FOUNDATION SERIES - PIER
Co-linear Direct Vent Gas Fireplaces
Installation and Operating Manual
Natural Gas
FDN-4-PIER
FDN-5-PIER
FDN-6-PIER
FDN-7-PIER
WARNING: If the information in these instructions are not followed exactly, a fire or explosion may result
causing property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS
—
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use any phone in your building.
•
Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
•
If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Please contact your Heat & Glo dealer with any questions or concerns.
Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19
Heat & Glo, a brand of Hearth & Home Technologies
7571 215
Street West, Lakeville, MN 55044
th
www.heatnglo.com
For the location of your nearest Heat & Glo dealer,
please visit www.heatnglo.com.
Installer:
Leave this manual with the appliance.
Consumer: Retain this manual for future reference.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Heat & Glo FDN-5-PIER
Summary of Contents for Heat & Glo FDN-5-PIER
- Page 1 Please contact your Heat & Glo dealer with any questions or concerns. For the location of your nearest Heat & Glo dealer, please visit www.heatnglo.com. Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19...
-
Page 2: Table Of Contents
Optional Mechanical Damper H. Wall Termination Cap Installation With and Without Optional Mechanical Damper I. Intake Air J. Changing From Side Intake Air to Bottom Intake Air Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 3: Safety Information
For more information go to: www.P65Warnings.ca.gov. • The flow of combustion and ventilation air must not be obstructed. Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 4: Fireplace Specifications
This is the allowable finishing width and height required to fit the glass panels into the fireplace. A* & B* Finishing materials shall not overlap dimensions. Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 5: Clearances
A COMBUSTIBLE HEARTH EXTENSION MAY BE USED AT THE BOTTOM OF GLASS VIEWING. DO NOT OVERLAP GLASS. * MINIMUM DISTANCE RECOMMENDED FROM ALL VIEWABLE SIDES OF APPLIANCE FOR SERVICE ACCESS = 24 IN. [610 mm]. Figure 2B Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 6: Installation Overview
• This fireplace may be installed in a bedroom. • Please be aware of the amount of heat this fireplace will produce when determining a location. Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 7: Prepare The Fireplace
(2) screws each on the back of the fireplace. Figure 3A.3 Placement of the standoffs and nailing flanges on the Pier fireplace. Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 8: Nailing Tab Installation
Refer to Figure 3B.5 Depending on your installation and how you frame it out, you may not use the provided nailing flanges. 1" Figure 3B.4 Figure 3B.5 Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 9: Framing
Build hearth to desired size and height. If a hearth extension is desired, combustible material may be used. Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 10: Pier Framing Dimensions
SEE SECTION 10 (FINISHING) FOR DETAILS REGARDING 1/2 INCH STANDOFFS. STEEL SURFACE MAY BE COVERED WITH NON-COMBUSTIBLE FINISHING MATERIAL. Figure 4.1 PIER Framing Dimensions 1" [25] CLEARANCE TO THE B-VENT MUST BE MAINTAINED. Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 11: Support Bracket
3. Ensure fireplace is fully supported and leveled and then remove support brackets. Caution! Risk of Injury! DO NOT remove support brack- ets until fireplace is fully supported and level. SUPPORT BRACKET Figure 4.2 Support Bracket Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 12: Mantel Requirements
COMBUSTIBLE HEARTH COMBUSTIBLE OR NON-COMBUSTIBLE MATERIAL SINGLE SIDED EXAMPLE: RIGHT SIDE VIEW APPLIES TO BOTH SIDES AND ENDS IF USING A MULTI-SIDED FIREPLACE NOTE: Refer to Page 33-34 for more information on fi nishing the wall. Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 13: Non-Combustible Zone - Not Using The Provided
