Parts Included
Leg Package:
(4) Legs (2A and 2B)
(4) Leg Top Plates
(2) Feet
(4) Toe Caps
(1) Front Hand-crank Assembly
with Gearbox
(1) Top Crank Assembly
(2) Drive Shaft Assembly
(1) Hardware Bag
Table Package:
(1) Cross Brace
(2) Table Tops
Tools Needed:
#2 Phillips Screwdriver or
Power Driver
A S S E M B LY I NS TR UCTI ONS
ASSEMBLY INSTRUCTIONS
ASSEMBLY INSTRUCTIONS
EQUITY BI-LEVEL WORKSTATION
Computer workstation with hand-crank adjustment
Hardware
Hardware Bag with:
(2) Cross Brace Brackets
(8)
⁄
" Cross Brace
3
8
Bracket Fasteners
(4) #8 x 1
⁄
" Wood Screws
3
4
(16)
⁄
" x
⁄
" Fasteners
1
3
4
4
(44) #10 x 1" Screws for
Leg Top Plates
(8)
⁄
" x 1" Fasteners
5
16
(8)
⁄
" Lock Washer
5
16
(4) Levelers (or optional casters)
(1)
⁄
" Allen Wrench
5
32
(1)
⁄
" Allen Wrench
3
1 6
Advertisement
Related Manuals for Populas EQUITY BI-LEVEL WORKSTATION
Summary of Contents for Populas EQUITY BI-LEVEL WORKSTATION
- Page 1 A S S E M B LY I NS TR UCTI ONS ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS EQUITY BI-LEVEL WORKSTATION Computer workstation with hand-crank adjustment Parts Included Hardware Leg Package: Hardware Bag with: (4) Legs (2A and 2B) (2) Cross Brace Brackets ⁄...
- Page 2 STEP ONE Unpack and identify all parts. Place table tops upside down on padded surface and identify front edge. STEP TWO Identify the legs (A and B) and their orientation as shown in the diagram. Look at the bottom of the leg to identify the leg letter (A or B).
- Page 3 STEP FIVE Attach cross brace bracket to cross brace using four #8 1 ⁄ " screws as shown. #8 x 1 ⁄ " Wood Screw (x2) # 10 x 1 3/4" Wood Screw (x2) Attach cross brace bracket to rear legs as shown.
- Page 4 STEP SEVEN Attach mounting plates to tabletops using #10 x 1" screws. Leg A Leg B Leg A Leg A Leg A Leg B Leg B Leg B #10 x 1" Screws (x6) # 10 x 1" Screw (x6) Detail : D #10 x 1”...
