Red Line Instruments EZ100J Owner's Manual page 7

First start up:
The RED LINE
need to do before you start work is to put together the ForceFeed
system cup assembly before you connect up the compressed air line
and power supply.
Infrastructure required:
[a] A power connection – 100 – 260V AC 50/60Hz with earth (ground) –
with surge and spike protection
[b] Dry and clean compressed at air pressure of 1.5 – 2.0 kg/cm
(around 20 - 30 psi) pressure – NOT EXCEEDING 3 kg/cm
Please note that higher pressure may permanently damage the
pneumatic system inside the gun.
Carefully remove the equipment from its original packing
1.
Check everything that is supposed to be with the set has been
2.
supplied – see the Packing List on the facing page.
To assemble the cup with the ForceFeed components to the gun,
3.
first unscrew the 'black' lid off of the cup. This cup also contains one
'J' shaped metal pipe and a screw (with washer). Press down the
black lid on the cuplid-holder on top of the gun (the rubber 'O' rings
will secure the position and ensure that the joint is air-tight) and
align the 'screw' hole of the lid with that on the flat cup lid-holder on
the gun. This will also align the 2
a similar hole in the lid-holder.
With the screw provided, tighten and lock down this black cup-lid
4.
into place.
Now press down the plastic stud of the 'J' metal pipe into the 2
5.
hole – the rubber 'O' rings will hold this pipe in place. Turn the pipe
so that the open end of the pipe is aligned over the small plastic
stud of the lid.
Your gun is now assembled.
6.
Fill in the desired amount of powder in the powder cup (the powder
7.
cup has a capacity of approx 500 gms) and screw it onto the black
lid of the powder spray gun. You will have to hold the gun upside
down for this. Avoid any spillage of powder. Use of gloves is
recommended when handling powder coatings.
Set up your compressed air line to generate around 20-30 psi
8.
pressure and connect it to the base of the handle of the gun. In case
a Quick Release Coupling (QRC) has been provided, then fix the
EZ100J
is supplied virtually ready to operate. All you
nd
hole (the larger one) of the lid to
2
2
(42 psi).
nd
