Brady BradyJet J2000 Replacement Manual

Ink pad replacement

Hide thumbs Also See for BradyJet J2000:

IMPORTANT!

Check the ink pads periodically for excessive ink saturation and replace when necessary.

Note: It is recommended to replace the ink pads after 20,000 prints.

Order Ink Pad Replacement Kit #Y4660270

1. Turn off power and remove power cord.

2. Carefully turn printer over and remove the two screws on the

metal cover.

3. Remove old felt pad and foam strip.

4. Fold new foam pad and fit into channel as shown.

Quick Start Guide

Felt Pad

Foam Strip

Felt Strip

Table of Contents

Do you have a question about the BradyJet J2000 and is the answer not in the manual?

Page 1: Quick Start Guide
Ink Pad Replacement Quick Start Guide Felt Pad Foam Strip Felt Strip IMPORTANT! Check the ink pads periodically for excessive ink saturation and replace when necessary. Note: It is recommended to replace the ink pads after 20,000 prints. Order Ink Pad Replacement Kit #Y4660270 1.
Page 2 10. Slide the end of the felt strip without notches into opening, as shown. 11. Fold felt strip down into trough so small tabs fit into notches on felt. 12. Use a needle-nose pliers or similar tool to press felt securely into place. © 2018 Brady Corporation. All Rights Reserved.
