Candela Selection for P, S, PC, & SC series models
For strobe candela selection, adjust the slide switch located
on the rear of the product while watching the viewing win-
dow under the reflector on the front of the unit. Use Table
1 to determine current draw at various candela settings.
Table 2 can be used to derate the candela rating for low
temperature operation. Tables 3 & 4 can be used to deter-
mine strobe light output at various viewing angles.
Note: SpectrAlert products set at 15 and 15/75 candela au-
tomatically work on either 12V or 24V power supplies. The
products are not listed for 12V operating voltages when set
to any other candela settings.
Table 1. Current Draw (mA)
Candela
Strobe 15
(Standard 15/75
Candela 30
75
Range)
95
110
115
Strobe 135
(High 150
177
Candela
185
Range)
Table 2.
Listed candela rating
15 cd
15/75 cd
30 cd
75 cd
95 cd
110 cd
115 cd
135 cd
150 cd
177 cd
185 cd
Note: The 15, 15/75, and 30 cd settings are not intended
for use at temperatures below 32°F.
Table 3. Horizontal Plane Light Distribution for
Wall and Ceiling Applications
Horizontal Angle
0
45
90
Table 4. Vertical Plane Light Distribution
for Wall Applications
Vertical Angle
0
45
90
D690-03-00
8–17.5 Volts 16–33 Volts
DC FWR DC
123 128 66
142 148 77
NA NA 94
NA NA 158
NA NA 181
NA NA 202
NA NA 210
NA NA 228
NA NA 246
NA NA 281
NA NA 286
Candela rating at –40°F
See Note
9.8
16.2
29.7
41.4
44.6
49.5
81.4
72.2
% of rated light output
100
75
25
% of rated light output
100
34
12
Horn Selection for P, PC, & H series models
Horn setting selection is accomplished by using the rotary
switch on the back of the product (see Table 5). The current
draw for various horn settings for horn and 4-wire horn/
strobe products is listed in Table 6. The current draw for
various horn and candela settings for 2-wire horn/strobe
products (P2 series) is shown in Table 7 & 8. The sound
measurements for various horn settings are shown in Table
9 for horn and horn/strobe products.
Table 5. Horn Patterns
Setting
1 Temporal horn
2 Temporal horn
3 Temporal horn
4 Normal horn
FWR
5 Normal horn
71
6 Normal horn
81
7 Externally coded
96
8 Externally coded
153
9 Externally coded
176
Note: In positions 7, 8, and 9, temporal coding must be
195
205
provided by the NAC. If the NAC voltage is held constant,
207
the horn output will remain constantly on. Positions 7, 8,
220
and 9 are not available on 2-wire horn/strobe products.
251
258 Table 6. Horn Current Draw (mA)
Sound Pattern
Temporal
Temporal
Temporal
Non-temporal
Non-temporal
Non-temporal
Coded
Coded
Coded
Note: Ceiling products have their maximum brightness on
the two axes shown below.
2
Repetition Rate
High
Medium
Low
High
Medium
Low
High
Medium
Low
8–17.5 Volts
dB DC FWR
High 57 55
Medium 44 49
Low 38 44
High 57 56
Medium 42 50
Low 41 44
High 57 55
Medium 44 51
Low 40 46
dB Out
16–33 Volts
DC FWR
69 75
58 69
44 48
69 75
60 69
50 50
69 75
56 69
52 50
A0351-00