COMBUSTIBLE HEARTH COMBUSTIBLE OR NON-COMBUSTIBLE MATERIAL SINGLE SIDED EXAMPLE: RIGHT SIDE VIEW APPLIES TO BOTH SIDES AND ENDS IF USING A MULTI-SIDED FIREPLACE NOTE: Refer to Page 33-34 for more information on fi nishing the wall. Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 14: Glass Frame Assembly
NOTE: GLASS REMOVAL AND INSTALLATION MUST BE PERFORMED WITH TWO PEOPLE. NOTE: Glass must be removed using quality suction cups. DO NOT attempt to remove the glass without using proper suction cups. NOTE: IN CASE OF CHIPPED OR BROKEN GLASS Have your dealer assist you with contacting Hearth & Home Technologies to get the proper glass specifications. Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 15: Install Glass Frame Assembly
Remove the lower trim panel that sits between the layer of glass. Remove the inner trim vertical panels. Using the suction cups, remove the inner panel in the same manner. Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 16: Gas Line Specifications & Access
SEE CHART ON PAGE 5 INPUT BTU/HR SEE CHART ON PAGE 5 SEE CHART ON PAGE 5 BALL VALVE 1/2 INCH GAS SUPPLY GAS VALVE Figure 7 Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 17: Gas And Electrical Access Panels
4 [102} 2X 7-15/32 [190] GLASS 7/8 [22] 2X 8-23/32 [222] 1-3/32 [28] 3 [76] 1-1/2 [38] 1-1/2 [38] 2-3/4 [70] 3-7/32 [82] 11-1/8 [283] Figure 8 Access Panel Dimensions Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 18: Venting
3. Place the intake collar base plate onto the silhouette, Figure 8.1 In-Line Powervent (PVI-67) matching up the holes as shown in Figure 8.4. Fasten the base plate to the silhouette using five self-tapping screws. Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 19: Horizontal Vent System Clearances
Connect the ten inch exhaust B-Vent to the collar and continue the vent run. SILHOUETTE CIRCLE Figure 8.5 Figure 8.3 Silhouette Circle on Intake B. HORIZONTAL VENT SYSTEM CLEARANCES ALL APPROVED VENTING BOTTOM SIDES HORIZONTAL 1 inch (25mm) 1 inch (25mm) 1 inch (25mm) C. WALL PASS-THROUGH - Follow all local codes for requirement of firestops. Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 20: Vertical Terminations
*Clearance must be in accordance with local installation codes & the requirements of the gas supplier. NOTE: A vent cannot be located directly above a side-walk or paved driveway that is located between two single family dwellings and serves both dwellings. VENT TERMINAL SUPPLY INLET AREA WHERE TERMINAL IS NOT PERMITTED Figure 8E.1 Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... - Page 21 G = Combustible 24” (609.6mm) = Non-combustible 12” (304.8mm) M = Combustible 24” (609.6mm) = Combustible 24” (609.6mm) = Non-combustible 12” (305mm) = Non-combustible 12” (304.8mm) Figure 8E.2 Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19...
-
Page 22: Vertical Termination Vent Cap Location & Clearances
(610MM) * = 24” TO A COMBUSTIBLE SIDE WALL 12” TO A NON-COMBUSTIBLE SIDE WALL IMPORTANT: ALL DIMENSIONS ARE FROM THE EDGE OF THE CAP Figure 8F Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 23: Roof Termination Cap Installation With And Without
POWERVENT MOUNTING BRACKETS OR DRILL MOUNTING HOLES TO MATCH BASE INSULATION PAD MUST BE CUT IN CENTER TO ACCOMMODATE VENT SIZE OPTIONAL MECHANICAL FLUE DAMPER Figure 8G.2 Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 24: Wall Termination Cap Installation With And Without
MUST BE CUT IN CENTER TO ACCOMMODATE VENT SIZE USE APPROPRIATE HEAVY DUTY FASTENERS TO SECURE POWER VENT ACCESS PANEL NEEDED FOR FUTURE DAMPER SERVICE Figure 8H.2 Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 25: Intake Air
Turn plate so collar is facing down, slide plate into slots on each side. Step 4: Re-attach the plate with four screws. Refer to Figure 8J.3A and Figure 8J.3B Refer to Figure 8J.4 INSTALL 4 SCREWS Figure 8J.3A Figure 8J.3B Figure 8J.4 Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 26: Electrical
The powervent and flame will not turn on for 30-60 seconds after switch is activated and the powervent will run for 30 seconds after it has been shut off. FACTORY CONNECTED FACTORY CONNECTED Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 27: Field Wiring - Service And Troubleshooting
