The tiltable Control Panel consists of the Touch Screen, Built-in Speaker, which emits sounds
Power Button
1.
: The Power Button enables you to power the device on and off.
Home Button
2.
:
NFC Indicator
3.
:
Touch Screen
4.
:
Status LED
5.
:
XEROX ALTALINK C8000
The Control Panel Features
for a range of events, and Hard Buttons.
The white LED backlight indicates if the device is on, off, in low power or sleep modes.
The Home button returns you to the Home screen of the user interface.
The NFC Indicator is displayed if Near Field Communication is enabled.
The capacitive touch screen enables you to interact with the device by using very light finger
touches.
The color of the Status LED provides a visual indication of the status of the device.
It Flashes
BLUE
if:
a. A user has swiped a card for authentication
b. The device is powering on
c. A print job, copy job, or receive-fax job has completed
d. A mobile client is using AirPrint to locate the device
It flashes
AMBER
if:
a. The device has an error or shows an alert (levels of toner, staples or waste). The LED
flashes
b. on and off to indicate a more serious condition, which can require a call for service.
c. The device requires user attention. The LED fades in and out to indicate a less serious
condition.
