- Page 1 Instruction Manual ™ qpod 2e Temperature-Controlled Sample Compartment for Fiber Optic Spectroscopy 22910 East Appleway Avenue, Suite 4, Liberty Lake, WA 99019-8606 Tel: (509) 624-9290 • Fax: (509) 624-9488 • E-mail: quantum@qnw.com • Web: www.qnw.com...
-
Page 2: Table Of Contents
Table of Contents qpod 2e Temperature-Controlled Sample Compartment for Fiber Optic Spectroscopy Overview Items Included with Your Purchase System Setup Software Installation Optics System Operation Error Conditions Temperature Specifications Other Specifications Optical slits provided with the qpod Appendix 1: Computer Control... -
Page 3: Qpod 2E Temperature-Controlled Sample Compartment For Fiber Optic Spectroscopy
MPKIT - multipurpose kit The qpod 2e is constructed of a single molded a. 2 QCL-UV collimating lenses housing. A Peltier-controlled cuvette holder in the b. 2 QIL-UV imaging lenses... -
Page 4: System Setup
2e manual. The qpod 2e may be controlled using a USB cable. C. BATH 100 If you will be using USB to control the qpod 2e you must install the software before connecting the 1. submersible pump hardware to the computer, otherwise the 2. - Page 5 2e accessory kit to loosen the set screw Figure 2 - Fluorescence configuration (Figure 3). As shown in Figure 2, to set the qpod 2e up for 2. Remove the silver sleeve with a black end fluorescence measurements insert an imaging lens piece from the lens assembly.
- Page 6 assembly so the screw is more available. The may require minor adjustments to maximize steering screws compress an o-ring, permitting throughput. fine alignment of the end of the fiber relative to the lens. 5. Now, unscrew the silver sleeve from the black end piece revealing the SMA connector (Figure Figure 4 - Attaching the fiber optic to the SMA connector...
-
Page 7: System Operation
8.5 emission light. 7. Put the cover and cap on the qpod 2e. Note: The qpod 2e is intended to hold a cuvette 8. Turn on the submersible pump by plugging it with a standard wall thickness of 1.25 mm and total... -
Page 8: Error Conditions
[F1 ER 05] Cell T out of range (Sensor failure?) (~22 ⁰C) water through the Peltier heat exchanger, the qpod 2e will achieve temperatures in the range [F1 ER 07] Heat exchanger T out of range (Sensor of -15 °C to 105 °C. Somewhat lower temperatures failure?) ( -25 ⁰C) can be obtained using ice water. -
Page 9: Other Specifications
8.5 mm diameter lenses may be mounted on the lens from the bottom surface of the cuvette. Thus, for assemblies using the optional QFH filter holder. Figure 5. The optical slits provided with the qpod 2e... -
Page 10: Appendix 1: Computer Control
Appendix 1: Computer Control The qpod 2e responds to the same text commands as the other temperature controllers from Quantum Northwest, although obviously some related to sample changing or reference controllers are not functional. This is the complete software specification. - Page 11 Stirrer [F1 SS +] Turn stirrer on (stir rate must be set manually). [F1 SS -] Turn stirrer off. Temperature Control [F1 TC +] Turn temperature control on. [F1 TC -] Turn temperature control off. Target Temperature [F1 TT S 23.10] Set target temperature to 23.10 ºC.
- Page 12 Current Temperature [F1 CT ?] What is the current temperature of the holder? ..[F1 CT 22.84] The current temperature is 22.84 ºC. [F1 CT +3] Automatically report current temperature every 3 seconds. [F1 CT -] Stop periodic current temperature reports. Probe Status [F1 PS ?] Is there an external temperature probe connected?
- Page 13 ..[F1 ER 09] Syntax error on a preceding command. [F1 ER +] Automatically report errors when they occur [F1 ER -] Stop automatic error reports Ramping [F1 RS S 3] Set the time increment to 3 seconds (must be a positive integer). [F1 RT S 10] Set the temperature increment to 0.1 ºC (a positive integer, units are hundredths of a degree).
-
Page 14: Appendix 2: Q-Blue Program Commands
Appendix 2: Q-Blue Program Commands In addition to the controller commands of Appendix 1, Q-Blue provides the following functionality. 1. Enables generation of a temperature ramp at a user specified rate. 2. Maintains records of temperature as a function of time for the sample holder and for the thermistor probe (and also for the reference holder for the dual controller). - Page 15 [*WPT>=#] - Wait until the probe temperature exceeds or equals a particular value (# as an integer). [*WPT<=#] - Wait until the probe temperature decreases to or below a particular value (# as an integer). The probe temperature is the reading of the standard 400 series or 500 series probe plugged into the temperature controller.
- Page 16 Warning Control commands [*E+] or [*E-] - When a script is running, attempting to use certain of the buttons or other controls in the main window will cause the appearance of a dialog box asking if you are sure you want to send the associated command (thus changing the series of actions defined by the script).
- Page 17 Miscellaneous commands [*R] - This program command is used only at the end of a script. It will cause the script to be repeated, starting at the beginning. [*P] - If the plot window is displayed while a script is running, the data in the plot will not be automatically updated unless a delay (*D) or wait (*W) command is being processed.
-
Page 18: Appendix 3: Example Script: Temperature Ramping
Appendix 3: Example Script: Temperature Ramping The following is an example of a script file. Scripts may be used to automate complex functions such as the three-old ramping illustrated here. Any text that is not enclosed by square brackets ( [ ] ) is completely ignored by the script processor, permitting the extensive commenting. - Page 19 Ramping rate will be 0.2 °C/min (0.04 °C/ 0.2 min). [F1 PA S 0.5] Set Automatic Probe temperature report to every 0.5 °C. [F1 TT S 45.00] Set Target Temperature to 45 °C to start ramping process. [*WRP>=45] Wait until the ramp parameter reaches 45 °C. [*D 200] Wait 2 minutes for probe temperature to catch up.
- Page 20 [F1 PT -] Stop periodic probe temperature reporting. [F1 CT -] Stop periodic sample holder temperature reporting. [*E+] Enable appearance of a warning dialog if a main window button or control is used while a script is running. [F1 PX -] Reset display of probe temperature to 0.1 °C precision.
- Page 21 The absorbance data were obtained using a fiber-optic spectrometer, ® light source and software in combination with a QNW qpod 2e fiber-optic sample holder and the QNW Serial Control program. The temperature ramp and absorbance data collections were started “simultaneously” using...
- Page 22 0.48 0.46 0.44 0.42 0.38 0.36 0.34 tim e (m in) tim e (m in) 0.12 0.08 0.06 0.04 0.02 tem perature (deg C) Figure 3. Experimental data obtained for the melting transition of the synthetic alternating copolymer of deoxyadenosine and deoxythymidine, poly(dA-dT) using a linear temperature ramp.
