Summary of Contents for Planet ADE-3400

  • Page 1 ADSL 2/2+ Router ADE-3400, ADE-4400 User’s Manual...
  • Page 2 PLANET Technology. Disclaimer PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for a particular purpose.

  • Page 3: Fcc Compliance Statement

    April 8, 2000. Trademarks The PLANET logo is a trademark of PLANET Technology. This documentation may refer to numerous hardware and software products by their trade names. In most, if not all cases, these designations are claimed as trademarks or registered trademarks by their respective companies.
  • Page 4 / surge protector) front of this ADSL router. Improper installation like without this protection and cause the equipment damaged could void the warranty. Revision User’s Manual for PLANET ADSL 2/2+ Router Model: ADE-3400, ADE-4400 Rev: 1.0 (Jun. 2005) Part No. EM-ADE4400v2...

  • Page 5: Table Of Contents

    Chapter 1 Introduction ... 7 1.1 Introducing the ADE-3400/4400... 7 1.2 Features of the ADE-3400/4400 ... 7 1.3 Applications for the ADE-3400/4400 ... 10 Chapter 2 Product Information 2.1 Package Contents... 11 2.2 The Top LEDs ... 11 2.3 The Rear Ports... 13 2.4 Cabling ...
  • Page 6 4.2.3 WAN Setup... 35 4.2.4 NAT ... 37 4.2.4.1 Selecting the NAT Mode ... 38 4.2.4.2 Configuring Edit Port Mapping ... 38 4.2.4.3 Configuring Address Mapping... 39 4.2.4.4 Editing an Address Mapping Rule... 41 4.2.5 Security... 42 4.2.6 Dynamic DNS ... 42 4.2.7 Time Zone ...

  • Page 7: Chapter 1 Introduction

    PCs/laptops on your network connected to the Internet over your ADSL or more ADSL 2+ high speed broadband connection. ADE-3400 is a single port ADSL 2/2+ modem router and ADE-4400 is an ADSL 2/2+ router with 4-port 10/100Mbps Ethernet switch.
  • Page 8 It supports downstream rates of up to 24 Mbps and upstream rates of up to 1 Mbps. It is compliant with Multi-Mode standard (ANSI T1.413, Issue 2; G.dmt (G.992.1); G.lite (G992.2), G.hs (G994.1), G.dmt.bis (G.992.3), G.dmt.bisplus (G.992.5). Fast Ethernet Switch (ADE-4400) A 10/100Mbps fast Ethernet switch is built in with automatic switching between MDI and MDI-X for 10Base-T and 100Base-TX ports.
  • Page 9 conversion request packet from the PC to this router will be forwarded to the real DNS in the outside network. Dynamic Domain Name System (DDNS) The Dynamic DNS service allows you to alias a dynamic IP address to a static hostname. This dynamic IP address is the WAN IP address. PPP over Ethernet (PPPoE) Provides embedded PPPoE client function to establish a connection.

  • Page 10: Applications For The Ade-3400/4400

    1.3 Applications for the ADE-3400/4400...

  • Page 11: Chapter 2 Product Information

    Chapter 2 Product Information 2.1 Package Contents ADE-3400/4400 ADSL 2/2+ Router CD-ROM containing the online manual Quick Installation Guide RJ-11 cable RJ-45 cable Power adapter (ADE-3400: 9V AC, 1A) / (ADE-4400: 12V DC, 1A) 2.2 The Top LEDs ADE-3400...

  • Page 12: Led Indicator

    ADE-4400 LED Indicator Meaning PPP : Lit steady when there is a PPPoA / PPPoE connection. Lit when successfully connected to an ADSL DSLAM ADSL: (“linesync”). Lit when connected to an Ethernet device. Green for LAN (1-4 100Mbps; Orange for 10Mbps. Blinking when data is ADE-4400): Transmitted / Received.

  • Page 13: The Rear Ports

    2.3 The Rear Ports ADE-3400 ADE-4400 Rear panel Port and Button Definition Port 9V AC: ADE-3400 Connect the supplied power adapter to this jack. 12V DC: ADE-4400 After the device is powered on, press it to reset the device or restore to factory default settings.

  • Page 14: Cabling

    2.4 Cabling One of the most common causes of problems is bad cabling or ADSL line(s). Make sure that all connected devices are turned on. On the top of the product is a bank of LEDs. Verify that the LAN Link and ADSL line LEDs are lit. If they are not, verify that you are using the proper cables.

