Technical Specification contd.
Suitable Gases:
EC9x1
Display:
Sample connections:
Ambient Temperature:
Sample Gas Inlet
Pressure:
Power:
Area Classification:
Communications:
Dimensions:
OPTIONS
High / Low Alarms:
Analogue outputs:
Flow Alarm:
Auto Calibration
(option):
Bypass Flowmeter:
Sample Pump
Stainless Steel
Fittings
www.systechillinois.com
EC900 Series Operation Manual
EC9x2
4 Digit high visibility LED
1/8" OD compression (Swagelok)
-5°C to 50°C (Instrument and sample gas)
3.5 – 29 PSI (0.25 Bar - 2 Bar)
Ambient (for pump equipped systems)
90-260 VAC, 40VA
General Purpose
USB 1.0 / 2.0 and RS485
Refer to the drawing B900 176 at the rear of the manual Appendix 1.
Two with volt free c/o contacts fully
configurable over the complete oxygen range,
one fault alarm.
Contact rating 5A @ 250VAC/30VDC
Software configurable over the entire oxygen range for either :
Current: 4-20mA isolated
Current 0-20mA isolated
Thermal Mass Flow sensor
Allows connection to a cylinder of gas with a certified level of oxygen.
Analyzer will correct to recorded level at programmed intervals.
Improves the response time of the analyzer due to sample transport lag by
adding a fast side stream.
Allows the instrument to be used in situations where there is no pressure to
the sample gas.
Allows the instrument to be used in situations where the sample gas will
react with either brass or copper fittings and pipes. Note: stainless steel
flowmeter and regulator will also be required.
EC9x0
All gases except corrosive gases
All gases except corrosive and/or
EC9x3
acidic gases
