FIREPLACE- NATURAL GAS- LPG STOVE
INSTRUCTION MANUAL
MODEL
HERMETIC HDU - 3
HERMETIC HDU - 5
HERMETIC HDU - 8
HERMETIC HDU - 9
HERMETIC HDU - 10
FUNNELED HBS - 12 HBS - 9
HERMETIC FIREPLACE HS 8,10
PLASMA FIREPLACE
HP 3,5,8,10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDU-5 and is the answer not in the manual?

Questions and answers

Summary of Contents for HOSSEVEN HDU-5

  • Page 1 FIREPLACE- NATURAL GAS- LPG STOVE INSTRUCTION MANUAL MODEL HERMETIC HDU - 3 HERMETIC HDU - 5 HERMETIC HDU - 8 HERMETIC HDU - 9 HERMETIC HDU - 10 FUNNELED HBS - 12 HBS - 9 HERMETIC FIREPLACE HS 8,10 PLASMA FIREPLACE HP 3,5,8,10...
  • Page 2: Hermetic

    GENERAL SAFETY WARNINGS Do not install your Do not use bottled gas hermetic stove into upside down or tilted. traditional chimney Hose of your stove must Use TSE certified bottled not be longer than 130 gas. Do not use crushed and crooked bottled gas.
  • Page 3 CE MARKING CE marking fulfills the requirement of appliances burning gaseous fuels 90/396/EEC (GD453/2003) directive.Stove comply to. EN 613 Independent gas-fired convection heaters UE 2016/426 Gas Appliance Regulation (GAR) 2011/65/EU Directive on the restriction of use of certain hazardous substance (RoHS) 2009/125/ECEcodesign requirements forenergy-reletad products(ErP) Regular control (e.g: yearly maintenance) of stove must be ensured.
  • Page 4: Table Of Contents

    INDEX 1. Hermetic stove features ……………………………………………… 2. Warnings before installation ……………………………………………… 3. Site Selection ……………………………………………… 4. Installation ……………………………………………… 5. Feature of Vented Stove ……………………………………………… 5.1. Connecting vented stove to the flue ……………………………………………… 5.2. Placement of flue to the stove ……………………………………………… 6.
  • Page 5: Hermetic Stove Features

    HERMETIC STOVE FEATURES It operates independently from its environment with special smoke duct. It takes necessary fresh air from external environment thanks to special smoke duct, and also it releases exhaust gas with special smoke duct to the external environment. When pilot flame extinguishes due to any reason, system automatically closed itself and secured.
  • Page 6: Hermetic

    The wall, where device connection will be done, must be fireproof and resistant to minimum 270C. The outlet in the external wall cannot be opened to everywhere. Take measures by replacing protective marble, plates, etc. under your stove. Do not connect hermetic kit to the flue.
  • Page 7: Hermetic

    Diameter of hole to be drilled on the wall is 27 cm. Hermetic stove must be mounted to the wall, of which external side is open. Lower edge of the exhaust duct outlet mouth must be at least 30 cm above from ground. Wall thickness must be maximum 42 cm, minimum 20 cm. Make sure that minimum 1 cm, maximum 5 cm between air inlet holes and wall surface.
  • Page 8: Installation

    4. INSTALLATION Remove stove from its packaging by holding its sides. Drill flue hole of your Hoşseven natural gas stove according to wall mounts scheme as shown in Figure 9. Drill screw holes and insert dowels on condition that measures will be taken into account in the same way. Ensure that the wall, where installation to be done, is heat resistant or necessary isolations are done in order to make it resistant, due to rear body of the stove will be heated during combustion.
  • Page 9: Connecting Vented Stove To The Flue

    combustion can be observed due to special thermal shock resistant glass, which is made from ceramic material. The heated surfaces are covered with high quality enamel. 5.1 CONNECTING VENTED STOVE TO THE FLUE Make sure that flue, which will be connected to stove, is clean and well draught. Connect your stove to shunt (indirect) or free-standing flue.
  • Page 10: Gas Connection Type

    Figure-6: Vented stove installation location 6. GAS CONNECTION TYPE Gas connection of device must be done according to ISO 07.01.1994 The clamp must be done to the 90 bracket end on device; with 1/2 bushed and sealed connection for NG ø...
  • Page 11: Natural Gas Connection

    WARNING: The appliance can only be operated by gas family defined on the data label of appliance. Nominal values of gas supply pressure; * For Natural Gas G20 / 20 mbar * For LPG G30/30 mbar. Allowed maximum gas pressure 50 mbar. WARNING: If the pressure of gas supply is higher than 50 mbar ,in this case using a gas pressure regulator.
  • Page 12: Gas Leakage Control

