GET STARTED! TACTIC TTX300 Transmitter ARRMA 4x4 BLX Vehicle REQUIRED: 4x AA Batteries Battery Charger NO TIME TO READ? CHECK OUT THE QUICK START VIDEO INSTEAD:...
Page 3
Folgen Sie hierzu grundsätzlich den Warnhinweisen und Anleitungen der Hersteller Der Käufer übernimmt sämtliche Risiken im Zusammenhang mit der Benutzung des Gerätes. ARRMA, die mit ihr verbundenen Benutzen Sie ausschliesslich schwer entflammbare LiPo Unternehmen, Hersteller, Händler und Handelspartner können Ladetaschen/-Boxen und einen speziell entwickeltes Ladegerät...
Contents Quick Start Guide How to Drive Electronic Speed Controller (ESC) Radio Gear Troubleshooting Inhalt Schnellstartanleitung Wie man fährt Fahrtregler Fernsteuer Fehlerbehebung Contenu Guide de Démarrage Rapide Comment conduire Variateur électronique Ensemble radio Dépannage...
Electronic Speed Controller (ESC) Only use fully charged LiPo batteries (4.2V per cell) to prevent battery/ESC damage. EC5 Battery Plug HEAT-SINK MAY BE HOT AFTER USE Motor wires x 3 Receiver Plug (CH2) Power Switch & Set button ESC Specifications Input Voltage BEC Output 6.0v/6A Max 2S-3S LiPo (7.4-11.1v)
Page 12
ESC Tuning Options The ARRMA BLX brushless ESC is setup for use straight from the factory, if you want to alter the settings for your track or driving style please see the table and steps below: Variable Setting >...
Radio Gear TACTIC TTX300 2.4Ghz Power switch Steer wheel (CH1) Trim and Dual-rate dials TACJ0300 Power LED End Point CH1/CH2 Reverse Throttle trigger Buttons Switches (CH2) Battery compartment BAT socket Steering (CH1) socket Status LED Bind button Throttle socket (CH2) CH3 socket TACL0326 Steering trim...
Page 15
THORISED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. arrma-rc.com/ce Industry Canada Notice This device complies with Industry Canada license-exempt RSS standard(s). 1. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Page 17
ARRMA-RC.com for advice steering input Clean, check condition and/or replace Drivetrain dirty or damaged - visit ARRMA-RC.com for more information Reverse relevant channel on TACTIC Relevant channel of TACTIC transmitter is reversed transmitter - see model/ transmitter manual...
Page 21
ESC Verbindung und Strom anschalten Fernsteuerung als erstes einschalten Fahrzeug als zweites einschalten Karosserie befestigen Nun kann es losgehen!
Fahrtregler Benutzen Sie nur vollständig geladene LiPo-Akkus (4,2V pro lten Zelle), um Schäden am Akku/Regler zu vermeiden. Akkustecker DER KÜHLKÖRP- ER KANN NACH DER FAHRT HEISS SEIN Motorkabel x 3 Empfängerkabel (CH2) Ein/Aus-Schalter & Set- Knopf Reglerspezifikationen Eingangsspan- BEC Ausgang 6.0v/6A Max 2S-3S LiPo (7.4-11.1v) 35C 5000mAh Minimum...
Page 24
Übertemperatur-Schutzmodus und die rote LED wird blinken. Nachdem die Temperatur des Reglers auf ein normales Maß gesunken ist, wird er wieder normal funktionieren. Reglerabstimmung Der ARRMA BLX Brushless-Regler ist werkseingestellt, kann aber individuell auf die eigenen Bedürfnisse abgestimmt werden. Wie genau, das erfahren Sie weiter unten: Variable Setting >...
Page 27
THORISED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. arrma-rc.com/ce Industry Canada Notice This device complies with Industry Canada license-exempt RSS standard(s). 1. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Page 29
Servokabel zur Einheit sind lose oder inkorrekt verbunden Einheit erneut Reichweite Das Funkgerät und Empfänger müssen ARRMA Funkfernsteuerung und Einheit sind nicht korrekt korrekt miteinander verbunden sein – miteinander verbunden siehe Bedienungsanleitung Halten Sie das Fahrzeug an und geben Einheit wurde aufgrund Überhitzung ausgeschaltet...
Page 33
Connecter à l’ESC et allumer Radiocommande en premier Voiture en second Installer la carrosserie de la voiture Maintenant, commencez à vous amuser !
Variateur électronique Utilisez uniquement des batteries LiPo chargée complètement (4.2V par cellule) pour éviter des dommages à la batterie et à l’ESC (Contrôleur Electronique de Vitesse). EC5 Connecteur de batterie LE RADIATEUR PEUT ÊTRE CHAUD APRÈS UNE UTILISATION Câbles moteur x3 Câble de récepteur (CH2) Bouton de réglage et interrupteur Spécifications du variateur électronique...
Page 36
Réglage du variateur électronique Le variateur électronique brushless ARRMA BLX est réglé d’usine afin d’être utilisé de suite, si vous souhaitez ajuster les réglages pour votre circuit ou à votre style de pilotage, veuillez suivre le tableau et les étapes ci-dessous :cambio para adaptarlo a tu circuito o estilo de pilotaje comprueba la tabla y los pasos que...
Ensemble radio TACTIC TTX300 2.4Ghz Interrupteur d’allumage Volant de direction (CH1) TRIM et Dual-rate TACJ0300 d’allumage Bouton fin de Commutateurs Manette (CH2) course d’inversion CH1 / accélérateur Compartiment Batterie Socket BAT Socket direction (CH1) LED Statu Bouton de liaison Socket accélérateur (CH2) CH3 socket TACL0326 Inversion de...
Page 39
THORISED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. arrma-rc.com/ce Industry Canada Notice This device complies with Industry Canada license-exempt RSS standard(s). 1. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Page 41
Les fils servo vers sont lâches ou mal connectés Réinstallez les fils de signal vers faible distance L’émetteur et le récepteur doivent L’émetteur ARRMA et l’unité ne sont pas «lié» cor- être liés - voir le manuel du modèle / rectement émetteur Arrêtez de conduire et laissez le ou le...
