ADSL 2/2+
VPN Firewall Router
ADE-4300A/B, ADW-4300A/B
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADE-4300A/B and is the answer not in the manual?

Questions and answers

Related Manuals for Planet ADE-4300A/B

Summary of Contents for Planet ADE-4300A/B

  • Page 1 ADSL 2/2+ VPN Firewall Router ADE-4300A/B, ADW-4300A/B User's Manual...

  • Page 2: Federal Communication Commission Interference Statement

    Copyright Copyright© 2005 by PLANET Technology Corp. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of PLANET.
  • Page 3 Revision User’s Manual for PLANET ADSL 2/2+ VPN Firewall Router, 802.11g Wireless PLANET ADSL 2/2+ VPN Firewall Router Model: ADE-4300A/B, ADW-4300A/B Rev: 1.0 (Jan. 2005) Part No. EM-ADE4300_ADW4300v4...

  • Page 4: Table Of Contents

    Table of Contents CHAPTER 1 INTRODUCTION..................1 ADE-4300/ADW-4300 Features................1 Package Contents ....................5 Physical Details ....................6 CHAPTER 2 INSTALLATION ..................8 Requirements......................8 Procedure ......................8 CHAPTER 3 SETUP ....................10 Overview......................10 Configuration Program ..................12 Setup Wizard ....................... 13 Home Screen.......................
  • Page 5 Diagnostics ....................... 109 Remote Administration ..................110 Routing ......................112 Upgrade Firmware .................... 116 CHAPTER 8 MODEM MODE..................117 Overview......................117 Management Connections................117 Home Screen..................... 118 Mode Screen ..................... 119 Operation......................119 Status Screen....................120 APPENDIX A TROUBLESHOOTING ............... 122 Overview......................

  • Page 6: Chapter 1 Introduction

    Chapter 1 Introduction This Chapter provides an overview of the ADE-4300/ADW-4300's fea- tures and capabilities. Congratulations on the purchase of your new ADE-4300/ADW-4300. The ADE- 4300/ADW-4300 is a multi-function device providing the following services: • ADSL 2/2+ Modem • Shared Broadband Internet Access for all LAN users.

  • Page 7: Advanced Internet Functions

    ADE-4300/ADW-4300 User Guide • IPoA, PPPoE, PPPoA, Direct Connection Support. The ADE-4300/ADW- 4300 supports all common connection methods. • Auto-detection of Internet Connection Method. In most situations, the ADE-4300/ADW-4300 can test your ADSL and Internet connection to determine the connection method used by your ISP. •...

  • Page 8: Lan Features

    Introduction • Supports both 802.11b and 802.11g Wireless Stations. The 802.11g standard provides for backward compatibility with the 802.11b standard, so both 802.11b and 802.11g Wireless stations can be used simultaneously. • Speeds to 54Mbps. All speeds up to the 802.11g maximum of 54Mbps are supported.
  • Page 9 ADE-4300/ADW-4300 User Guide • Firewall. All incoming data packets are monitored and all incoming server requests are filtered, thus protecting your network from malicious attacks from ex- ternal sources. • Protection against DoS attacks. DoS (Denial of Service) attacks can flood your Internet connection with invalid packets and connection requests, using so much bandwidth and so many resources that Internet access becomes unavail- able.

  • Page 10: Package Contents

    Introduction Package Contents The following items should be included. If any of these items are damaged or missing, please contact your dealer immediately. • The ADE-4300/ADW-4300 Unit • Quick Installation Guide • User’s Manual CD • Power Adapter • 1 RJ-45 Cable •...

  • Page 11: Physical Details

    ADE-4300/ADW-4300 User Guide Physical Details Front-mounted LEDs of ADE-4300 Figure 2: Front Panel of ADE-4300 Front-mounted LEDs of ADW-4300 Figure 3: Front Panel of ADW-4300 PWR LED On - Power on. Off - No power. STATUS Off - Normal operation. Blinking - This LED blinks during start up, and during a Firmware Upgrade.

  • Page 12: Rear Panel

    Introduction Rear Panel Figure 4: Rear Panel of ADE-4300 Figure 5: Rear Panel of ADW-4300 This button will reset the ADE-4300/ADW-4300 to the factory RESET Button default settings. (Reset to De- To do this, press and hold the Reset Button for five (5) sec- faults) onds, until the Status LED is lit, then release the Reset Button, and wait the ADE-4300/ADW-4300 to restart using the factory...

  • Page 13: Chapter 2 Installation

    Chapter 2 Installation This Chapter covers the physical installation of the ADE-4300/ADW- 4300. Requirements • Network cables. Use standard 10/100BaseT network (UTP) cables with RJ45 connectors. • TCP/IP protocol must be installed on all PCs. • For Internet Access, an Internet Access account with an ISP, and a DSL connec- tion.
  • Page 14 Installation 2. Connect LAN Cables Use standard LAN cables to connect PCs to the Switching Hub ports on the ADE- 4300/ADW-4300. Both 10BaseT and 100BaseT connections can be used simulta- neously. If required, connect any port to a normal port on another Hub, using a standard LAN cable.

  • Page 15: Chapter 3 Setup

    Chapter 3 Setup This Chapter provides Setup details of the ADE-4300/ADW-4300. Overview This chapter describes the setup procedure for: • Internet Access • LAN configuration • Wireless setup (ADW-4300 only) • Assigning a Password to protect the configuration data. PCs on your local LAN may also require configuration. For details, see Chapter 4 - PC Configuration.
  • Page 16 Setup Use any of the following Administration Configuration Chapter 7 settings or features: Advanced Administration • PC Database • Config File • Logging • E-mail • Diagnostics • Remote Admin • Routing • Upgrade Firmware...

