FOUNDATION SERIES - SEE THROUGH
Co-linear Direct Vent Gas Fireplaces
Installation and Operating Manual
Natural Gas
FDN-4-ST
FDN-5-ST
FDN-6-ST
FDN-7-ST
WARNING: If the information in these instructions are not followed exactly, a fi re or explosion may result
causing property damage, personal injury or loss of life.
— Do not store or use gasoline or other fl ammable vapors and liquids in the vicinity of this or any other
appliance.

WHAT TO DO IF YOU SMELL GAS

—
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use any phone in your building.
•
Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
•
If you cannot reach your gas supplier, call the fi re department.
— Installation and service must be performed by a qualifi ed installer, service agency or the gas supplier.
Please contact your Heat & Glo dealer with any questions or concerns.
Heat & Glo • FDN-4-ST, FDN-5-ST, FDN-6-ST, FDN-7-ST Installation Manual • 16400-9801 Rev. H • 11/19
Heat & Glo, a brand of Hearth & Home Technologies
7571 215
Street West, Lakeville, MN 55044
th
www.heatnglo.com
For the location of your nearest Heat & Glo dealer,
please visit www.heatnglo.com.
Installer:
Installer:
Leave this manual with the appliance.
Leave this manual with the appliance.
Consumer: Retain this manual for future reference.
