ADN-4100
VERIFY THE CONTENTS INSIDE PACKAGE BOX
The package should contain the items plus ADN-4100. If any item is missing or damaged, please contact the seller immediately
Quick Installation Guide
CD-ROM
Splitter
Ethernet Cable
Phone Cable
Power Adapter
STEP 1 : Connect telephone line to the LINE port via splitter
Telephone Line
Telephone
MODEM
PHONE
Splitter
LINE
Phone
Jack
Telephone Line
STEP 2 : Connect network devices to LAN port
Telephone Line
Telephone
MODEM
PHONE
Ethernet Cable
Splitter
LINE
Phone
PC
Jack
(DHCP Client or Fixed 192.168.1.2)
Telephone Line
Quick Guide
