Lowtech Studios slither.io Operator's Manual page 47

156
160
159
161
157
155
162
158
Upper Back Door Assembly
ITEM NO. PART NUMBER
155 601-00809-01
156 800-00001-00
McMaster-Carr -
157
90272A201
McMaster-Carr -
158
90631A009
159 600-00043-01
McMaster-Carr -
160
90054A196
161 150-00001-00
McMaster-Carr -
162
90126A512
slither.io
DESCRIPTION
Upper Back Door
120mm Wire Fan Guard
Steel Phillips Rounded Head
Screws, 8-32 Thread Size, 1-1/4"
Long
Low-Strength Steel Nylon-Insert
Locknut, Zinc-Plated, 8-32
Thread Size
Lock Retainer Plate
Flanged Hex Head Screws for
Sheet Metal, Zinc-Plated Steel,
Number 8 Size, 5/8" Long
Standard Door Lock Assembly
(for 3/4" Panels)
Zinc-Plated Steel SAE Washer for
Number 8 Screw Size, 0.188" ID,
0.438" OD
QTY.
1
2
8
8
1
3
1
8
