Connections
All ingoing and outgoing connections can be found at the rear panel of the instrument.
Name
Function
Ethernet
Connector for connecting the Ethernet cable to the PC/notebook.
USB
Connector for connecting the USB cable to the PC/notebook. Only
used for service by NanoTemper Technologies service.
When the switch is turned on (position "I"), the instrument is
Power Switch
switched on.
DC Input
The connector to the external power supply. Connect with the
external power supply.
8