  • Page 17: Configuration Program

    ADE-4300/ADW-4300 User Guide Configuration Program The ADE-4300/ADW-4300 contains an HTTP server. This enables you to connect to it, and configure it, using your Web Browser. Your Browser must support JavaScript. The configuration program has been tested on the following browsers: •...

  • Page 18: Setup Wizard

    Setup If you can't connect If the ADE-4300/ADW-4300 does not respond, check the following: • The ADE-4300/ADW-4300 is properly installed, LAN connection is OK, and it is powered ON. You can test the connection by using the "Ping" command: • Open the MS-DOS window or command prompt window.

  • Page 19: Common Connection Types

    ADE-4300/ADW-4300 User Guide Common Connection Types Type Details ISP Data required Dynamic Your IP Address is allocated a) ADSL parameters (VPI and IP Address automatically, when you con- VCI) may be required, if they nect to you ISP. cannot be detected automati- cally.

  • Page 20: Home Screen

    Setup Home Screen After finishing the Setup Wizard, you will see the Home screen. When you connect in future, you will see this screen when you connect. An example screen is shown below. Figure 7: Home Screen Main Menu The main menu, on the left, contains links to the most-commonly used screen. To see the links to the other available screens, click "Advanced"...

  • Page 21: Lan Screen

    ADE-4300/ADW-4300 User Guide LAN Screen Use the LAN link on the main menu to reach the LAN screen. An example screen is shown below. Figure 8: LAN Screen Data - LAN Screen TCP/IP IP Address IP address for the ADE-4300/ADW-4300, as seen from the local LAN.

  • Page 22: Using Another Dhcp Server

    Setup • The DHCP Server provides the Gateway and DNS addresses to the client, as well as allocating an IP Address. • The ADE-4300/ADW-4300 can act as a DHCP server. • Windows 95/98/ME and other non-Server versions of Windows will act as a DHCP client.

  • Page 23: Wireless Screen (Adw-4300 Only)

    ADE-4300/ADW-4300 User Guide Wireless Screen (ADW-4300 only) The ADW-4300's settings must match the other Wireless stations. Note that the ADW-4300 will automatically accept both 802.11b and 802.11g connec- tions, and no configuration is required for this feature. To change the ADW-4300's default settings for the Wireless Access Point feature, use the Wireless link on the main menu to reach the Wireless screen.
  • Page 24 Setup Options Mode Select the desired mode: • 802.11G-plus (TI) This allows clients to use any of the following modes: • Standard 802.11b • 802.11B+ (Texas Instruments proprietary enhanced mode) • Standard 802.11g • 802.11G-plus (Texas Instruments proprietary enhanced mode). This mode can increase throughput by up to 50%, but will only work between compatible TI wireless stations.
  • Page 25 ADE-4300/ADW-4300 User Guide Use this feature to determine which Wireless stations can use Allow access the Access Point. The options are: by … • All Wireless Stations - All wireless stations can use the access point, provided they have the correct SSID and secu- rity settings.

  • Page 26: Wireless Security (Adw-4300 Only)

    Setup Wireless Security (ADW-4300 only) This screen is accessed by clicking the "Configure" button on the Wireless screen. There are 3 options for Wireless security: • Disabled - no data encryption is used. • WEP - data is encrypted using the WEP standard. •...
  • Page 27 ADE-4300/ADW-4300 User Guide You must enter a Key Value for the Default Key. Key Value Enter the key value or values you wish to use. The Default Key is required, the other keys are optional. Other stations must have the same key. Passphrase If desired, you can generate a key from a phrase, instead of entering the key value directly.

  • Page 28: Trusted Wireless Stations (Adw-4300 Only)

    Setup Trusted Wireless Stations (ADW-4300 only) This feature can be used to prevent unknown Wireless stations from using the Access Point. This list has no effect unless the setting Allow access by trusted stations only is enabled. To change the list of trusted wireless stations, use the Modify List button on the Ac- cess Control screen.
  • Page 29 ADE-4300/ADW-4300 User Guide Use this to change an existing entry in the "Trusted Stations" Edit list: 1. Select the Station in the Trusted Station list. 2. Click the Edit button. The address will be copied to the "Address" field, and the Add button will change to Up- date.

  • Page 30: Password Screen

    Setup Password Screen The password screen allows you to assign a password to the ADE-4300/ADW-4300. Figure 13: Password Screen Old Password Enter the existing password in this field. Enter the new password here. New password Re-enter the new password here. Verify pass- word You will be prompted for the password when you connect, as shown below.

  • Page 31: Mode Screen

    ADE-4300/ADW-4300 User Guide Mode Screen Use this screen to change the mode between Router mode and Modem (Bridge) mode. Figure 15: Mode Screen Select the desired option, and click "Save". Both the ADSL Modem and the Router features are operational. In Router this mode, this device can provide shared Internet Access to all your LAN users.

  • Page 32: Chapter 4 Pc Configuration

    Chapter 4 PC Configuration This Chapter details the PC Configuration required on the local ("Inter- nal") LAN. Overview For each PC, the following may need to be configured: • TCP/IP network settings • Internet Access configuration • Wireless configuration (ADW-4300 only) Windows Clients This section describes how to configure Windows clients for Internet access via the ADE-4300/ADW-4300.

  • Page 33: Using Dhcp

    ADE-4300/ADW-4300 User Guide Checking TCP/IP Settings - Windows 9x/ME: 5. Select Control Panel - Network. You should see a screen like the following: Figure 16: Network Configuration 6. Select the TCP/IP protocol for your network card. 7. Click on the Properties button. You should then see a screen like the following. Figure 17: IP Address (Win 95) Ensure your TCP/IP settings are correct, as follows: Using DHCP...
  • Page 34 PC Configuration • On the Gateway tab, enter the ADE-4300/ADW-4300's IP address in the New Gateway field and click Add, as shown below. Your LAN administrator can advise you of the IP Address they assigned to the ADE-4300/ADW-4300. Figure 18: Gateway Tab (Win 95/98) •...