  • Page 15: Chapter 3 Installation

    Chapter 3 Installation The router can be configured with your web browser. A web browser is included as a standard application in the following operating systems: Windows 98/Me/NT /2000/XP, etc. The product provides a very easy and user-friendly interface for configuration.
  • Page 16 double-click on Network Connections 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window, click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties. 5. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons.
  • Page 17 Configuring PC in Windows 2000 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window click Properties.
  • Page 18 4. Select Internet Protocol (TCP/IP) and click Properties. 5. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons. 6. Click OK to finish the configuration. Configuring PC in Windows 98/Me 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab.
  • Page 19 3. Select the Obtain an IP address automatically radio button. 4. Then select the DNS Configuration tab. 5. Select the Disable DNS radio button and click OK to finish the configuration.
  • Page 20 Configuring PC in Windows NT4.0 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties. 3. Select the Obtain an IP address from a DHCP server radio button and click...

  • Page 21: Factory Default Settings

    3.2 Factory Default Settings Before configuring your ADSL router, you need to know the following default settings. Web Interface: User name: admin Password: admin LAN Device IP Settings: IP Address: 192.168.1.254 Subnet Mask: 255.255.255.0 ISP setting in WAN site: PPPoE DHCP server: DHCP server is enabled.

  • Page 22: Lan And Wan Port Addresses

    3.3 LAN and WAN Port Addresses The parameters of LAN and WAN ports are pre-set in the factory. The default values are shown below. 3.4 Information from your ISP Before configuring this device, you have to check with your ISP (Internet Service Provider) what kind of service is provided such as PPPoE, PPPoA, RFC1483, or IPoA.

  • Page 23: Configuring With Your Web Browser

    3.5 Configuring with your Web Browser Open your web browser, enter the IP address of your router, which by default is 192.168.1.254, and click “Go”, a user name and password window prompt will appear. The default user name and password are “admin” and “admin”.

  • Page 24: Chapter 4 Configuration

    Chapter 4 Configuration At the configuration homepage, the left navigation pane where bookmarks are provided links you directly to the desired setup page, including: Wizard Setup (wizard setup) Advanced Setup (Password, LAN, WAN, Wireless, NAT, Security, Dynamic DNS, Time Zone, Remote Management Control, UPnP) Static Route（Current Route）...

  • Page 25: Pppoe

    Mode: Select Routing (default). If your ISP allows multiple computers to share an Internet account. Otherwise select Bridge. Encapsulation: Select the encapsulation type your ISP uses from the Encapsulation drop-down list box. Choose vary depending on what you select in the Mode field.
  • Page 26 Service Name: Type the name of your PPPoE service here. User Name: Enter the user name exactly as your ISP assigned. Password: Enter the password associated with the user name above. IP Address: Type your ISP assigned IP address in the IP Address text box below.

  • Page 27: 1483 Routed Ip

    from the drop-sown list box. Refer to the NAT chapter (4.2.4) for more details. 4.1.3 1483 Routed IP Select 1483 Router IP from the Encapsulation drop-down list box in the first wizard screen to display the screen as shown. IP Address: Type your ISP assigned IP address in the IP Address text box below.

  • Page 28: Pppoa

    IP Address: Type your ISP assigned IP address in the IP Address text box below. Subnet Mask: Enter a subnet mask in dotted decimal notation. Gateway: You must specify a gateway IP address (supplied by your ISP) when you use 1483 Bridged IP in the Encapsulation field in the previous screen. Network Address Translation: Select None, Many to One or Many to Many from the drop-sown list box.
  • Page 29 User Name: Enter the user name exactly as your ISP assigned. Password: Enter the password associated with the user name above. IP Address: Type your ISP assigned IP address in the IP Address text box below. Connection: Select Connect on Demand when you don't want the connection up all the time and specify an idle time-out (in seconds) in the Max.

  • Page 30: Wizard Setup Configuration

    4.1.6 Wizard Setup Configuration If you want to change your ADE-3400/4400 LAN settings, click Change LAN Configuration to display the screen as shown next.
  • Page 31 LAN IP Address: Enter the IP address of ADE-3400/4400 in dotted decimal notation, for example, 192.168.1.254 (factory default). LAN Subnet Mask Enter a subnet mask in dotted decimal notation. DHCP Server: From the DHCP Server drop-down list box, select On to allow ADSL Router to assign IP addresses, an IP default gateway and DNS servers to computer systems that support the DHCP client.

  • Page 32: Advanced Setup

    4.2 Advanced setup 4.2.1 Password In factory setting, the default password is admin. You can change the default password to ensure that someone cannot adjust your settings without your permission. Every time you change your password, please record the password and keep it at a safe place.

