After the separator, the goods are loaded onto pallets - each pallet is fitted with a tag. These
tags also contain user data that provides information about the sender and receiver of the
goods. Based on the data read by the SIMATIC RF670R reader, the pallets at the outgoing
goods gate are checked to make sure that they are intended for the receiver to which the
gate is assigned. Light barriers are installed to control the reader. Depending on the read
results of the reader, the outgoing portal opens, or it remains closed.
Summary of the features
Note
Note that the following features show sample values for the scenario. The specific data for
your application may deviate from these values.
Feature
Single-tag
Multi-tag
Read velocity
Tag orientation
Material characteristics
Reading ranges
Reader density
Interference
4.3

Antenna configurations

Note
Validity of antenna configuration
The following specifications for the antenna configuration only apply to the RF660A antenna.
See Section Guidelines for selecting RFID UHF antennas (Page 54) for specifications for the
configuration of third-party antennas.
4.3.1

Antenna configuration example

The following diagram shows an application example for an antenna configuration of the
RF670R. The antennas are positioned at the height at which the tags are expected which
are to be identified. The maximum width of the portal that is recommended for reliable
operation is 4 m.
SIMATIC RF600
System Manual, 05/2012, J31069-D0171-U001-A13-7618
RF600 system planning
4.3 Antenna configurations
No
Yes
2 m/s
Specified and not specified
Non-metal
Approx. 3.5°m
High
High