  • Page 35: Checking Tcp/Ip Settings - Windows Nt

    ADE-4300/ADW-4300 User Guide Checking TCP/IP Settings - Windows NT4.0 1. Select Control Panel - Network, and, on the Protocols tab, select the TCP/IP protocol, as shown below. Figure 20: Windows NT4.0 - TCP/IP 2. Click the Properties button to see a screen like the one below.
  • Page 36 PC Configuration Figure 21: Windows NT4.0 - IP Address 3. Select the network card for your LAN. 4. Select the appropriate radio button - Obtain an IP address from a DHCP Server or Specify an IP Address, as explained below. Obtain an IP address from a DHCP Server This is the default Windows setting.
  • Page 37 ADE-4300/ADW-4300 User Guide Figure 22 - Windows NT4.0 - Add Gateway 2. The DNS should be set to the address provided by your ISP, as follows: • Click the DNS tab. • On the DNS screen, shown below, click the Add button (under DNS Service Search Order), and enter the DNS provided by your ISP.

  • Page 38: Checking Tcp/Ip Settings - Windows

    PC Configuration Checking TCP/IP Settings - Windows 2000: 1. Select Control Panel - Network and Dial-up Connection. 2. Right - click the Local Area Connection icon and select Properties. You should see a screen like the following: Figure 24: Network Configuration (Win 2000) 3.
  • Page 39 ADE-4300/ADW-4300 User Guide 5. Ensure your TCP/IP settings are correct, as described below. Using DHCP To use DHCP, select the radio button Obtain an IP Address automatically. This is the default Windows setting. Using this is recommended. By default, the ADE- 4300/ADW-4300 will act as a DHCP Server.

  • Page 40: Checking Tcp/Ip Settings - Windows Xp

    PC Configuration Checking TCP/IP Settings - Windows XP 1. Select Control Panel - Network Connection. 2. Right click the Local Area Connection and choose Properties. You should see a screen like the following: Figure 26: Network Configuration (Windows XP) 3. Select the TCP/IP protocol for your network card. 4.
  • Page 41 ADE-4300/ADW-4300 User Guide Figure 27: TCP/IP Properties (Windows XP) 5. Ensure your TCP/IP settings are correct. Using DHCP To use DHCP, select the radio button Obtain an IP Address automatically. This is the default Windows setting. Using this is recommended. By default, the ADE- 4300/ADW-4300 will act as a DHCP Server.

  • Page 42: Internet Access

    PC Configuration Internet Access To configure your PCs to use the ADE-4300/ADW-4300 for Internet access: • Ensure that the DSL modem, Cable modem, or other permanent connection is functional. • Use the following procedure to configure your Browser to access the Internet via the LAN, rather than by a Dial-up connection.

  • Page 43: Macintosh Clients

    ADE-4300/ADW-4300 User Guide Macintosh Clients From your Macintosh, you can access the Internet via the ADE-4300/ADW-4300. The procedure is as follows. 1. Open the TCP/IP Control Panel. 2. Select Ethernet from the Connect via pop-up menu. 3. Select Using DHCP Server from the Configure pop-up menu. The DHCP Client ID field can be left blank.

  • Page 44: Wireless Station Configuration (Adw-4300 Only)

    PC Configuration Wireless Station Configuration (ADW-4300 only) This section applies to all Wireless stations wishing to use the ADW-4300's Access Point, regardless of the operating system which is used on the client. To use the Wireless Access Point in the ADW-4300, each Wireless Station must have compatible settings, as follows: Mode The mode must be set to Infrastructure (rather than Ad-hoc)
  • Page 45 ADE-4300/ADW-4300 User Guide Figure 29 Wireless Networks (Windows XP) If the "Broadcast SSID" setting on the ADW-4300 has been disabled, its SSID will NOT be listed. See the following section "If the SSID is not listed" for details of dealing with this situation. 4.
  • Page 46 PC Configuration To connect: • Check the checkbox Allow me to connect to the selected wireless network, even though it is not secure. • The Connect button will then be available. Click the Connect button, and wait a few seconds for the connection to be established. If using WEP Data Encryption If WEP data encryption has been enabled on the ADW-4300, Windows will detect this, and show a screen like the following.
  • Page 47 ADE-4300/ADW-4300 User Guide Figure 32: Advanced - Wireless Networks Select the SSID for the ADW-4300, and click Configure, to see a screen like the following: Figure 33: Wireless Network Properties - WEP Configure this screen as follows: • Set Network Authentication to match theADW-4300. (If the setting on the ADW- 4300 is "Auto", then either Open or Shared can be used.) •...
  • Page 48 PC Configuration • For the Network key and Confirm network key, enter the default key value used on the ADW-4300. (Windows will determine if 64bit or 128bit encryption is used.) • The Key index must match the default key index on the ADW-4300. The default value is 1.
  • Page 49 ADE-4300/ADW-4300 User Guide If using WPA-PSK Data Encryption If WPA-PSK data encryption has been enabled on the ADW-4300, it does not matter which network is selected on the screen below. Just click the Advanced button. Figure 35: Wireless Networks (Windows XP) You will then see a screen like the example below.
  • Page 50 PC Configuration Figure 37: Wireless Network Properties- WPA-PSK Configure this screen as follows: • Set Network Authentication to WPA-PSK. • For Data Encryption, select TKIP. • For the Network key and Confirm network key, enter the network key (PSK) used on the ADW-4300.
  • Page 51 ADE-4300/ADW-4300 User Guide Figure 38: Preferred Networks Click OK to establish a connection to the ADW-4300. If the SSID is not listed If the "Broadcast SSID" setting on the ADW-4300 has been disabled, its SSID will NOT be listed on the screen below. Figure 39: Wireless Networks (Windows XP) In this situation, you need to obtain the SSID from your network administrator, then follow this procedure:...
  • Page 52 PC Configuration Figure 40: Unlisted Wireless Network 2. Click the Add button. You will see a screen like the example below. Figure 41: Add Wireless Network 3. Configure this screen as follows: • Enter the correct SSID, as used on the ADW-4300. Remember the SSID is case- sensitive, so be sure to match the case, not just the spelling.
  • Page 53 ADE-4300/ADW-4300 User Guide • If using data encryption (WEP or WPA-PSK), enter the key used on the ADW- 4300. See the preceding sections for details of WEP and WPA-PSK. • Uncheck the options The key is provided for me automatically and This is a com- puter-to-computer (ad hoc) network.