    Figure 8: Tube connection type Prefer the collector set, of which figure is given above. Do not use pipe collector due to leakage, do not use material such as casting due to it is not appropriate for gas pressure. TSE logo, hose document and manufacturing date must be available on used hose.
  • Page 13: Commissioning Of The Device

    7. COMMISSIONING OF THE DEVICE After your device is installed according to abovementioned instructions, make Hoşseven Authorized Service do commissioning operations. Otherwise, your device will be outside of scope of warranty. Hoşseven is entitled to not carry out commissioning operations until electricity, gas connections missing and/or faults are eliminated for installation, electricity and gas connections, which are not complying with Hoşseven service installation instructions.
  • Page 14: Extinguishing Of The Stove

    In the various positions of thermostat button (1,2...7), thermostat opens and closes gas path according to temperature in the environment, where stove is placed. For example, when environment temperature is 17 C, stove opens gas path in approximately in 3 position and burner starts to burn.
  • Page 15: Cleaning Of Device

    Do not use any cleaning agent, detergent for cleaning. It is recommended to make control of your stove in each year and to make authorized service to do general maintenance at least every other year. 10. TECHNICAL INFORMATION MODEL HDU-3 HBS-12 HDU-10 HDU-5 HDU-8/HHS-9 HP-10 HS-10 N. HEAT POWER (kW) 11,5 7,9/8,7 TYPE HERMETİC...
  • Page 16: Gas Conversion

    11. GAS CONVERSION Only Hoşseven Stations are authorized for gas conversion of Hoşseven brand devices. For the usage of natural gas; the approval must be obtained from Local Gas Distribution Company. Insert gas valve between device and mains. For Gas mains connection, remove hose end and seal, make R ½...
  • Page 17 PROBLEM CAUSE OF FAILURE SOLUTION Pilot does not burn -Close regulator and natural -Open valve gas valve -Clean injector. Hose must -Pilot injector is clogged. be maximum 130 cm. Hose is long or air is While holding pressed accumulated in connection lighter, continue to press pipe thermostat button for a...
  • Page 18 4. The possible damages, which may occur during shipping after delivery date, are outside of the guarantee scope. 5. The damages and failures arising from high, low or unstable voltage, faulty electrical installation, voltage value unsuitable for product, over current passing over device, phase transition to the neutral or earth circuit (phase overlap) are outside of the guarantee scope.
  • Page 19: Declaration Of Conformity

    Ankara yolu 18. km Barakfakih San. Böl. Bursa / Turkey Tel: 0224 384 11 10 Fax: 0224 384 11 14 e-mail: hosseven@hosseven.com.tr web: www.hosseven.com.tr 17. AUTHORIZED SERVICE CENTERS Customer Service Headquarter is the Hoşseven Factory, of which full address is given above;...
  • Page 20 HDU 10 WALL MOUNTS SCHEME HDU 5 and HDU 3 WALL MOUNTS SCHEME Figure-9: Wall Mounts Scheme...
  • Page 21 GUARANTEE CONDITIONS In case natural gas stove is mounted according to manual and used in accordance with instructions stated in manual, and is not intervened with the maintenance-repair purposes by other people outside of Hoşseven Authorized Service: Guarantee period starts with delivery of the product. Guarantee period is 2 years. Whole goods are covered under guarantee, including all parts.
  • Page 22 CERTIFICATE OF WARRANTY Document Number: 116242 Document Issue Date: 31.08.2012 Document Expiry Date: 31.08.2014 The use of this certificate was permitted by the Ministry of Trade and Industry General Directorate for the Protection of Consumers and Competition pursuant to Law Concerning the Protection of Consumers Nr: 4077 and the Regulation Concerning the Implementation Principles of the Guarantee Certificate enforced based on this law.
  • Page 24 FIRST RUN COUPON OF NATURAL GAS STOVE The first run of the devices will be carried out by our Model: authorized service as free of charge. Type: ……………………. 1) Do not run your device before our service our service Valve No: ……………………. carry out first run.
  • Page 25 Authorized Service Customer Name: ………………………………… Seal and signature Address: ……………………………………………… : ……………………………………………… : ……………………………… Telephone: ……………… Start-up date: ……/……/201… customer Signature First run of the machine is carried out by authorized service.
  • Page 26 ① ② ③ FAILURE COUPON FAILURE COUPON FAILURE COUPON Date of fault : ………………………….. Date of fault : ………………………….. Date of fault : ………………………….. Customer name : ………………………….. Customer name : ………………………….. Customer name : ………………………….. Product nr. : ………………………….. Product nr.