9 - ELECTRICAL B. FIELD WIRING (SERVICE & TROUBLESHOOTING) Figure 9B Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 28: Terminals 1 & 2 - Led Lights
9 - ELECTRICAL C.1 TERMINALS 1 & 2 - LED Lights Figure 9C.1 Terminals 1 & 2 C.2 TERMINALS 3 & 4 - Main Flame Figure 9C.2 Terminals 3 & 4 Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 29: Terminals 5 & 6 - Fireplace Power
9 - ELECTRICAL C.3 TERMINALS 5 & 6 - Fireplace Power Figure 9C.3 Terminals 5 & 6 C.4 TERMINALS 7 & 8 - Powervent Connection Figure 9C.4 Terminals 7 & 8 Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 30: Terminals 9 & 10 - Flue Damper Connection
9 - ELECTRICAL C.5 TERMINALS 9 & 10 - Flue Damper Connection NOTE: OPTIONAL IF A DAMPER IS NOT USED DO NOT CONNECT ANYTHING TO TERMINALS 9 & 10 Figure 9C.5 Terminals 9 & 10 Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 31: Terminals 11 & 12 - Flue Damper Prove
9 - ELECTRICAL C.6 TERMINALS 11 & 12 - Flue Damper Prove SEE NOTE NOTE: OPTIONAL IF A DAMPER IS NOT USED TERMINALS 11 AND 12 HAVE A JUMPER ACROSS THEM Figure 9C.6 Terminals 11 & 12 Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 32: Terminals 13 & 14 - Vacuum Switch
“COM” OR “NO” TERMINALS IN THE VACUUM SWITCH FOR FIREPLACE 1. TERMINAL #14 CONNECTS TO THE “COM” OR “NO” TERMINALS IN THE VACUUM SWITCH FOR FIREPLACE 1. Figure 9C.7 Terminals 13 & 14 Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 33: Finishing The Wall - Using The Provided 1/2" Standoffs
(shown above), side, back and inside behind the glass. Please take consideration of which option will be used to access the components for service later during planning. I. Combustible framing and finishing materials allowed. Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 34: Finishing The Wall -Not Using The Provided 1/2" Standoffs
(shown above), side, back and inside behind the glass. Please take consideration of which option will be used to access the components for service later during planning. I. Combustible framing and finishing materials allowed. Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 35: Lighting & Shutdown
The fireplace has a pre and post timer, set at the factory for 30 seconds. The powervent and flame will not turn on for 30-60 seconds after switch is activated and the powervent will fun for 30 seconds after it has been shut off. Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 36: If The Fireplace Does Not Light
If you don't smell gas, go to next step. Turn ON all electrical power to fireplace. Turn fireplace on at switch. Figure 11B CAUTION: If fireplace will not operate, follow instructions TURNING OFF GAS TO FIREPLACE and call your service technician or the gas supplier. NOTE: When fireplace is initially lit, condensation will appear on the glass; this is normal in all gas fireplaces and will disappear after several minutes. Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 37: Pressure Testing
When fireplace is first lit, the flames will be blue. Flames will gradually turn yellowish-orange during first 15 minutes of operation. If flames remain blue, or become dark orange with evidence of sooting (black tips), the burner tube venturi may need adjustment. Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... -
Page 38: Maintenance
Propane Conversion Kit LPK-FDN GLA-P4-IN (INNER) PART PART NUMBER QUANTITY Side Service Glass, 4 ft. GLA-P4-OUT (OUTER) Varies by model size GLA-P5-IN (INNER) FDN-4-PIER = 8 bags Side Service Glass, 5 ft. GLA-P5-OUT (OUTER) Crystal Rock, 5 lb bag 2188-851 FDN-5-PIER = 9 bags GLA-P6-IN (INNER) FDN-6-PIER = 11 bags Side Service Glass, 6 ft. FDN-7-PIER = 13 bags GLA-P6-OUT (OUTER) GLA-P7-IN (INNER) Side Service Glass, 7 ft. GLA-P7-OUT (OUTER) NOTE: All appliances utilize two pieces of side service glass. Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19... - Page 39 Firebox and heat exchanger Lifetime All replacement parts 90 Days beyond warranty period See conditions, exclusions, and limitations on next page. 4021-645H 10/15 Page 1 of 2 Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19...
- Page 40 THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE. 4021-645H 10/15 Page 2 of 2 Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 • 2/19...
