Network

SERVER

The IP address' shown are for example only. Please consult with your I.T. for all required information relating to IP; DNS
Server, etc.
CENTER SERVER 1
OPTIONS
MESSAGE SERVER
OPTIONS
PORT
MEDIA SERVER
OPTIONS
PORT
The IP address' shown are for example only. Please consult with your I.T. for all required information relating to IP; DNS
Server, etc.
CENTER SERVER 2
OPTIONS
MESSAGE SERVER
OPTIONS
Cable Net Select this option when a CAT5/6 cable is directly connected
from a PC/Server to the 304-SD, or, when using an external Wi-Fi
radio.
Mobile Net Allows connection to the 304-SD via 2G/3G cellular networks.
Wi-Fi Net Select this value when the 304-SD is going to use the internal Wi-
Fi module for communications.
Domain Name If a fully qualified domain name is available, this option can be
utilized. Enter the FQDN in the text entry box below this option.
Static IP If a dedicated IP address can be assigned this option can be
selected. If this option is selected enter the IP address of the
server in the text box below. The IP address must use all digits
contained within the octet. For example, if the server has an IP
address of 10.5.0.100 the digits entered into the IP address text
box would be in the following format: 010.005.000.100
This should be left at its default value.
Domain Name If a fully qualified domain name is available, this option can be
utilized. Enter the FQDN in the text entry box below this option.
Static IP If a dedicated IP address can be assigned this option can be
selected. If this option is selected enter the IP address of the
server in the text box below. The IP address must use all digits
contained within the octet. For example, if the server has an IP
address of 10.5.0.100 the digits entered into the IP address text
box would be in the following format: 010.005.000.100
This should be left at its default value.
Cable Net Select this option when a CAT5/6 cable is directly connected from
a PC/Server to the 304-SD, or, when using an external Wi-Fi radio.
Mobile Net Allows connection to the 304-SD via 2G/3G cellular networks.
Wi-Fi Net Select this value when the 304-SD is going to use the internal Wi-Fi
module for communications.
Domain Name If a fully qualified domain name is available, this option can be
utilized. Enter the FQDN in the text entry box below this option.
Static IP If a dedicated IP address can be assigned this option can be
selected. If this option is selected enter the IP address of the
server in the text box below. The IP address must use all digits
contained within the octet. For example, if the server has an IP
address of 10.5.0.100 the digits entered into the IP address text
box would be in the following format: 010.005.000.100
