20 DCD
18 RI
16 GND
Others /
NOTE
These test pins belong to 3.3V power domain.
UC20_EVB_User_Guide
Connected directly to UC20 Mini PCIe UART's CTS.
Converted from UC20-TE-A Main UART's DCD.
Connected directly to UC20 Mini PCIe UART's DCD.
Converted from UC20-TE-A Main UART's RI.
Connected directly to UC20 Mini PCIe UART's RI.
Ground.
Reserved.
