Operation with Accessories:

The PTT Foot Switch allows hands free operation,
and overrides VOX if the Environment becomes noisy
If the Operator has a Push-to-Talk Foot Switch (Optional)
PTT disables VOX mode
When the Foot Switch is pressed the Console Microphone is immediately activated
When the Foot Switch is Released the Console returns to Listening
The Wireless Headset allows the Operator to move about the room,
while carrying on a conversation with the Procedure Room
If the Operator has a Wireless Headset (Optional)
The Wireless Headset has a an ON/OFF switch, when the Headset is 'Off' the function is the same as
above
The Headset has priority, and converses with the Procedure Room when the
"HEADSET ON" indicator is lighted Red;
The Console Microphone, Speaker, and Switches, are disabled
The Listen and Talk indicators are forced off

Configuration:

Jumper:
Operation
P2 Mic. Enable
P3 Talk Sw
Other Combinations are allowed and give special functionality where required like VOX with PTT
or PTT with TOGGLing Button.
Cleaning – If the product becomes dirty and requires cleaning DO NOT USE CLEANING CHEMICALS SUCH
AS 409, SIMPLE GREEN, or other solvents. If possible only use water to make a damp soft cloth and rub
lightly to preserve the finish. If further cleaning or disinfecting is required, use only isopropyl alcohol on
a soft cloth. Alcohol may dull the finish of the product but will not harm the electronics.
As Shipped Jumpers to the Right
HANDS FREE OPERATION
VOX
TOGGLE
Move both Jumpers to the Left
PTT OPERATION
PTT
PTT