  • Page 54: Chapter 5 Operation And Status

    Chapter 5 Operation and Status This Chapter details the operation of the ADE-4300/ADW-4300 and the status screens. For Details of operation in Bridge (Modem) mode, see Chapter 8 - Modem Mode. Operation - Router Mode Once both the ADE-4300/ADW-4300 and the PCs are configured, operation is automatic.
  • Page 55 ADE-4300/ADW-4300 User Guide Figure 43: Status Screen Data - Status Screen ADSL This indicates the status of the ADSL modem component. Modem Status Displays the speed for the DownStream Connection. DownStream Connection Speed UpStream If connected, displays the speed for the Up Stream (upload) ADSL Connection.
  • Page 56 Operation and Status • Idle - No current connection, but no error has been detected. This condition normally arises when an idle connection is automatically terminated. • Failed - The connection was terminated abnormally. This could be caused by Modem failure, or the loss of the connection to the ISP's server.
  • Page 57 ADE-4300/ADW-4300 User Guide...

  • Page 58: Connection Status - Pppoe & Pppoa

    Operation and Status Connection Status - PPPoE & PPPoA If using PPPoE (PPP over Ethernet) or PPPoA (PPP over ATM), a screen like the following example will be displayed when the "Connection Details" button is clicked. Figure 44: PPPoE Status Screen Data - PPPoE/PPPoA Screen Connection Time This indicates how long the current connection has been...

  • Page 59: Connection Details - Dynamic Ip Address

    ADE-4300/ADW-4300 User Guide Connection Details - Dynamic IP Address If your access method is "Direct" (no login), with a Dynamic IP address, a screen like the following example will be displayed when the "Connection Details" button is clicked. Figure 45: Connection Details - Fixed/Dynamic IP Address Data - Dynamic IP address Internet The current IP Address of this device, as seen by Internet...
  • Page 60 Operation and Status...

  • Page 61: Connection Details - Fixed Ip Address

    ADE-4300/ADW-4300 User Guide Connection Details - Fixed IP Address If your access method is "Direct" (no login), with a fixed IP address, a screen like the following example will be displayed when the "Connection Details" button is clicked. Figure 46: Connection Details - Fixed/Dynamic IP Address Data - Fixed IP address Screen Internet The IP Address of this device, as seen by Internet users.

  • Page 62: Chapter 6 Advanced Features

    Chapter 6 Advanced Features This Chapter explains when and how to use the ADE-4300/ADW- 4300's "Advanced" Features. Overview The following advanced features are provided: • Access Control • Internet Access • Trusted PCs • Internet: • DMZ • Special Applications •...
  • Page 63 ADE-4300/ADW-4300 User Guide Figure 47: Access Control Screen Data - Access Control Screen Internet Access Select the desired options for Internet access control: Access control • Disable - Nothing is blocked. • Block all Internet access - All traffic via the WAN port is blocked.

  • Page 64: Internet

    Advanced Features Figure 48: Trusted PCs Data - Trusted PCs Trusted PCs Trusted PCs This lists any PCs which you have designated as “Trusted”. This list any PCs detected by the router, which you have not Other PCs designated as "Trusted". Buttons <<...

  • Page 65: Special Applications

    ADE-4300/ADW-4300 User Guide Figure 49: Internet Screen This feature, if enabled, allows the DMZ computer on your LAN to be exposed to all users on the Internet. • This allows almost any application to be used on the "DMZ PC". •...
  • Page 66 Advanced Features Figure 50: Special Applications Screen Data - Special Applications Screen Checkbox Use this to Enable or Disable this Special Application as required. Name Enter a descriptive name to identify this Special Application. • Type - Select the protocol (TCP or UDP) used when you receive Incoming data from the special application or service.

  • Page 67: Using A Special Application

    ADE-4300/ADW-4300 User Guide Using a Special Application • Configure the Special Applications screen as required. • On your PC, use the application normally. Remember that only one (1) PC can use each Special application at any time. Also, when 1 PC is finished using a par- ticular Special Application, there may need to be a "Time-out"...
  • Page 68 Advanced Features Note: It is necessary to click the Save button in the Access Control page for activation of Trusted PCs if you add/delete any entry of Trusted PCs page. Figure 51: URL Filter Screen Data - URL Filter Screen Current Filter Strings Current Filter The list contains the current list of items to block.

  • Page 69: Dynamic Dns (Domain Name Server)

    ADE-4300/ADW-4300 User Guide Dynamic DNS (Domain Name Server) This free service is very useful when combined with the Virtual Server feature. It allows Internet users to connect to your Virtual Servers using a URL, rather than an IP Address. This also solves the problem of having a dynamic IP address. With a dynamic IP address, your IP address may change whenever you connect, which makes it difficult to connect to you.
  • Page 70 Advanced Features DDNS Data Enter the domain name allocated to you by the DDNS Service. Host Name If you have more than one name, enter the name you wish to use. User Name Enter your Username for the DDNS Service. (TZO.com uses your E-mail address.) Enter your current password for the DDNS Service.

