Table Of Contents - PIE 525 Plus Operating Instructions Manual

Find Quality Products Online at:
Contents
General Operations
Connections ............................................................................ 4
Accessories ............................................................................. 5
Carrying Case, Boot, and Magnet Strap ................................. 6
Changing Batteries & Storing EZ-CHECK Outputs ................ 7
Basic Operation
Switches & Knobs ................................................................8-9
MAIN Menus - Functions, Units & Ranges ...................... 10-11
Display Resolution & Troubleshooting Settings ..................... 12
Milliamp Display for RTD, Thermocouple, V & Ohms ........... 13
FEATURE Menu - Stepping & Ramping / Auto Off ............... 14
FEATURE Menu - Stepping & Ramping / Backlight ............. 15
Functions and Hookup Diagrams
Millivolt
Source mV; Read mV ...................................................... 16,17
Thermocouple
Source T/C & Read T/C Sensors ..................................... 18,19
Resistance
Source Resistance, Read Resistance............................. 20, 21
RTD
Source RTD & Read RTD Sensors................................. 22, 23
Troubleshooting
Troubleshooting RTD Instruments ........................................ 24
Troubleshooting Thermocouple Sensors ............................... 26
Troubleshooting RTD Sensors .............................................. 28
Milliamp
Source mA ............................................................................ 30
Read mA ............................................................................... 31
Power/Measure mA ............................................................... 32
Simulate 2-Wire Transmitters ................................................ 33
Calibrate 2-Wire Temperature Transmiters ............................ 34
Using Ground Leak Detection ............................................... 36
Specifications
General ............................................................................38-41
Thermocouple Ranges & Accuracies...............................42-44
RTD Ranges & Accuracies ..............................................46-47
Warranty
Warranty & Additional Information ........................................ 49
