User manual
EN
Mode d'emploi
FR
Instrucciones de manejo X
ES
4
X
SCD589

Advertisement

Table of Contents

   Related Manuals for Philips SCD589

   Summary of Contents for Philips SCD589

  • Page 1 SCD589 User manual Mode d’emploi Instrucciones de manejo X...
  • Page 3 Important 13 Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: A.When the power supply cord or plug is damaged or frayed. B. If the product has been exposed to rain or water. C.
  • Page 5 A. Baby unit B. Parent unit...
  • Page 6: Legend Of Functions

    Legend of functions A. Baby unit On/Off button (y) Temperature sensor LINK light Volume – / + buttons PAGE button Microphone Night light button ( Lullaby button ( ) Play/stop button (2 9) A-10 Night light A-11 Display A-12 Battery compartment cover A-13 DC 9V / 300mA power supply jack A-14 AC power adapter B.
  • Page 7 Legend of functions C.What else you need Both units can be battery operated. For battery-operated use you’ll need: – 4 x 1.5V AA non-rechargeable batteries for baby unit. Not supplied. – 2 x 1.2V AAA rechargeable batteries for parent unit. Supplied. D.
  • Page 8: Table Of Contents

    Contents 22 Important information Important Safety Instructions Technical specifications Illustrations Maintenance Environmental information Legend of functions Factory initialization mode Baby unit Compliance information Parent unit Radio Interference What else you need FCC RF Radiation Exposure Statement Display Need help? Contents 25 Guarantee and service Welcome Service centers...
  • Page 10: Parent Unit

    2 Insert four 1.5V AA batteries, noting the + and – configuration inside the battery compartment (batteries are not supplied; we recommend Philips Alkaline batteries). 3 Put the battery compartment cover (A-12) back in place. Close the compartment by turning the cover (A-12) to the right (CLOSE 2), using the palm of your hand.
  • Page 11: Parent Unit

    Getting your baby monitor ready for use 5 Place the parent unit in the charging base (B-15). > The POWER light (B-16) lights up red. 6 Leave the parent unit in the charging base until the batteries are fully charged (at least 16 hours). >...
  • Page 12: Other Features

    Using your baby monitor 3 Press and hold the On/Off button (y) (B-6) on the parent unit for 2 seconds. > The sound level lights (B-9) briefly light up orange. > The display (B-8) lights up.The battery indicator ( ) and the room temperature light up in the display.
  • Page 13: Talking To Your Baby

    Other features > The displays (A-11, B-8) give visual feedback on the volume settings of the units: - VoluMe OFF: parent unit volume switched off / monitoring baby silently; - VoluMe 9: minimum volume (parent unit and baby unit); - VoluMe 9 9 9 9 9: maximum volume (parent unit and baby unit).
  • Page 14: Switching Night Light On/off

    Other features > When sound is detected the sound-level lights (B-9) light up orange. Switching night light on/off 1 Briefly press the night light button ( ), A-7) on the baby unit to switch on the night light (A-10). lights up on both displays. >...
  • Page 15: Connecting / Disconnecting Belt Clip And Neck Strap

    Other features 2 Briefly press the play/stop button (2 9, A-9) to play the selected lullaby. • Briefly press the OK button (B-7) on the parent unit to interrupt playback of the lullaby. Press the play/stop button (2 9, A-9) on the baby unit or the OK button (B-7) on the parent unit again to restart playback of the lullaby.
  • Page 16: Menu Options

    Other features Connecting the neck strap • Insert the little spindle at the end of the neck strap into the recess (B-11) on the rear of the parent unit. Turn the spindle to the left until it clicks in position. Disconnecting the neck strap •...
  • Page 17: Switching Night Light On/off

    Menu options 4 Press the MENU button (B-2) again to exit the menu. Note: Always press the buttons MENU (B-2), – and + (B-10) and OK (B-7) shortly. Switching night light on/off • Select Light on? or Light oFF?, using – and + (B-10).
  • Page 18: Switching Sound Alert On / Off

    Menu options Switching sound alert on and off If sound alert is switched on, the parent unit beeps as soon as the second sound level light (B-9) lights orange while the volume is switched off. • Select Sound Alert, using – and + (B-10). Confirm with OK (B-7).
  • Page 19: Troubleshooting

    Troubleshooting Problem Possible cause Solution LINK light (A-3, B-3) Parent unit: does not light at all. Power adapter (B-14) not Connect power adapter (B-14) to plugged in. wall outlet. Unit not turned on. Press and hold On/Off button (y) (B-6) for two seconds. Batteries are low.
  • Page 20 Troubleshooting Problem Possible cause Solution High pitched noise. Units are too close to each Move parent unit away from baby other. unit (at least 1 meter / 3 feet). Volume on parent unit Decrease volume (B-10) on set too high. parent unit.
  • Page 21: Frequently Asked Questions

    Frequently asked questions Question Answer The technical specifications The specified range is only valid outdoors in open air. Inside show an operating range of your house the workable range is limited by the amount and 300 meters / 900 feet outdoors. type of walls and/or ceilings in between.
  • Page 22: Important Information

    Important information Technical specifications Power supply – 1 x AC power adapter DC 9V / 300mA for baby unit (supplied). – 1 x charging base DC 9V / 300mA for parent unit (supplied). – 4 x AA 1.5V Alkaline batteries for baby unit. (not supplied). NiMH –...
  • Page 23: Environmental Information

    Important information Environmental information Disposal of your old product Your product is designed and manufactured with high quality materials and components, which can be recycled and reused. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC.
  • Page 24: Compliance Information

    Important information Default factory settings Parent unit – Loudspeaker volume: 1 – Microphone sensitivity: 5 (maximum) – Sound alert: on – Temperature alert: off Baby unit – Loudspeaker volume: 3 – Nightlight: off – Lullaby: 1 – Temperature alert low: 14°C –...
  • Page 25: Guarantee And Service

    Guarantee & service If you need information or if you have a problem, please visit the Philips website at www.philips.com or contact the Philips Customer Care Centre in your country (you will find its phone number in the worldwide guarantee leaflet). If there is no...
