Installation Guide
5/816/24/48-Port PoE
Switch
Package Contents: Switch, Power cord, QIG, Rackmount Kit(except 5/8-port Model).
Note: For simplicity, we will take WI-PS518GF for example through this Guide .
LED Explanation
Power
On: Power on
Off: Power off
PoE/Link
Yellow
Green
For 100M port:
Yellow light Solid On: Power supplying for PD.
Green light Solid On: PD connected to the PoE port,
but no data transmission.
Flashing: Data transmitting.
For 1000M port:
Yellow light Solid On: Running at 1000Mbps.
Green light
Solid On: Running at 100Mbps.
Flashing: Transmitting/receiving data.
SFP
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wi-Tek WI-PS518GF
Summary of Contents for Wi-Tek WI-PS518GF
-
Page 1: Installation Guide
Yellow light Solid On: Running at 1000Mbps. Green light Solid On: Running at 100Mbps. Flashing: Transmitting/receiving data. Package Contents: Switch, Power cord, QIG, Rackmount Kit(except 5/8-port Model). Note: For simplicity, we will take WI-PS518GF for example through this Guide . - Page 2 A3: The cable must be less than 100 meters long (328 feet) if it doesn’t support the Extend function . Warranty Card The PIN definition of Wi-Tek PoE For managed model, If you want to configure L2 advanced function, please launch a browser and type 192.168.0.1 into address bar. The default username and password are both admin in lower case.
