Explosive Hazard: Do not use the ApneaLink Air system in an explosive atmosphere or in the presence of flammable anesthetics or gases. General warnings and cautions WARNING Do not use the system if any of the accessories are ripped, broken or bent or if the housing of the ApneaLink Air device is broken. CAUTION •...
Page 2
Oximeter (optional) Test complete Xpod ApneaLink Air interface The ApneaLink Air device has the following lights, connectors and button: Test complete indicator light Oximeter connector and accessory light Nasal cannula connector and accessory light Effort sensor connector and accessory light...
Page 3
Follow these steps if you are using the effort sensor: Test complete Test complete 2. Flip the device over. Thread the end of the belt closest to the 3. Fasten the tab to the belt. device through one of the slots on the effort sensor (if used). Slide the device into a position that is close to the effort sensor.
Page 4
Connecting the oximeter (if used) Test complete 1. Attach the oximeter finger 2. Attach the belt clip to the 3. Attach the oximeter to the oximeter connector on the device by sensor to the oximeter. oximeter. pushing it on. Fitting the belt CAUTION To avoid irritation or allergic reactions, wear the belt and device over a long-sleeved shirt.
Page 5
Fitting the accessories CAUTION If you develop redness, irritation or a rash from the nasal cannula or finger sensor, discontinue use and contact your healthcare provider or physician. You may be having an allergic reaction. Nasal cannula WARNING Ensure that the cannula is fitted as described so as not to pose a strangulation risk. 1.
Page 6
Disposable finger sensor (if used) WARNING Ensure that the oximeter clip is positioned on the same side of the body as the finger sensor so as not to pose a strangulation risk. 1. Remove the backing from 2. Place the sensor over the 3.
Page 7
Starting the test Test complete Test complete Test complete When properly set up, the full 1. Press and hold the power 2. Check that lights next to the system looks like this. button in the centre of accessories you are using the device for about three are green.
ResMed Corp 9001 Spectrum Center Boulevard San Diego CA 92123 USA. See www.resmed.com for other ResMed locations worldwide. For patent information, see www.resmed.com/ip. ApneaLink is a trademark of ResMed R&D Germany GmbH and is registered in U.S. Patent and Trademark Office.
