- Page 1 INSTRUCTION MANUAL PT1001 & PT1001-31 (General Transport Stretcher) Read and understand all of the instructions and safety information in this manual before operating this product. MAN-037 Rev C © 2017 MAC Medical, Inc. 11/2017...
-
Page 2: Table Of Contents
This manual provides the parts list, operation, cleaning and maintenance instructions for the General Transport Stretcher. This manual pertains to both the PT1001 (29” bed with) and the PT1001-31 (31” bed width). To place an order, contact our customer service department at 618-476-3550 or 877-828-9975 or by email at sales@macmedical.com... -
Page 3: Warnings And Cautions Icon Key
MAC Medical, Inc or by other manufacturers, unless such a combination has been specifically endorsed by MAC Medical, Inc. -
Page 4: Overall Stretcher Dimensions
Instruction Manual General Material Specifications of the PT1001 and PT1001-31 General Transport Stretcher Chassis Shroud: LDR33/1 552 ABS FS8039 Mattress Pad: Polyurethane Foam Core Wheel Lock Pedal: Hot Rolled Bar Stock Pedals: Flexible PVC Overall Stretcher Dimensions [1295.39 mm] [889 mm] 51”... -
Page 5: Parts List Of Pt1001 And Pt1001-31 General Transport Stretcher
Instruction Manual Parts List of PT1001 and PT1001-31 General Transport Stretcher The main structural and operational Stretcher components called out in the following illustrations are identified in the table on Page 7. The operational components will be covered in more detail in this installation manual. - Page 6 Instruction Manual Top view of the stretcher bed with Pad and Back Rest removed for clarity. Top view of the bottom half of the stretcher. Side view of the bottom half of the stretcher. MAN-037 www.macmedical.com...
- Page 7 ST0032 Pedal, Green STR0211-P Painted Brake Pedal Assembly ST0006F14 Stretcher Boot ST0006F5-02 Chassis Shroud ST0005-A Caster, Tente Directional ST0004 Caster, Tente Total Lock STR0600 I.V. Pole Assembly ST0058-PT1001 MAC General Transport Stretcher Decal Set (for PT1001 & PT1001-31) MAN-037 www.macmedical.com...
-
Page 8: Operation Of The Pt1001 General Transport Stretcher
Instruction Manual Operation of the PT1001 General Transport Stretcher 1. Height Adjustment A. The Height Adjustment Mechanism pedals are located on both sides of the stretcher. B. Raise the stretcher surface by depressing the height adjustment pedal downwards to the floor. - Page 9 (ST0004) which is included in the kit. See “Optional Accessories: Only standard MAC Medical accessories should be used on MAC Medical beds. Use of other non-MAC Medical products may cause damage or malfunction of the structure of the stretcher.” on page 15.
- Page 10 Instruction Manual 4. Back Rest Adjustment A. The Back Rest is raised by lifting upward on the red Release Lever located beneath the Back Rest section at the head-end of the stretcher and lifting the Back Rest section of the bed. B.
- Page 11 Instruction Manual 5. Rail Adjustment A. Side rails are raised from a folded position by simply pulling up the rail and pushing it forward until it locks securely into its fully extended position. Caution: Patients should not be left unattended until it is confirmed that both side rails are locked securely into its fully extended position.
- Page 12 Instruction Manual 6. Other Features IV poles provided with the stretcher are telescopic. Turn the knob to release the second tube and raise to desired height. Maximum extension of the pole (from IV hook to mounting stretcher socket) is 43 1/2”. Insert IV poles in the any or all of the six IV sockets.
-
Page 13: Fowler Adjustment For Pt1001 And Pt1001-31 General Transport Stretcher
Instruction Manual Fowler Adjustment for PT1001 and PT1001-31 General Transport Stretcher 1. At times, it may be necessary to adjust the Fowlers on the General Transport Stretcher. To do this, first unscrew the 4 screws securing the Fowler Release Cover. - Page 14 Instruction Manual 6. When the stretcher Release Lever is pulled back (as shown in the picture at left), the retaining pin is depressed. 7. The picture below shows the retaining pin (in red circle) being depressed by the Release Lever. 8.
-
Page 15: Stretcher Optional Features
K = Knee Gatch • Use a lubricant on the moving parts to allow free Example: PT1001 with features Knee Gatch and push movement of sliding parts and help reduce noise. handles would be order model #PT1001-K-PH. Cleaning The same for PT1001-31 would be PT1001-31-K-PH. -
Page 16: Transportation Damage And Claims
DEALING. packaged, in a way the product will not be damaged Liability of MAC Medical under this warranty is limited to the during transit to the factory. MAC Medical does not repair and / or replacement of any products. MAC Medical warranty any freight damage to or from the factory.