  • Page 71: Firewall Rules

    ADE-4300/ADW-4300 User Guide Firewall Rules The Firewall Rules screen allows you to define "Firewall Rules" which can allow or prevent certain traffic. "Traffic" means incoming connection attempts, not packets. By default: • All Outgoing traffic is permitted. • All Incoming traffic is denied. Because of this default behavior, any Outgoing rules will generally Block traffic, and Incoming rules will generally Allow traffic.
  • Page 72 Advanced Features The WAN IP address or addresses covered by this rule. WAN Users Indicates whether or not connections covered by this rule should be logged. Use the Add button to create a new rule. Buttons The other buttons - Edit, Move, or Delete - require that a rule be selected first.
  • Page 73 ADE-4300/ADW-4300 User Guide Incoming Rules (Inbound Services) This screen is displayed when the "Add" or "Edit" button for Incoming Rules is clicked. Figure 54: Inbound Services Screen Data - Incoming Rules Screen Inbound Services Select the desired Service. This determines which packets are Service covered by this rule.
  • Page 74 Advanced Features desired values in the "Single/Start" and "Finish" fields to de- termine the address range. • Single address - Enter the required address in the "Sin- gle/Start" fields. This determines whether packets covered by this rule are logged. Select the desired action. •...
  • Page 75 ADE-4300/ADW-4300 User Guide • ALLOW by schedule, otherwise Block Note: • Any outbound traffic which is not blocked by rules you create will be allowed by the Default rule. • ALLOW rules are only useful if the traffic is already covered by a BLOCK rule.

  • Page 76: Firewall Services

    Advanced Features Firewall Services Services are used when creating Firewall Rules. If you wish to create a firewall rule, but the required service is not listed in the "Ser- vice" list, you can use this feature to define the required service or services. Once created, these services will be listed in the "Service"...
  • Page 77 ADE-4300/ADW-4300 User Guide Add/Edit Service This screen is displayed when the Add or Edit button on the Services screen is clicked. Figure 57 : Add/Edit Service Data - Add/Edit Service Services If editing, this shows the current name of the Service. Name If adding a new service, this will be blank, and you should enter a suitable name.

  • Page 78: Options

    Advanced Features Options This screen allows advanced users to enter or change a number of settings. For normal operation, there is no need to use this screen or change any settings. An example Options screen is shown below. Figure 58: Options Screen Data - Options Screen Internet •...

  • Page 79: Schedule

    ADE-4300/ADW-4300 User Guide Schedule This Schedule can be used for the Firewall Rules and the URL filter. Figure 59: Schedule Screen Data - Schedule Screen Schedule Each day of the week can scheduled independently. Two (2) separate sessions or periods can be defined. Session Session 1 2 can be left blank if not required.
  • Page 80 Advanced Features If you prefer to use a particular NTP server as the primary Use this NTP NTP server, check the checkbox "Use this NTP Server" and Server enter the Server's IP address in the fields provided.. If this setting is not enabled, the default NTP Servers are used.

  • Page 81: Virtual Servers

    ADE-4300/ADW-4300 User Guide Virtual Servers This feature, sometimes called Port Forwarding, allows you to make Servers on your LAN accessible to Internet users. Normally, Internet users would not be able to ac- cess a server on your LAN because: • Your Server does not have a valid external IP Address.

  • Page 82: Connecting To The Virtual Servers

    Advanced Features namic IP addresses (IP address is allocated upon connection, so it may change each time you connect). Figure 61: Virtual Servers Screen Data - Virtual Servers Screen Servers This lists a number of common Server types. If the desired Servers Server type is not listed, you can create a Firewall Rule to achieve the same effect as the Virtual Server function.

  • Page 83: Vpn (Ipsec)

    ADE-4300/ADW-4300 User Guide VPN (IPSec) The VPN (Virtual Private Network) feature in the ADE-4300/ADW-4300 allows you to create a VPN connection between 2 ADE-4300/ADW-4300s, or a remote PC to estab- lish a VPN connection to the ADE-4300/ADW-4300. To establish a VPN connection from a remote PC to the ADE-4300/ADW-4300, you need suitable (IPSec) VPN client software on your PC.
  • Page 84 Advanced Features VPN Policies Screen This screen is displayed when you select VPN on the Advanced menu. It allows you to create, modify and manage your VPN Policies. If you have not created any policies, the Policy Table will be empty. Figure 62: VPN Policies Screen Data - VPN Policies Screen Policy Table...
  • Page 85 ADE-4300/ADW-4300 User Guide View details of each current VPN Tunnel (connection) in a VPN Status sub-window. You also have the option of viewing the VPN Log. VPN Auto Policy Screen This screen is displayed when you click the Add Auto Policy button on the VPN Poli- cies screen, or when you edit an existing Auto Policy.
  • Page 86 Advanced Features Data - VPN-Auto Policy Screen General Enter a unique name to identify this policy. This name is not Policy Name supplied to the remote VPN endpoint. It is used only to help you manage the policies. Remote VPN If the remote endpoint has a dynamic IP address, select "Dynamic IP address".
  • Page 87 ADE-4300/ADW-4300 User Guide This setting is used when determining if the IKE policy Direction matches the current traffic. Select the desired option. • Responder only - Incoming connections are allowed, but outgoing connections will be blocked. • Initiator and Responder - Both incoming and outgoing connections are allowed.
  • Page 88 Advanced Features If enabled, security is enhanced by ensuring that the key is IPSec PFS (Per- changed at regular intervals. Also, even if one key is broken, fect Forward subsequent keys are no easier to break. (Each key has no Secrecy) relationship to the previous key.) This setting applies to both IKE and IPSec SAs.