  • Page 33: Lan

    Old Password: Type the default password or the existing password you use to access the system in this field. New Password: Type the new password in this field Retype to confirm: Type the new password again in this field. 4.2.2 LAN Click LAN to open the following screen.
  • Page 34 DHCP client. If set to None, the DHCP server will be disabled. If set to Relay, the ADE-3400/4400 acts as a surrogate DHCP server and relays DHCP requests and responses between the remote server and the clients. Enter the IP address of the actual, remote DHCP server in the Remote DHCP Server field in this case.

  • Page 35: Wan Setup

    4.2.3 WAN Setup A WAN (Wide Area Network) is an outside connection to another network or the Internet. It allows the user to set the configuration for the WAN/ADSL ports. To change ADE-3400/4400 WAN remote node settings, click WAN.
  • Page 36 Half Bridge Name: Enter the name of your Internet Service Provider Mode: Select Routing (default) or Bridge Encapsulation: Select Bridge in the Mode field and select either PPPoA or RFC 1483. Select Routing in the Mode field and select PPPoA, RFC 1483, ENET ENCAP, or PPPoE.

  • Page 37: Nat

    Virtual Circuit ID: VPI and VCI define a virtual circuit. VPI: The valid range for the VPI is 0 to 255 VCI: The valid range for the VCI is 32 to 65535 ATM QoS Type: Select CBR to specify fixed (always-on) bandwidth for voice or data traffic.

  • Page 38: Selecting The Nat Mode

    multiple WAN connections. The LAN traffic is routed to appropriate WAN connections based on the destination IP addresses and Route Table. This eliminates the need for the static NAT session configuration between multiple LAN clients and multiple WAN connections. 4.2.4.1 Selecting the NAT Mode None: Select this radio button to disable NAT Many to One: Select this radio button if you have just one public WAN IP address for your router.

  • Page 39: Configuring Address Mapping

    End Port No.: Enter a port number in this field. IP Address: Enter your server IP address in this field. 4.2.4.3 Configuring Address Mapping To change your ADE-3400/4400 address mapping settings, click NAT, Select Many to Many and click Edit Details to open the following screen.
  • Page 40 Local Start IP: This is the starting Inside Local IP Address. Local IP addresses are N/A for Server port mapping. Local End IP: This is the end Inside Local IP Address (ILA). If your rule is for all local IP addresses, then enter 0.0.0.0 as the Local Start IP address and 255.255.255.255 as the Local End IP address.

  • Page 41: Editing An Address Mapping Rule

    the NAT to be accessible to the outside world. 4.2.4.4 Editing an Address Mapping Rule To edit an address mapping rule, click the rule’s link in the NAT Address Mapping Rules screen to display the screen shown next. Type: 1-1: One-to-one mode maps one local IP address to one global IP address. Note that port numbers do not change for the One-to-one NAT mapping type.

  • Page 42: Security

    Global Start IP: This is the starting Inside Global IP Address (IGA). Enter 0.0.0.0 here if you have a dynamic IP address from your ISP. Global End IP: This is the ending Inside Global IP Address (IGA). This field is N/A for One-to-one, Many-to-One and Server mapping types.

  • Page 43: Time Zone

    Active: Select this check box to use dynamic DNS. Service Provider: Select the name of your Dynamic DNS service provider. Host Name: Type the domain name assigned to your Planet ADE-3400/4400 by your Dynamic DNS provider. E-mail Address: Type your e-mail address.
  • Page 44 Network Time Protocol (SNTP) to get the current time from an SNTP server outside your network. Choose your local time zone. After a successful connection to the Internet, the router will retrieve the correct local time from the SNTP server you have specified.
  • Page 45 Router use the time server (that you configured above) to set its internal system clock. Please wait for up to 60 seconds while the ADE-3400/4400 locates the time server. If the ADE-3400/4400 cannot find the time server, please check the time server protocol and its IP address.

