Bit P466 / P476 setting = 2
Drive Fault
0
0 = No Fault
1 Reserved
Run Forward
2
0 = NOT Run Forward
Run Reverse
3
0 = NOT Run Reverse
Drive Status
4
0 = NOT Ready
Control
5
0 = Local Control
Speed Reference
6
0 = Local Reference
Operation at Setpoint
7
0 = Setpoint not reached
8
Actual setpoint / reference source
0 - Keypad
9
1 - 0-10VDC
2 - 4-20mA
10
3 - Preset #1
4 - Preset #2
11
5 - Preset #3
PID Mode Status
12
0 = PID NOT Active
Torque Mode Status
13
0 = NOT in Torque Mode 1 = Torque Mode Active
Current Limit Status
14
0 = NOT in Current Limit
DC brake
15
0 = DC brake not active
Unsigned speed 0.1 Hz resolution
Digital input/Output States
Bit 2 - Output Fault Bit 3 - Fast Current Limit State
Bit 4 - TB1 ON Bit 6 - TB13A
Bit 7 - TB13B Bit 8 - TB13C
Bit 9 - TB14 Out State Bit 10 - Relay State
Bit 11 - Charge Relay Bit 12 - Assertion Level
Analog Input [0.01 VDC]; Active when P150 = 9
• Received value = 0x024B = 5.87 VDC
1 = Faulted
1 = Run Forward
1 = Run Reverse
1 = Ready
1 = Network Control
1 = Network Reference
1 = Setpoint reached
6 - Preset #4
7 - Preset #5
8 - Preset #6
9 - Preset #7
10 - MOP
11 - Network
1 = PID Active
1 = in Current Limit
1 = DC brake active
ENGLISH
Commissioning
P466 / P476 setting = 3
Bit
Drive Fault
0
0 = No Fault
1 Reserved
Run Forward
2
0 = NOT Run Forward
Run Reverse
3
0 = NOT Run Reverse
Drive Status
4
0 = NOT Ready
Control
5
0 = Local Control
Speed Reference
6
0 = Local Reference
Operation at Setpoint
7
0 = Setpoint not reached
8
Actual setpoint / reference source
0 - Keypad
9
1 - 0-10VDC
2 - 4-20mA
10
3 - Preset #1
4 - Preset #2
11
5 - Preset #3
PID Mode Status
12
0 = PID NOT Active
Torque Mode Status
13
0 = NOT in Torque Mode 1 = Torque Mode Active
Current Limit Status
14
0 = NOT in Current Limit
DC brake
15
0 = DC brake not active
Unsigned actual frequency 0.1 Hz resolution
Actual PID setpoint
Signed value -999...3100
Actual PID feedback
Signed value -999...3100
1 = Faulted
1 = Run Forward
1 = Run Reverse
1 = Ready
1 = Network Control
1 = Network Reference
1 = Setpoint reached
6 - Preset #4
7 - Preset #5
8 - Preset #6
9 - Preset #7
10 - MOP
11 - Network
1 = PID Active
1 = in Current Limit
1 = DC brake active