  • Page 89: Microsoft Vpn

    ADE-4300/ADW-4300 User Guide VPN- Manual Policy Screen This screen is displayed when you click the Add Manual Policy button on the VPN Policies screen, or when you edit an existing Manual Policy. It allows you to define or edit a "Manual" VPN policy. An "Manual"...
  • Page 90 Advanced Features Check this if you wish NETBIOS traffic to be forwarded over NETBIOS Enable the VPN tunnel. The NETBIOS protocol is used by Microsoft Networking. Local LAN Local LAN This identifies which PCs on your LAN are covered by this policy.
  • Page 91 ADE-4300/ADW-4300 User Guide Select the desired Authentication Algorithm, and enter the key Authentication in the field provided. • For MD5, the key should be 16 ASCII characters (32 Hex characters). • For SHA-1, the key should be 20 ASCII (40 Hex charac- ters).

  • Page 92: Vpn Status Screen

    Advanced Features VPN Status Screen This screen is displayed when you click the VPN Log button on the VPN Policies screen, or on the Status screen. This screen allows you to view details of each current VPN Tunnel (connection). If there are no current connections, the status table will be empty.
  • Page 93 ADE-4300/ADW-4300 User Guide Microsoft VPN Microsoft VPN uses the Microsoft VPN Adapter which is provided in recent versions of Windows. This feature can be used to provide remote access to your LAN by individ- ual PCs. This method provides an alternative to using IPSec VPN, which is described in the previous chapter.
  • Page 94 Advanced Features Data – Microsoft VPN Screen PPTP Server Use this checkbox to enable or disable this feature as required. Enable To allow connection by remote Windows clients, you must enable this feature, and enter the client details (on the Clients screen) to allow them to login to this Server.

  • Page 95: Windows Client Setup

    ADE-4300/ADW-4300 User Guide VPN Server Status Screen This screen is displayed when you click the VPN Server Status button on the Micro- soft VPN screen. Figure 67: Microsoft VPN Status Screen Data - Microsoft VPN Status Screen Connection This table contains the following data about each current con- nection.
  • Page 96 Advanced Features Windows 98/ME 1. Click Start - Settings - Dial-up Networking 2. Select Make New Connection 3. Type a name for this connection, and ensure that "Microsoft VPN Adapter" is selected. Click "Next" to continue. Figure 68: Windows ME VPN Adapter 4.
  • Page 97 ADE-4300/ADW-4300 User Guide Figure 70: Windows ME VPN Dialing Properties To establish a connection: 1. Ensure you are connected to the Internet. 2. Select Start - Settings - Dial-up Networking 3. Double-click the new VPN entry in Dial-up Networking. 4. Enter your User name and Password, as recorded in the Client database on ADE- 4300 / ADW-4300.
  • Page 98 Advanced Features 3. On the screen below: • Select "Do not dial the initial connection" if Internet access is via the LAN. • If using a PPPoE software client, select "Automatically dial this initial connec- tion" and select the PPPoE connection. •...
  • Page 99 ADE-4300/ADW-4300 User Guide Figure 74: Windows 2000 Connection Availability 6. Enter a suitable name, and click "Finish" to save and exit. Figure 75: Windows 2000 Finish Wizard Setup is now complete. To establish a connection: Right-click the connection in "Network Connections", and select "Connect". You will then be prompted for the username and password.
  • Page 100 Advanced Features • The Properties dialog has a Networking tab with a "Type of VPN" setting. If you have trouble connecting, you can change this setting from "Automatic" to "PPTP VPN". Windows XP Ensure you have logged on with Administrator rights before attempting this procedure. 1.
  • Page 101 ADE-4300/ADW-4300 User Guide Figure 78: Windows XP Connection Name 5. On the screen below, select "Do not dial the initial connection". Click Next to continue. Figure 79: Windows XP Public Network 6. On the screen below, enter the Domain Name or Internet IP address of ADE-4300 / ADW-4300 you wish to connect to.
  • Page 102 Advanced Features 7. Choose whether to allow this connection for everyone, or only for yourself, as required. Click Next to continue. Figure 81: Windows XP Connection Availability 8. On the final screen, click Finish to save and exit. Setup is now complete. To establish a connection: Right-click the connection in "Network Connections", and select "Connect".

  • Page 103: Snmp

    ADE-4300/ADW-4300 User Guide SNMP Simple Network Management Protocol (SNMP) is the protocol which enable adminis- trator to monitor network and bandwidth usage as well as various other network parameters like system information and port usages, providing system administrators with live readings and periodical usage trends to optimize the network efficiency. SNMP Screen Select Advanced on the main menu, then SNMP, to see a screen like the following: Figure 82: SNMP Screen...

  • Page 104: Chapter 7 Advanced Administration

    Chapter 7 Advanced Administration This Chapter explains the settings available via the "Administration" section of the menu. Overview Normally, it is not necessary to use these screens, or change any settings. These screens and settings are provided to deal with non-standard situations, or to provide additional options for advanced users.

  • Page 105: Pc Database

    ADE-4300/ADW-4300 User Guide PC Database The PC Database is used whenever you need to select a PC (e.g. for the "DMZ" PC). • It eliminates the need to enter IP addresses. • Also, you do not need to use fixed IP addresses on your LAN. However, if you do use a fixed IP address on some devices on your LAN, you should enter details of each such device into the PC database, using the PC Database screen.
  • Page 106 Advanced Features Data - PC Database Screen This lists all current entries. Data displayed is name (IP Address) Known PCs type. The "type" indicates whether the PC is connected to the LAN. Name If adding a new PC to the list, enter its name here. It is best if this matches the PC's "hostname".
  • Page 107 ADE-4300/ADW-4300 User Guide PC Database - Advanced This screen is displayed if the "Advanced Administration" button on the PC Database is clicked. It provides more control than the standard PC Database screen. Figure 84: PC Database (Admin) Data - Advanced PC Database Known PCs This lists all current entries.
  • Page 108 Advanced Features Select the appropriate option: IP Address • Automatic - The PC is set to be a DHCP client (Windows: "Obtain an IP address automatically"). The ADE-4300/ADW- 4300 will allocate an IP address to this PC when requested to do so. The IP address could change, but normally won't. •...

