Bit P446 / P456 setting = 4
Run Forward
0
0 = NOT Run Forward
Run Reverse
1
0 = NOT Run Reverse
2 Fault Reset: on transition from 0 to 1
3 Reserved
4 Reserved
Control
5
0 = Local Control
Speed Reference
6
0 = Local Reference
7 Reserved
8
Network setpoint / reference (when Bit 6 = 1)
0 - Network
9
1 - Keypad
2 - 0-10VDC
10
3 - 4-20mA
4 - Preset #1
11
5 - Preset #2
Controller inhibit
12
0 = No controller inhibit
Quick stop
13
0 = Quick stop not active 1 = Quick stop active
Force Mode (Network / PID modes only)
14
0 = No Action
DC brake
15
0 = DC brake not active
Unsigned Torque Setpoint
0 - 400% limited by P330 (Torque Limit)
Digital Output and Relay; Active when:
• Bit 9 = Open Collector (and P142 = 25)
• Bit 10 = Relay (and P140 = 25)
Others reserved for future use
Analog Output [0.01 VDCC]; Active when P150 = 9
• Received value = 0x024B = 5.87 VDC
(7)
Preset #4, #5, #6 and #7 are ignored when the drive is operating in either PID Mode or Torque Mode.
1 = Run Forward
1 = Run Reverse
1 = Network Control
1 = Network Reference
6 - Preset #3
7 - Preset #4 (7)
8 - Preset #5 (7)
9 - Preset #6
(7)
10 - Preset #7
(7)
11 - MOP
1 = Controller inhibit
1 = Force Manual / Open Loop Mode
1 = DC brake active
