PIE 525Plus Specifications
Voltage Source
Ranges & Resolution -13.000 to 80.000 mV & -13.0000 to 80.0000 mV
Accuracy ±(0.008% of Setting + 0.006 mV)
Source Current ≥ 10 mA
Output Impedance < 0.3 Ohm
RMS Noise ≤ ± 0.0005 mV from 0.1 to 10 Hz
Short Circuit Duration Infinite
Voltage Read
Range and Resolution Same as Voltage Source
Accuracy ±(0.008% of Reading + 0.006 mV)
Input resistance ≥ 10 MΩ
Thermocouple Source
Accuracy ±(0.008% of Setting + 0.006 mV)
Cold Junction ± 0.09°F (±0.05 °C) - Thermistor traceable to
Compensation NIST for 11 years
Output Impedance < 0.3 Ohms
Source Current > 10 mA (drives 80 mV into 10 Ohms)
RMS Noise ≤ ± 0.0005 mV from 0.1 to 10 Hz
Thermocouple Read
Accuracy ±(0.008% of Reading + 0.006 mV)
Cold Junction ± 0.09°F (±0.05 °C) - Thermistor traceable to
Compensation NIST for 11 years
Input Impedance > 10 Megohms
Open Threshold: 15,000 Ohms nominal
Thermocouple Pulse: < 10 microamp pulse for 400 milliseconds