  • Page 109: Config File

    ADE-4300/ADW-4300 User Guide Config File This feature allows you to download the current settings from the ADE-4300/ADW- 4300, and save them to a file on your PC. You can restore a previously-downloaded configuration file to the ADE-4300/ADW- 4300, by uploading it to the ADE-4300/ADW-4300. This screen also allows you to set the ADE-4300/ADW-4300 back to its factory default configuration.

  • Page 110: Logging

    Advanced Features Logging The Logs record various types of activity on the ADE-4300/ADW-4300. This data is useful for troubleshooting, but enabling all logs will generate a large amount of data and adversely affect performance. Since only a limited amount of log data can be stored in the ADE-4300/ADW-4300, log data can also be E-mailed to your PC.
  • Page 111 ADE-4300/ADW-4300 User Guide Logs Include (Check- Use these checkboxes to determine which events are boxes) included in the log. Checking all options will increase the size of the log, so it is good practice to disable any events which are not really required. •...

  • Page 112: E-Mail

    Advanced Features E-mail This screen allows you to E-mail Logs and Alerts. A sample screen is shown below. Figure 87: E-mail Screen Data - E-mail Screen E-Mail Notification Check this box to enable this feature. If enabled, the E-mail Turn E-mail address information (below) must be provided.
  • Page 113 ADE-4300/ADW-4300 User Guide E-mail Alerts Send E-mail You can choose to have alerts E-mailed to you, by checking the desired checkboxes. The ADE-4300/ADW-4300 can send alerts immedi- an immediate alert when it detects a significant security inci- ately dent such as •...

  • Page 114: Diagnostics

    Advanced Features Diagnostics This screen allows you to perform a "Ping" or a "DNS lookup". These activities can be useful in solving network problems. An example Network Diagnostics screen is shown below. Figure 88: Network Diagnostics Screen Data - Network Diagnostics Screen Ping Ping this Enter the IP address you wish to ping.

  • Page 115: Remote Administration

    ADE-4300/ADW-4300 User Guide Remote Administration If enabled, this feature allows you to manage the ADE-4300/ADW-4300 via the Inter- net. Figure 89: Remote Administration Screen Data - Remote Administration Screen Remote Administration Check to allow administration/management via the Internet. Enable Remote (To connect, see below).
  • Page 116 Advanced Features To connect from a remote PC via the Internet 1. Ensure your Internet connection is established, and start your Web Browser. In the "Address" bar, enter "HTTP://" followed by the Internet IP Address of the ADE-4300/ADW-4300. If the port number is not 80, the port number is also re- quired.

  • Page 117: Routing

    ADE-4300/ADW-4300 User Guide Routing Overview • If you don't have other Routers or Gateways on your LAN, you can ignore the "Routing" page completely. • If the ADE-4300/ADW-4300 is only acting as a Gateway for the local LAN seg- ment, ignore the "Routing" page even if your LAN has other Routers. •...

  • Page 118: Configuring Other Routers On Your Lan

    Advanced Features Figure 90: Routing Screen Data - Routing Screen RIP Direction Select the desired RIP Direction. Choose the RIP Version for the Server. RIP Version Static Routing This list shows all entries in the Routing Table. Static Routing Table Entries •...
  • Page 119 ADE-4300/ADW-4300 User Guide 4300 itself. Typically, routers have a special entry for the Default Route. It should be configured as follows. Destination IP Address Normally 0.0.0.0, but check your router documenta- tion. Network Mask Normally 0.0.0.0, but check your router documenta- tion.
  • Page 120 Advanced Features local Router) Metric Entry 2 (Segment 2) Destination IP Address 192.168.2.0 Network Mask 255.255.255.0 (Standard Class C) Gateway IP Address 192.168.0.100 Metric For Router A's Default Route Destination IP Address 0.0.0.0 Network Mask 0.0.0.0 Gateway IP Address 192.168.0.1 (ADE-4300/ADW-4300's IP Address) For Router B's Default Route Destination IP Address...

  • Page 121: Upgrade Firmware

    ADE-4300/ADW-4300 User Guide Upgrade Firmware The firmware (software) in the ADE-4300/ADW-4300 can be upgraded using your Web Browser. You must first download the upgrade file, then select Upgrade Firmware on the Ad- ministration menu. You will see a screen like the following. Figure 92: Router Upgrade Screen To perform the Firmware Upgrade: 1.

  • Page 122: Chapter 8 Modem Mode

    Chapter 8 Modem Mode This Chapter explains configuration and operation when in "Modem" or "Bridge" mode.. Overview There are two modes available on the Mode screen. • Router - Both the ADSL Modem and the Router features are operational. In this mode, this device can provide shared Internet Access to all your LAN users.

  • Page 123: Home Screen

    ADE-4300/ADW-4300 User Guide Home Screen If in Modem mode, the home screen will look like the example below. Figure 93: Home Screen - Modem Mode Note that the menu has changed, many of the options in Router mode are not avail- able.

  • Page 124: Mode Screen

    Advanced Administration Mode Screen This screen is change back to Router mode, if desired. Figure 94: Mode Screen Data - Mode Screen Device This field displays the current name of this device. Name Select the desired device mode for the router: Device Mode •...

  • Page 125: Status Screen

    ADE-4300/ADW-4300 User Guide Status Screen In Modem mode, the Status screen looks like the example below. Figure 95: Status Screen - Bridge Mode Data - Status Screen (Bridge Mode) System The current name of the Router. This name is also the Device Name "hostname"...
  • Page 126 Advanced Administration For each VC (Virtual Circuit), the current status is dis- VC 1 Status played. This will be either "Enabled" or "Disabled". VC 2 Status VC 3 Status VC 4 Status Click this button to open a sub-window and view the details ADSL Details of each VC (Virtual Circuit).

