Installation, Operating and Servicing
Instructions
Silverlink 600 Electric Bains Marie
Dry Heat
BA3-A004, BS3-A004, BA4-A004,
BS4-A004, BA7-A005, BS7-A005,
BM3-A003, BM4-A003, BM6-A003,
BM7-A004, BM7X-A001
Wet Well
BS3W-A005, BS4W-A005, BS7W-A005,
BM3W-A005, BM4W-A005, BM6W-A005,
BM7W-A005, BM7XW-A001
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________
IS 221 ECN4315
Page 1 of 8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Silverlink 600 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lincat Silverlink 600

  • Page 1 Installation, Operating and Servicing Instructions Silverlink 600 Electric Bains Marie Dry Heat BA3-A004, BS3-A004, BA4-A004, BS4-A004, BA7-A005, BS7-A005, BM3-A003, BM4-A003, BM6-A003, BM7-A004, BM7X-A001 Wet Well BS3W-A005, BS4W-A005, BS7W-A005, BM3W-A005, BM4W-A005, BM6W-A005, BM7W-A005, BM7XW-A001 Please make a note of your product details for...
  • Page 2: Table Of Contents

    WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips.
  • Page 3: Warnings And Precautions

    WARNINGS AND PRECAUTIONS This appliance must be Installed, Commissioned and Serviced by a qualified person in accordance with national and local regulations in force in the country of installation. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified person.
  • Page 4: Checklist Of Enclosures

    CHECK LIST OF ENCLOSURES Warranty Card Instructions Manual Drain Pipe (Wet Well models only) INSTALLATION AND COMMISSIONING This appliance must be earthed. An equipotential bonding terminal is provided to allow cross bonding with other equipment. Fig 1 IS 221 ECN4315 Page 4 of 8...
  • Page 5: Operating Instructions

    Install this appliance on a level surface ensuring all vents are unobstructed. Any partitions, walls or furniture must be of non-combustible material. Minimum distances A 100mm B 500mm – see Fig 1. This appliance is fitted with adjustable feet for levelling. If replacing the plug connect the terminals as follows: Green and Yellow wire Earth Blue wire...
  • Page 6: Cleaning

    Turn the control knob to maximum and heat up for 20 minutes. Adjust the temperature to the desired level. Place hot food into the containers. Wet Well Models Always ensure the drain tap is fully closed to the left. Add water to a depth that covers around 10mm of the base of the gastronorm or pot.
  • Page 7: Spare Parts List

    SPARE PARTS LIST Part Number Description Used on EL216 Element BA3, BS3, BA7, BS7, BM3, BM7 EL219 Element BA4, BS4, BM4, BM6 EL207 Element BS3W, BS4W, BM3W, BM4W EL152 Element BS7W, BM6W, BM7W EN10 Energy Regulator BA3, BS3, BA4, BS4, BA7, BS7, BM3, BM4, BM6, BM7 FE37 Adjustable foot...
  • Page 8: Service Information And Guarantee

    Type number All available on serial plate  Serial number Lincat reserve the right to carry out any work under warranty, given reasonable access to the appliance, during normal working hours, Monday to Friday, 08:30 to 17:00. GUARANTEE This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is in addition to, and does not diminish your statutory or legal rights.
