DuraSea Roof Top Air Conditioner
Description
Model
Air Conditioner
489516P
489516A
Read these instructions carefully. These
instructions MUST stay with this product.
USA
SERVICE OFFICE
Dometic Corporation
1120 North Main Street
Elkhart, IN 46514
RECORD THIS INFORMATION FOR FUTURE
REFERENCE:
Model Number
Serial Number
ADB Model Number
ADB Serial Number
Date Purchased
Roof Top Unit
Use With Air Distribution Box (not included)
Model
3314861.000
CANADA
Dometic Corporation
46 Zatonski, Unit 3
Brantford, ON N3T 5L8
CANADA
Control
Integral Mechanical
SERVICE CENTER &
DEALER LOCATIONS
Please Visit:
www.eDometic.com
Advertisement
Table of Contents
Related Manuals for Dometic 489516P series
Summary of Contents for Dometic 489516P series
- Page 1 REVISION B DEALER LOCATIONS SERVICE OFFICE Dometic Corporation Form No. 3315430.000 08/16 Dometic Corporation 46 Zatonski, Unit 3 Please Visit: (French 3315824.000_B) 1120 North Main Street Brantford, ON N3T 5L8 www.eDometic.com ©2016 Dometic Corporation Elkhart, IN 46514 CANADA LaGrange, IN 46761...
-
Page 2: Table Of Contents
This unit can be installed by one person with brief help from additional personnel. Use these instructions to ensure a properly installed, and properly functioning product. Dometic Corporation reserves the right to modify appearances and specifications without notice. TABLE OF CONTENTS INTRODUCTION ..................................2... -
Page 3: Important Safety Instructions
● Do NOT add any devices or accessories to this product except those specifically authorized in writing by Dometic Corporation. DOCUMENT SYMBOLS I ndicates additional information that is NOT related I ndicates step-by-step instructions. -
Page 4: Specifications
3.5 kW / 5.0 kW For wire length over 24 ft., consult the National Electrical Code for proper sizing. ** Dometic Marine gives GENERAL guidelines for generator requirements. To reduce start-up power draw by up to 65%, consider installing a Dometic SmartStart. -
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS Choosing Proper Location For Unit c. Check inside the boat's cabin for air distri- bution box (hereinafter referred to as "ADB") This unit is specifically designed for installation on the roof obstructions (i.e. space for doors to open, of a boat. -
Page 6: Wiring Requirements
INSTALLATION INSTRUCTIONS Placing Unit On Roof Using the roof opening as a guide, cut the match- ing hole in the ceiling. 1. Remove the unit from the carton and discard carton. The opening created must be framed to provide adequate support and prevent air from being 2. -
Page 7: Installing Unit
INSTALLATION INSTRUCTIONS Installing Unit FIG. 7 1. C heck for correct alignment and adjust the unit as necessary (roof gasket centers over the roof opening). See (FIG. 5). FIG. 5 Center Unit From Below Electrical Measure Ceiling Thickness Cord 5. - Page 8 INSTALLATION INSTRUCTIONS 6. Ceiling Template Installation f. Hold the ceiling template up to the roof open- ing and start each mounting bolt, by hand, a. Plug the 6 pin electrical cord from the top unit through the ceiling template and up into the into the matching 6 pin connector in the elec- unit base pan.
-
Page 9: Wiring System
INSTALLATION INSTRUCTIONS Wiring System FIG. 15 Ceiling Template 1. 120 Vac Power Supply Connection Alignment Holes a. ELECTRICAL SHOCK HAZ- ARD. Verify 120 Vac power is disconnected from boat. Failure to obey this warning could result in death or serious injury. b. - Page 10 INSTALLATION INSTRUCTIONS 2. Install two (2) (supplied) sheet metal screws in- FIG. 19 side return air opening to secure ADB to ceiling template. See (FIG. 17). 3. Install eight (8) (supplied) wood screws inside Slot In ADB the front, rear and side doors to secure ADB to ceiling.
-
Page 11: Operating Instructions
OPERATING INSTRUCTIONS Controls Wait at least 2 minutes before restarting the compressor when it has been 1. The Selector Switch has (8) positions including manually cycled off with either the selector "OFF". This controls fan speeds, cooling modes switch or the temperature set lever. Other- and optional heating modes of operation. -
Page 12: Maintenance
MAINTENANCE Air Filter ADB Housing 1. Periodically (a minimum of every 2 weeks of op- 1. Clean ADB housing and control panel with a soft eration) remove the return air filter located be- cloth dampened with a mild detergent. Never hind the return air vent grille and wash it with use furniture polish or scouring powders. -
Page 13: Service - Unit Does Not Operate
● Go to WWW.dometic.com/marinedealers or ● Check your fuse or circuit breaker to see if it is ● Call Dometic Marine at 1-800-542-2477 8:00 open. Insure fuse is not burnt, or circuit breaker AM to 5:00 PM Eastern Time, or 1-888-440- is “ON”... -
Page 14: Owner's Limited Warranty
Dometic reserves the right to improve its products, through changes in design or material without being obligated to incorporate such changes in products of prior manufacture. Dometic can make changes at any time in design, materials, or part of units of any one, model year, without obligation or liability to owners of units of the same year's model of prior manufacture. -
Page 15: Coverage Period
Dometic warranty as described in Section A. For proof of date put in service, Dometic will require a copy of the bill of sale of the Dometic equipment from the installer or new boat dealer to the original owner. -
Page 16: Table Of Warranty Periods
ABLE ARRANTY ERIODS DOMETIC DURASEA ROOFTOP AIR CONDITIONING Important Notes: 1. Warranty periods begin from the date of possession of the boat by the first owner if OEM installed or date of installation if dealer installed, but not to exceed three (3) years from date of production. The warranty is transferable and will carry the remainder of the original owner's warranty based on the original date of pur- chase or date of installation.
