly is composed of items 1 & 21.
42" MODEL R. E. RIDER SERIES 22
PART NO. DESCRIPTION
5-4372 ASSEMBLY, R.H. Fender Bearing & DX Bearing
9-0362 SCREW, 1/4-20 x 5/8" Hex Washer Self-Tap (13)
3-1079 WASHER, Thrust
1-0969 NUT, 5/16-24 Hex Flange Lock
3-8067 PLATE, Differential
2-2115 SPACER, Pinion (8)
2-1127 GEARS, Differential Pinion (8)
1-1072 WASHER, Thrust
5-1584 ASSEMBLY, Drive Hex Tube
1-0988 WASHER, Hex Insert
1-0964 GEAR, 11 Teeth-10 Pitch
1-0941 CHAIN, 46 Pitch (#35)
2-1129 SPROCKET
1-0965 RING, 1-13/16" External Retaining
2-1128 SPACER
1-2332 CLAMP, Boot (for 2" Hose) (2)
1-7083 BOOT, Oil Seal
1-1024 PLUG, Oil Fill & Check
3-7279 CASE, Transmission
2-8762 GASKET, Transmission Case
3-7280 FENDER, Right Hand
2-7644 GEAR, 63 Teeth-10 Pitch
4-7763 AXLE, Long (Includes Gear)
(Use Only With Short Axle #5-7398)
7-4431 SPACER
5-7398 AXLE, Short (Includes Gear)
(Use Only With Long Axle #4-7763)
1-2333 SCREW, 5/16-24 x 1-5/8" Hex Cap Special Lock (8)
1-1156 O-RING, 5/16 (2)
1-1782 WASHER, Belleville (2)
9-0395 WASHER, 5/16" External Tooth Lock
9-0188 WASHER, 5/16" Flat
1-1042 BOLT, 5/16-24 x 2-5/8" Idler
9-0361 SCREW, 5/16-18 x 5/8" Hex Washer Self-Tap (11)
6-1017 GREASE, SNAPPER Transmission (24 oz. Required)
5-7260 ASSEMBLY, Differential (Includes items 5, 6, 7, 23,
24, 25, & 26)
6-0662 KIT, Differential (Incl.1-8822, Ball Bearing & 3-7957, Fender)
6-0411 KIT, Differential (Includes 1-2296, Powdered Metal Bearing for item 1 and
3-7280, Fender)
DIFFERENTIAL, R.H. FENDER
9
MANUAL No. 06130