  • Page 127: Appendix A Troubleshooting

    Appendix A Troubleshooting This Appendix covers the most likely problems and their solutions. Overview This chapter covers some common problems that may be encountered while using the ADE-4300/ADW-4300 and some possible solutions to them. If you follow the suggested steps and the ADE-4300/ADW-4300 still does not function properly, con- tact your dealer for further advice.

  • Page 128: Wireless Access (Adw-4300 Only)

    Appendix A - Troubleshooting • Check the ADE-4300/ADW-4300's status screen to see if it is working correctly. Problem 2: Some applications do not run properly when using the ADE- 4300/ADW-4300. The ADE-4300/ADW-4300 processes the data passing through it, so Solution 2: it is not transparent.
  • Page 129 ADE-4300/ADW-4300 User Guide devices should be shielded or relocated. • RF Shielding Your environment may tend to block transmission between the wireless stations. This will mean high access speed is only pos- sible when close to the ADW-4300.

  • Page 130: Appendix B About Wireless Lans(Adw-4300 Only)

    Appendix B About Wireless LANs (ADW-4300 only) This Appendix provides some background information about using Wireless LANs (WLANs). Modes Wireless LANs can work in either of two (2) modes: • Ad-hoc • Infrastructure Ad-hoc Mode Ad-hoc mode does not require an Access Point or a wired (Ethernet) LAN. Wire- less Stations (e.g.

  • Page 131: Channels

    ADE-4300/ADW-4300 User Guide performance. This capability is called Roaming. (Access Points do not have or require Roaming capabilities.) Channels The Wireless Channel sets the radio frequency used for communication. • Access Points use a fixed Channel. You can select the Channel used. This allows you to choose a Channel which provides the least interference and best perform- ance.

  • Page 132: Wireless Lan Configuration

    Appendix B - About Wireless LANs The same encryption method must be used. The most Encryption common encryption method is TKIP. Another widely- supported method is AES. Wireless LAN Configuration To allow Wireless Stations to use the Access Point, the Wireless Stations and the Access Point must use the same settings, as follows: On client Wireless Stations, the mode must be set to "Infrastruc- Mode...

  • Page 133: Appendix C About Vpns

    Appendix C About VPNs Overview A VPN (Virtual Private Network) provides a secure connection between 2 points, over an insecure network - typically the Internet. This secure connection is called a VPN Tunnel. There are many standards and protocols for VPNs. The standard implemented in the ADE-4300/ADW-4300 is IPSec.

  • Page 134: Vpn Configuration

    Appendix C - VPNs Because the IKE and IPsec connections are separate, they have different SAs (secu- rity associations). Policies VPN configuration settings are stored in Policies. Note that different vendors use different terms. Generally, the terms "VPN Policy", "IPSec Policy", and "IPSec Proposal" have the same meaning. However, some ven- dors separate IKE Policies (Phase 1 parameters) from IPSec Policies (Phase 2 parameters).

  • Page 135: Common Vpn Situations

    ADE-4300/ADW-4300 User Guide Common VPN Situations VPN Pass-through Figure 96: VPN Pass-through Here, a PC on the LAN behind the Router/Gateway is using VPN software, but the Router/Gateway is NOT acting as a VPN endpoint. It is only allowing the VPN connec- tion.

  • Page 136: Vpn Example

    Appendix C - VPNs Connecting 2 LANs via VPN Figure 98: Connecting 2 VPN Gateways This allows two (2) LANs to be connected. PCs on each endpoint gain secure access to the remote LAN. • The 2 LANs MUST use different IP address ranges. •...
  • Page 137 ADE-4300/ADW-4300 User Guide Configuration Settings - Gateway A Gateway A should be configured as shown below. Figure 100: Gateway A Configuration...
  • Page 138 Appendix C - VPNs Configuration Settings - Gateway B Gateway B should be configured as shown below. Figure 101: Gateway B Configuration Settings Setting LAN A Gateway LAN B Gateway Notes Policy Name Example Example Name does not affect operation. Select a meaningful name.
  • Page 139 ADE-4300/ADW-4300 User Guide NetBIOS Enable Enable Disable if not required. Local LAN 192.168.0.1 192.168.1.1 Local Address subnet. IP address 255.255.255.0 255.255.255.0 Use a more restrictive Mask definition if possible. Remote LAN 192.168.1.1 192.168.0.1 Remote Address IP address 255.255.255.0 255.255.255.0 subnet. Mask Use a more restrictive definition if possible.

  • Page 140: Appendix D Specifications

    Appendix D Specifications ADSL 2/2+ VPN Firewall Router Product ADSL 2/2+ VPN Firewall Router, 802.11g Wireless ADSL 2/2+ VPN Firewall Router Model ADE-4300A/B, ADW-4300A/B Hardware Standard Multi-Mode code support ANSI T1.413 Issue 2 ITU-T G.994.1 (G.hs) rev. 3 ITU-T G.992.1(G.dmt)

  • Page 141: Wireless Interface (Adw-4300 Only)

    ADE-4300/ADW-4300 User Guide Management Web browser management Environment Specification Dimension (W x D x H) 199 mm x 150 mm x 33 mm Power 15V AC, 1A Power Consumption Maximum 15W, 51 BTU Temperature: 0~40 degree C (operating), -10~70 degree C (storage) Humidity 5%~ 95% (non-condensing) Emission...

  • Page 142: Regulatory Approvals

    Appendix D - Specifications Regulatory Approvals FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interfer- ence to radio communications.

This manual is also suitable for:

Adw-4300a/bAde-4300aAde-4300bAdw-4300aAdw-4300b

Table of Contents
