Battery Warnings And Cautions - Human Design Medical Z1 CPAP System User Manual

• Do not leave long lengths of air tubing around the top of your bed . The tube could
twist around your head or neck while you are sleeping .
• Do not connect or insert any device, cable or articles into the Micro USB or Micro SD
ports of your Z1 except as described in this User Guide . Connecting other devices
could result in injury to you or damage to the Z1 and void the warranty .
• Do not locate your Z1 in an unapproved place or where the air intake can be blocked
during treatment . This will lead to overheating of the Z1 . If a blocked intake should
occur during operation, the unit may stop supplying pressurized air and cause a fault
condition . Refer to "Troubleshooting" in this User Guide to interpret this fault and
instructions for corrective action .
• The Z1 is designed to deliver pressures from 4 to 20 cm H
certain fault conditions, pressures of up to 30 cm H
• Blocking the CPAP Tube while in operation could lead to overheating of the Z1 .
• In the clinical environment, any personal computer that is used with your CPAP
system must be at least 5 feet (1 . 5 m) away from, or at least 8 feet (2 . 5 m) above, the
patient . It must also comply with the relevant test standard . For personal computers
the international standard is IEC 60950 or equivalent .
CAUTIONS:
• Be careful not to place your Z1 where it can be bumped or where someone is likely to
trip over the power cord .
• Make sure your Z1, Power Supply, PowerShell and Battery are kept clean, dry, and free
of dust .
• Always make sure the power cord and plugs are in good condition and the
equipment is not damaged before use .
• Make sure the area around your Z1 and accessories is dry and clean .
• During partial (below rated minimum voltage) or total power failure, therapy
pressures will not be delivered . When power is restored, your Z1 will enter standby
mode and all prior settings will be retained in memory .
• Follow the storage and cleaning instructions provided with your CPAP Tube and mask .
• The air filter should be changed at intervals specified in this User Guide .
Accumulation of filtered particles over time can reduce the efficiency and shorten the
life of any CPAP device, including the Z1 . Replacement filters are available at your retail
medical supplier or at www . h dmusa . c om .
• Do not wash the air filter . The air filter is not washable or reusable .
• The End Cap protects the Z1 in the event of a minor collision . Always ensure that the
End Cap is securely fitted in accordance with instructions at all times . The Z1 may not
operate if the End Cap is not properly installed .
• The temperature of the airflow for breathing produced by CPAP devices can be higher than
the temperature of the room . This is true of all CPAP devices . Caution should be exercised
when using your Z1 at room temperatures warmer than 90˚F (32˚C) .
6
O . In the unlikely event of
2
O are possible .
2
• Only operate the Z1 and accessories within the operating temperature, humidity and
altitude conditions specified in the Technical Specifications section of this User Guide .
• Only store or transport the Z1 and accessories within the storage and transport
temperature, humidity and altitude conditions specified in the Technical Specifications
section of this User Guide .
• Damage to the CPAP Tube may result in air leaks . If this occurs, stop using the damaged
CPAP Tube and replace immediately .

Battery Warnings and Cautions

The PowerShell comes with a removable Lithium Ion Battery . Careful attention must be paid to
the warnings and cautions described below relating to the Battery . Misusing the Battery may
cause the Battery to get hot, rupture, ignite and cause serious injury .
WARNINGS:
• Do not place the Battery in fire or heat the Battery .
• Do not install the Battery backwards so that the polarity is reversed .
• Do not connect the positive terminal and the negative terminal of the Battery to each other
with any metal object (such as wire) .
• Do not carry or store the Battery together with necklaces, hairpins, or other metal objects .
• Do not pierce the Battery with nails, strike the Battery with a hammer, step on the Battery or
otherwise subject it to strong impacts or shocks .
• Do not solder onto the Battery .
• Do not expose the Battery to water or salt water, or allow the Battery to get wet .
• Do not disassemble or modify the Battery . The Battery contains safety and protection
devices which, if damaged, may cause the Battery to generate heat, rupture or ignite .
• Do not place the Battery on or near fires, stoves or other high-temperature locations . Do not
place the Battery in direct sunlight, or use or store the Battery inside cars in hot weather .
Doing so may cause the Battery to generate heat, rupture or ignite . Using the Battery in this
manner may also result in a loss of performance and a shortened life expectancy .
• Immediately discontinue use of the Battery if, while using, charging or storing the Battery,
the Battery emits an unusual smell, feels hot, changes color, changes shape or appears
abnormal in any other way . Contact the Human Design Medical Service Center at 1-855-
436-8724 if any of these problems are observed .
• Do not place the Battery in microwave ovens, high-pressure containers, or on induction
cookware .
• In the event that the Battery leaks and the fluid gets into one's eye, do not rub the eye . Rinse
well with water and immediately seek medical care . If left untreated the battery fluid could
cause damage to the eye .
• Only charge the Battery with the supplied Human Design Medical PowerShell and the
supplied Human Design Medical Power Supply . Do not use any other removeable battery
charger, AC adapter, or other device to charge the Battery .
7
