Velleman K6600 Assembly Manual
Velleman K6600 Assembly Manual

Velleman K6600 Assembly Manual

Multi-tone chime

Advertisement

Quick Links

Total solder points: 74
Difficulty level: beginner 1
2
3
4
5
advanced
MULTI-TONE CHIME
K6600
ILLUSTRATED ASSEMBLY MANUAL
H6600IP-1

Advertisement

loading
Need help?

Need help?

Do you have a question about the K6600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Velleman K6600

  • Page 1 Total solder points: 74 Difficulty level: beginner 1 advanced MULTI-TONE CHIME K6600 ILLUSTRATED ASSEMBLY MANUAL H6600IP-1...
  • Page 2: Specifications

    Features & Specifications SPECIFICATIONS: For use in homechime, call systems, games or discobars. One, two or three tones triggered by 3 different push buttons. Adjustable tone and volume control. Peak output power: 0.3W (8 Ohm speaker). Power Supply: 6 to 9VAC/0.2A or 4.5V battery (3 x 1.5V). Standby current: less than 10µ...
  • Page 3: Assembly Hints

    Assembly hints 1. Assembly (Skipping this can lead to troubles ! ) Ok, so we have your attention. These hints will help you to make this project successful. Read them carefully. 1.1 Make sure you have the right tools: • A good quality soldering iron (25-40W) with a small tip.
  • Page 4 3- Trim excess leads as close as possible to the solder joint REMOVE THEM FROM THE TAPE ONE AT A TIME ! AXIAL COMPONENTS ARE TAPED IN THE CORRECT MOUNTING SEQUENCE ! You will find the color code for the resistances and the LEDs on our website: http://www.velleman.be/common/service.aspx...
  • Page 5 Construction 5. Capacitors. D5 : 1N4007 1. Resistors D6 : 1N4007 D7 : 1N4007 C... D8 : 1N4007 R... 3. Zenerdiode. Watch the polarity ! C1 : 4n7 (472) R1 : 10K (1 - 0 - 3 - B) ZD... C2 : 100nF (104) ZD1 : 6V2 R2 : 10K...
  • Page 6 Construction 9. Electrolytic Capacitors. 7. Transistors Watch the polarity ! T1 : BC337 or eq : 10µ F C... : 470µ F : 470µ F 8. PCB pins 10. IC mounting IC1 : SAE800 Pay attention to the position of the notch!
  • Page 7 Connection 11. Connection of battery as supply...
  • Page 8 Connection 12. Connection of transformer as supply...
  • Page 9 Connection 13. Connecting a transformer and backup battery supply...
  • Page 10 Schematic diagram 14. Schematic diagram.
  • Page 11 15. PCB...
  • Page 12 VELLEMAN Components NV Legen Heirweg 33 9890 Gavere Belgium Europe www.velleman.be www.velleman-kit.com Modifications and typographical errors reserved © Velleman Components nv. H6600IP - 2007 - ED1 5 4 1 0 3 2 9 2 8 9 4 8 5...
