Hiland AFP-RT Owner's Manual

Hiland AFP-RT Owner's Manual

Outdoor gas firepit

Advertisement

5010198
ANS Z21.97-2014 • CSA 2.41-2014 Outdoor Decorative Gas Appliance
ATTACH YOUR RECEIPT HERE
Serial Number
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-888-775-1330, 7 a.m. - 4 p.m., PST, Monday – Friday, or email
warranty@azpatioheaters.com
Purchase Date
OWNER'S MANUAL
OUTDOOR GAS FIREPIT
MODEL # AFP-RT
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance and
immediately call your gas supplier or fire department.
WARNING
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
WARNING:
DANGER
CARBON MONOXIDE HAZARD
This appliance can produce
carbon monoxide which has
no odor. Using it in an enclosed
space can kill you. Never use this
appliance in an enclosed space
such as a camper, tent, car or home.
WARNING
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
Read the installation, operating, and maintenance
instructions thoroughly before installing or servicing this
equipment.
For Outdoor Use Only
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AFP-RT and is the answer not in the manual?

Questions and answers

Summary of Contents for Hiland AFP-RT

  • Page 1 OWNER’S MANUAL OUTDOOR GAS FIREPIT MODEL # AFP-RT DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. If odor continues, keep away from the appliance and immediately call your gas supplier or fire department.
  • Page 2: Carbon Monoxide Hazard

    FOR OUTDOOR USE ONLY ! This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm If you smell gas and/or hear a gas hissing sound: 1. Immediately, SHUT OFF gas to the appliance. 2.
  • Page 3: Safety Information

    SAFETY INFORMATION Before you assemble or operate this unit, please read carefully this entire Owner's Manual. Failure to do so may result in a fire, explosion, injury or death. The installation of this unit must adhere to local codes or either the National Fuel Gas Code, ANSI Z223.
  • Page 4 • DO NOT fill tank over 80% full. • The tank system must be set up for vapor withdrawal. • STOP using if any part of the Propane Gas Tank is damaged. Rust and dents in tank may be hazardous and should be inspected by a Gas Supplier. •...
  • Page 5 • Keep the appliance area clear and free from combustible material, gasoline and other flammable vapors and liquids. • If the flame goes out while burning, turn the gas valve off. Wait 5 minutes before repeating the initial lighting procedure. Once you have a flame started, hold down the control knob for 1 minute.
  • Page 6 • Children and adults should be alerted to the hazards of high surface temperatures and should stay away to avoid burns or clothing ignition. • Young children MUST BE carefully supervised at all times when they are in the area of this appliance. •...
  • Page 7: Part List

    PART LIST DESCRIPTION ITEM# Polyester Cover Table Lid Battery 1BOX Fire Glass Fire Table with Burner Panel F ITEM# DESCRIPTION Panel G Screw(M6*40MM) 2PCS Panel H 4PCS Screw(M8*10MM) Door Spacer 4PCS Tank Holder Wrench Rail Screw(M6*15MM) 8PCS Michel's Clip 4PCS 1SET Wind Screen...
  • Page 8: Assembly Instruction

    ASSEMBLY INSTRUCTION 1, Check the control knob for gas supply system is turned to OFF position before starting your assembly. 2.Put tank Holder(J) into panel(F) and panel(H). Attach it with 2 screws (a) using the Wrench(d). Please do not fully tighten. 3.Insert Door (I) into the hole on the Tank Holder(J).
  • Page 9 5.Attach Panels (G),(F)and (H)using 4 Screws(e)using the Wrench(d). Fully tighten akk screws. 6.Fit the Table (B) onto the metal base,making sure the metal base mates with the window of the Panel. 7.Secure the metal base to the Top using 4 Screws (b) and (c) using the Wrench(d). 8.Your Fire Table is finished.
  • Page 10 Assembly Inserting the glass Assembling the glass Unscrew all preassembled screws on the glass clamps Insert the glass assembly made in step 2 into the ridge on (F). Then, assemble one short glass panel (G) to one long glass panel (H). Repeat for the other short glass panel (G) and long glass panel (H).
  • Page 11 USAGE Connect hose and regulator to cylinder The propane gas and cylinder are sold separately. Use a standard 20 lb. propane cylinder only. Use this heater only with a propane vapor withdrawal supply system. See chapter 5 of the standard for storage and handling of liquefied petroleum gas, ANS/NFPA 58.
  • Page 12 The knob on the LP tank must be closed. Make sure that the knob is turned clockwise to a full stop. The cylinder supply system must be arranged for vapor withdrawal. Check that the control knob on the control unit is turned off. Hold the regulator in one hand and insert the nipple into the valve outlet.
  • Page 13 Leak Check WARNING • Perform all leak tests outdoors. • Extinguish all open flames. • NEVER leak test when smoking. • Do not use the fire pit until all connections have been leak tested and do not leak. Hose / Regulator Regulator / Cylinder connection connection...
  • Page 14 OPERATION INSTRUCTIONS DANGER DANGER • CARBON MONOXIDE HAZARD Very hot while in a operation! Never lean over the fireplace while in use. • For outdoor use only. Never use inside house, or Do not touch tile of spark guard while the fire pit is in operation, wait until the fire pit has cooled down after other unventilated or enclosed areas.
  • Page 15: For Your Safety

    WARNING FOR YOUR SAFETY Be careful when attempting to manually ignite this fire pit. Holding in the control knob for more than 10 seconds before igniting the gas will cause a ball of flame upon ignition. When fire pit is ON: Burner will display tongues of blue and yellow flame.
  • Page 16 9. Fire pit is away from gasoline or other flammable liquids or vapors. 10. Fire pit is away from windows, air intake openings, sprinklers and other water sources. 11. Fire pit is at least 24 in. on rear and at least 24 in. on sides from combustible materials. 12.
  • Page 17 CARE AND MAINTENANCE Gas odor with extreme yellow tipping of flame. Fire pit does NOT reach the desired temperature. Fire pit glow is excessively uneven. Fire pit makes popping noises. Spiders and insects can nest in burner or orifices. This dangerous condition can damage fire pit and render it unsafe for use.
  • Page 18: Troubleshooting

    TROUBLESHOOTING If you have any questions regarding the product, please call customer service at 1-888-775-1330, 7 a.m. - 4 p.m. (PST), Monday - Friday. PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Wait until the propane cylinder Propane cylinder is frosted over warms up and becomes unfrosted Burner won’t light Blockage in orifice Clear blockage...
  • Page 19 AZ Patio Heater, LLC (“Vendor”) warrants to the original retail purchaser of this heater to no other person, that if this heater is assembled and operated in accordance with the printed instructions accompanying it, then for a period of one year from the date of purchase, all parts in the heater shall be free from defects in manufacturing and workmanship.
