EC900 Series Operation Manual
V4.7

14.0 USB and RS485 COMMUNICATIONS

The USB port is a bi-directional high speed communications port which allows operator intervention
via a communication utility called Systech_Illinois_Client Utility. This communication utility is included
on the Memory Stick supplied with the analyzer. Also supplied is a USB data connection cable.
If you do not have the Memory stick, the software can be downloaded from our website, please
contact Systech / Illinois Instruments to obtain the required customer log in details. The USB data
communication cable is standard USB A to USB B cable.
However before the USB cable is plugged into your PC you MUST install the necessary driver
software. This is again available on the Memory Stick supplied and is called CDM20600.exe

14.1 Installing the USB Driver Software

Open Memory stick using your computers explorer and double click on autorun.exe From the
memory Stick distribution screen (below); click on USB Driver Software as shown below:-
You will then be presented with the following screen. Click on the "USB Driver Software Button" and
you will be presented with a window similar to the one shown here.