  • Page 46: Remote Management

    Secured Client IP: The default 0.0.0.0 allows any client to use this service to remotely manage the ADE-3400/4400. Type an IP address to restrict access to a client with a matching IP address.
  • Page 47 Allow users to make configuration changes through UPnP: Select this check box to allow UPnP-enabled applications to automatically configure the ADE-3400/4400 so that they can communicate through the ADE-3400/4400. For example by using NAT traversal, UPnP applications automatically reserve a NAT forwarding port in order to communicate with another UPnP enabled device.
  • Page 48 Step 3. In the Communications window, select the Universal Plug and Play check box in the Components selection box. Step 4. Click OK to go back to the Add/Remove Programs Properties window and click Next. Step 5. Restart the computer when prompted. Follow the steps below to install the UPnP in Windows XP.
  • Page 49 and select Optional Networking Components …. The Windows Optional Networking Components Wizard window displays. Step 4. Select Networking Service in the Components selection box and click Details. Step 5. In the Networking Services window, select the Universal Plug and Play check box.
  • Page 50 Auto-discover Your UPnP-enabled Network Device Step 1. Click start and Control Panel. Double-click Network Connections. An icon displays under Internet Gateway. Step 2. Right-click the icon and select Properties. Step 3. In the Internet Connection Properties window, click Settings to see the port mappings there were automatically created.
  • Page 51 Step 4. You may edit or delete the port mappings or click Add to manually add port mappings. Step 5. Select Show icon in notification area when connected option and click OK. An icon displays in the system tray...
  • Page 52 Web Configurator Easy Access With UPnP, you can access the web-based configurator on the ADE-3400/4400 without finding out the IP address of the ADE-3400/4400 first. This is helpful if you do not know the IP address of the ADE-3400/4400. Follow the steps below to access the web configurator.
  • Page 53 Step 4. An icon with the description for each UPnP-enabled device displays under Local Network. Step 5. Right-click on the icon for your ADE-3400/4400 and select Invoke. The web configurator login screen displays.

  • Page 54: Static Route

    Step 6. Right-click on the icon for your ADE-3400/4400 and select Properties. A properties window displays with basic information about the ADE-3400/4400. 4.3 Static Route 4.3.1 Current Route If you have another router with a LAN-to-LAN connection, you may create a static routing on the router that is the gateway to Internet.

  • Page 55: Maintenance

    RIP broadcasts. Set “Yes”, it keeps private and is not included in RIP broadcasts. Set “No”, the remote node will be propagated to other hosts through RIP broadcasts. 4.4 Maintenance Use the maintenance screens to view system information, upload new firmware, manage configuration and restart your ADE-3400/4400.

  • Page 56: System Status

    4.4.1 System Status System Status: System Name: This is the name of the router. It is for identification purposes. RAS F/W Version: This is the firmware version and the date created. DSL FW Version: This is the DSL firmware version associated with your router. Standard: This is the standard that the router is using.

  • Page 57: System Statistics

    IP Address: This is the WAN port IP address IP Subnet Mask: This is the WAN port IP subnet mask. Default Gateway: This is the IP address of the default gateway VPI/VCI: This is the Virtual Path Identifier and Virtual Channel Identifier that you entered in the first Wizard screen.
  • Page 58 System up Time: This is the elapsed time the system has been up. CPU Load: This field specifies the percentage of CPU utilization. WAN Port Statistics: This is the WAN port. Link Status: This is the status of your WAN link. Transfer Rate: This is the transfer rate in kbps.

  • Page 59: Dhcp Table

    IP Address: This field displays the IP address relative to the Host Name field MAC Address: This field displays the MAC (Media Access Control) address of the computer with the displayed host name. 4.4.4 Diagnostic These read-only screens display information to help you identify problems with the ADE-3400/4400.

  • Page 60: Diagnostic-General

    Ping: Click this button to ping the IP address that you entered. Reset System: Click this button to reboot the ADE-3400/4400. A warning dialog box is displayed and asking you if you're sure you want to reboot the system.

  • Page 61: Firmware

    Your router’s firmware is the software that allows it to operate and provide all its functionality. Over time this software may be improved and modified, and your router allows you to upgrade the software. It runs to take advantage of these changes. To upgrade the firmware of ADE-3400/4400, you should download or...
  • Page 62 Reset: Click this button to clear all user-entered configuration information and return the ADE-3400/4400 to its factory defaults. Refer to the Resetting the ADE-3400/4400 section. After two minutes, log in again and check your new firmware version in the System Status screen. If the upload was not successful,...

  • Page 63: Restart

    4.4.6 Restart Click Restart with option Current Settings to reboot your router (and restore your last saved configuration). If you wish to restart the router using the factory default settings (for example, after a firmware upgrade or if you have saved an incorrect configuration), select Factory Default Settings to reset to factory default settings.

  • Page 64: Logout

    4.5 Logout To exit the router’s web interface, choose Logout. Please ensure that you have saved the configuration settings before you logout. Be aware that the router is restricted to only one PC accessing the configuration web pages at a time. Once a PC has logged into the web interface, other PCs cannot get access until the current PC has logged out of the web interface.

  • Page 65: Chapter 5 Troubleshooting

    Chapter 5 Troubleshooting If the ADSL Router is not functioning properly, you can refer first to this chapter for simple troubleshooting before contacting your service provider. This could save your time and effort but if the symptoms persist, then consult your service provider.
