Specifications
Input external power supply: 90–264 VAC ± 10% 47–63 Hz, 230 VA max
Output external power supply: 12 VDC, 5.0 A max, 2.4 A typical
Electrical input Monolith NT.115 instrument: 12 VDC, 5A
Environmental
Operating temperature 15 – 30°C (Indoor use only)
Storage temperature -20 – 30°C
Humidity 0–80%, noncondensing
Operating altitude max 2000m
Monolith NT.115 size
Width 33 cm (13")
Height 45 cm (17.5")
Depth 51 cm (20")
Weight 24 kg (51 lbs) net
Power supply size
Width 10.6 cm (4.2")
Height 3 cm (1.2")
Depth 6.5 cm (2.6")
Power supply weight 0.23 kg (0.51 lbs) net max
IR laser
Wavelength: 1475 nm +/- 15 nm
Power: 120 mW max.
Monolith NT.115 laser classification
Device is LASER PRODUCT CLASS 1
Temperature control
Range: 22°C – 45°C (at Room Temperature 25°C)
Accuracy: +/- 0.3°C
Noise level of Monolith NT.115 instrument: max. 64 dB(A)
7
