Operating Instructions
Double Click Menus - MAIN Page
Double click the EZ-DIAL knob to access the Double Click
Menus. Shown are the MAIN menus for each function. Turn the
knob to scroll thru the menus and press the knob to select. Default
values are in black and available choices are shown in grey.
Source V
>EXIT
>EXIT (1/4)
FUNCTION V
RANGE 80mV
Source & Read Thermocouples
>EXIT (1/4 for SOURCE, 1/3 for READ)
FUNCTION T/C
UNITS °C °F
T/C TYPE J K E T R S B N L U G C D P
COLD JUNC ON OFF
Source Ohms
>EXIT (1/4)
FUNCTION OHMS
RANGE 400Ω 4000Ω
Source RTD
>EXIT (1/4)
FUNCTION RTD
UNITS °C °F
RTD Pt 100 a=3850 [*RTD Types - See Read RTD]
Read RTD
>EXIT (1/3)
FUNCTION RTD
UNITS °C °F
Pt 100 a=3850, Pt 200 a=3850, Pt 500 a=3850,
RTD
Pt 1000 a=3850, Pt 100 a=3902, Pt 100 a=3916,
Pt 100 a=3926, Cu 10 a=4274, Cu 50 a=4280, Ni 120 a=6720
Pt 10 a=3850, Pt 50 a=3850
Page 10
GlobalTestSupply
www.
Read V
(1/3)
FUNCTION V
RANGE 80mV
Read Ohms
>EXIT (1/3)
FUNCTION OHMS
RANGE 400Ω 4000Ω
