Lowtech Studios slither.io Operator's Manual page 42

115
120
116
117
121
108
107
113
112
118
119
ITEM NO. PART NUMBER
106 600-02320-01
McMaster-Carr -
107
94639A330
108 500-00242-01
McMaster-Carr -
109
98019A309
McMaster-Carr -
110
90480A005
McMaster-Carr -
111
6338K453
112 600-02324-01
McMaster-Carr -
113
5906K563
McMaster-Carr -
114
99620A615
115 600-02323-01
116 600-02322-01
McMaster-Carr -
117
91249A144
McMaster-Carr -
118
92311A194
119 500-00241-01
120 608-00235-01
McMaster-Carr -
121
90251A541
110
109
114
111
106
DESCRIPTION
Main Bushing Bracket
Off-White Nylon Unthreaded Spacer, 5/16" OD,
1/8" Long, for Number 6 Screw Size
LED Spinner PCB
18-8 Stainless Steel Mil. Spec. Washer, Passivated,
Number 4 Screw Size, MS/NASM 15795-803
Low-Strength Steel Hex Nut, Zinc-Plated, 4-40
Thread Size
Oil-Embedded Flanged Sleeve Bearing for 5/16"
Shaft Diameter and 7/16" Housing ID, 3/8" Long
Spinner Shaft
Oil-Embedded Thrust Bearing, 5/16" Inside
Diameter, 5/8" OD, 1/16" Thickness
Heavy Duty Side-Mount External Retaining Rings
for 5/16" OD, Black-Phosphate 1060-1090 Spring
Steel
Spinner Weight
Opto Disc
Black-Oxide 18-8 Stainless Steel Pan Head Phillips
Screws, 6-32 Thread, 1/4" Long
18-8 Stainless Steel Cup-Point Set Screw, 8-32
Thread, 1/2" Long
USB Spinner PCB
Spinner Knob Assembly
Thread-Locking Cup-Point Set Screws, 18-8
Stainless Steel, 1/4"-20 Thread, 1" Long
slither.io
Spinner Assembly
(800-00070-01)
QTY.
1
2
1
4
4
2
1
2
2
1
1
1
1
1
1
2
